Air
large space type
User's Manual
Read and SAVE THESE INSTRUCTIONS
Thank you for purchasing Air Purifier
Large space type "KL-F01"
Please read this owner's manual before you start using this appliance.
Read "Quick Start Guide" for the initial set up.
Purifier,
K L- F 0 1
The Flow of Use .......................................................... 3
Safety Precautions ...................................................... 4
Before Use ............................................................... 6
Name of Each Parts ................................................... 7
How to use ................................................................... 8
Care & Troubleshooting
How to Care and Maintain ......................................11
Trouble Shooting....................................................... 14
Specifications ............................................................ 15
Introduction
How to use
Advertisement
Related Manuals for Kaltech TURNED KL-F01
Summary of Contents for Kaltech TURNED KL-F01
-
Page 1: Table Of Contents
K L- F 0 1 Purifier, large space type User's Manual Read and SAVE THESE INSTRUCTIONS Introduction The Flow of Use ............3 Thank you for purchasing Air Purifier Safety Precautions ............4 Large space type “KL-F01” Please read this owner’s manual before you start using this appliance. Before Use …………………………………………..…………. - Page 2 The photocatalyst technology is applied to this large space type Air Purifier This product will bring you comfortable “noiseless space " Photocatalytic technology reduces a variety of odors What is "photocatalytic technology"? When a photocatalytically active material is irradiated with light, it has a strong oxidizing power. This strong oxidizing capability of the photocatalyst can be used to reduce pollutants in the air.
-
Page 3: The Flow Of Use
The Flow of Use How to Install See Quick Start Guide Getting started Just press the Power Button. Beep Use it P.8 – P.10 or See Quick Start Guide Pick the right place and scene for use, You can make your own comfortable space. How to turn off Press the Power Button. -
Page 4: Safety Precautions
Safety Precautions Please make sure to follow these instructions. Before using this product, be sure to read this "Safety Precautions" section. The following information is provided to ensure the correct and safe use of this product. Notation of this item ●... - Page 5 Safety Precautions(Continued) Caution. ● Do not use in the following places. ・Places where sprays and chemicals are used ・Close to combustible materials such as curtains and clothing. ・Locations with flammable/explosive gases ・Bathrooms and other places subject to water or high humidity ・Places exposed to direct sunlight or extreme ・Places where oil components, such as cooking oil, are floating.
-
Page 6: Before Use
Before Use Installation location ● Do not place any objects on the exhaust vent. 20cm intake Place the unit 20 cm away from the wall. Do not place any objects on top of the unit. When it is placed on the other side of the air conditioner, it increases the circulation effect, reduces unevenness in room temperature during heating and cooling, and increases the deodorizing effect. -
Page 7: Name Of Each Parts
Name of Each Parts Outlet Power Button Power Lamp Power Cord Sensor Sensitivity Lamp Odor Sensor Lamp Air Volume Lamp To the outlet. Light Display Button Top Panel Cover Sensor Sensitivity Button Air Volume switching Button Turbo Mode Button Louver Photocatalytic Filter (4 pcs) Handles &... -
Page 8: How To Use
How to use 1 Turn on the power Press the Power Button. Power Lamp lights up. Beep TURBO HIGH SILENT The levels of the odor in the room is displayed in three colors by the odor sensor. AUTO (In 3 stages: Green, Yellow and Red) Green: Clean When the air volume is set to "Auto", the air volume is Yellow: Slightly... - Page 9 How to Use (continued) 2 Set the sensor sensitivity (when using with the airflow set to "Auto") At first, it is set to "High". The sensitivity setting of the odor sensor varies depending on where it’s placed and environment around the product. Refer to "Recommended mode settings for various locations"...
- Page 10 How to Use (continued) Turbo mode, for 30 minutes When you want to sterilize/deodorize quickly (using turbo mode) ● It will then switch to automatic mode. Using the turbo mode, the room can be deodorized faster than in normal operation. If you want to change the turbo mode to the normal mode within 30 minutes, press the Air Volume Button to change back to the automatic mode.
-
Page 11: How To Care And Maintain
How to Care and Maintain Please keep the appliance front panel and vent area clean. In particular around the air outlet where dust and dirt stains may build up, ensure the air outlet surrounding areas are cleaned on a regular basis. If you want to know the recommended frequency of maintenance, see "Guide for caring ". - Page 12 How to Care and Maintain(continued) Rinse the dust on the surface of the Photocatalyst filter. Cleaning the Photocatalyst filter ● Rinse all 4 filters at once. Turn off the power. Remove the louvers. Press the end to remove the Top panel cover. ②...
- Page 13 How to Care and Maintain (continued) ※ Our recommended standard below. Guide for caring ● The frequency of the care depends on the usage environment. Cleaning Instructions Locations Pre-filter Pollen filter (2 filters at once) Photocatalytic filter (4 filters of once) Waiting room Once every 2 months Once every 3 months...
-
Page 14: Trouble Shooting
Trouble shooting Power does not turn on / does not work ■ Please check Possible solutions Is power plug inserted into the outlet correctly? Make sure the following is connected correctly. Please wait for electricity supply to resume. Is your area during power outage? Is the electrical circuit breaker at the location Turn back on the electrical circuit breaker. -
Page 15: Specifications
Power cord length Approx. 1.8m ※1 According to generally accepted standard, when the appliance is used for the applicable floor area 142mm it can reduce odor to comfortable level in about 30 minutes. (Depending on the environment) 203mm Kaltech Corporation FO1-tr ver.1.0... - Page 16 Kaltech Corporation FO1-tr ver.1.0 EN_KL-F01_User manual_E_v1.0_2309 3-3-7 Bakuromachi, Chuo-Ku, Osaka 541-0059, Japan...
