Jump Starter/Power Pack
OWNER'S MANUAL
PLEASE SAVE THIS OWNERS MANUAL AND READ BEFORE EACH
USE. This manual will explain how to use the unit safely and effectively.
Please read and follow these instructions and precautions carefully.
1. IMPORTANT SAFETY INSTRUCTIONS
WARNING – RISK OF EXPLOSIVE GASES.
WORKING IN THE VICINITY OF A LEAD-ACID BATTERY IS
DANGEROUS. BATTERIES GENERATE EXPLOSIVE GASES
DURING NORMAL OPERATION. IT IS IMPORTANT THAT YOU
FOLLOW THESE INSTRUCTIONS EACH TIME YOU USE THE UNIT.
To reduce the risk of battery explosion, follow these instructions and
those published by the battery manufacturer and the manufacturer
of any equipment you intend to use in the vicinity of a battery.
Review cautionary markings on these products and on the engine.
WARNING! RISK OF ELECTRIC SHOCK OR FIRE.
1.1 Read the entire manual before using this product. Failure to do so
could result in serious injury or death.
1.2 Keep out of reach of children.
1.3 Do not put fingers or hands into any of the unit's outlets.
1.4 Do not expose the unit to rain or snow.
1.5 Use only recommended attachments (SA934 jump cable). Use of an
attachment not recommended or sold by the jump starter manufacturer
for this unit may result in a risk of fire, electric shock or injury to persons
or damage to property.
1.6 To reduce the risk of damage to the electric plug or cord, pull by the
adaptor rather than the cord when disconnecting the unit.
1.7 Do not operate the unit with damaged cables or clamps.
1.8 Do not operate the unit if it has received a sharp blow, been dropped or
otherwise damaged in any way; take it to a qualified service person.
1.9 Do not disassemble the unit; take it to a qualified service person when
service or repair is required. Incorrect reassembly may result in a risk of
fire or electric shock.
1.10 Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
this device.
WARNING! RISK OF EXPLOSIVE GASES.
1.11 To reduce the risk of a battery explosion, follow these instructions and
those published by the battery manufacturer and the manufacturer of
any equipment you intend to use in the vicinity of the battery. Review
the cautionary markings on these products and on the engine.
1.12 Do not set the unit on flammable materials, such as carpeting,
upholstery, paper, cardboard, etc.
SAVE THESE INSTRUCTIONS.
MODEL
SL1517
0099002281-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL1517 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Schumacher SL1517

  • Page 1 Jump Starter/Power Pack MODEL SL1517 OWNER’S MANUAL PLEASE SAVE THIS OWNERS MANUAL AND READ BEFORE EACH USE. This manual will explain how to use the unit safely and effectively. Please read and follow these instructions and precautions carefully. 1. IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS.
  • Page 2: Personal Precautions

    NEVER attempt to pick up or move a hot, smoking, or burning product, as you may be injured. 2.13 Changes or modifications not expressly approved by Schumacher Electric Corporation could void the user’s authority to operate this device.
  • Page 3: Preparing To Use The Unit

    2.14 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4 4.5 Determine which post of the battery is grounded (connected) to the chassis. If the negative post is grounded to the chassis (as in most vehicles), see step 4.6. If the positive post is grounded to the chassis, see step 4.7. 4.6 For a negative-grounded vehicle, connect the POSITIVE (RED) clamp from the jump starter to the POSITIVE (POS, P, +) ungrounded post of the battery.
  • Page 5: Charging The Jump Starter

    6. CHARGING THE JUMP STARTER IMPORTANT! CHARGE IMMEDIATELY AFTER PURCHASE, AFTER EACH USE AND EVERY 30 DAYS, OR WHEN THE CHARGE LEVEL FALLS BELOW 85%, TO KEEP THE INTERNAL BATTERY FULLY CHARGED AND PROLONG BATTERY LIFE. 6.1 CHECKING THE LEVEL OF THE INTERNAL BATTERY 1.
  • Page 6 5. For a positive-grounded vehicle, connect the NEGATIVE (BLACK) clamp from the jump starter to the NEGATIVE (NEG, N, -) ungrounded post of the battery. Connect the POSITIVE (RED) clamp to the vehicle chassis or engine block away from the battery. Do not connect the clamp to the carburetor, fuel lines or sheet-metal body parts.
  • Page 7: Wireless Charging

    NOTE: The USB Fast Charging port requires a specific charging cable (not included). 4. When finished using the USB port, disconnect the charging cable from your mobile device and then disconnect the charging cable from the unit. 5. Recharge the unit as soon as possible after each use. NOTE: If no USB device is connected, power to the USB ports will automatically shut off after 30 seconds.
  • Page 8: Troubleshooting

    10. TROUBLESHOOTING Jump Starter PROBLEM SOLUTION The jump starter’s display will Make sure the unit is charged. not turn on. Connect to a power source, to reset. The thermometer symbol The unit is too hot or cold. The thermometer is flashing. symbol will disappear when the condition is removed.
  • Page 9: Specifications

    11. SPECIFICATIONS Internal battery type .......... Lithium ion polymer Capacity ................29.6 Wh USB input ............... USB, 2A USB output ........... Standard: 5V DC, 2.4A USB Fast Charging: 5V, 3A / 9V, 2A / 12V, 1.5A Jump start ..............1200A peak Charging Temperature......
  • Page 10 • 10 •...
  • Page 11 • 11 •...
  • Page 12 The Schumacher logo is a registered trademark of Schumacher Electric Corporation. • 12 •...
