Summary of Contents for Tractive Technology Auto-Blip
- Page 1 2008-22 Dodge Challenger Customer collaboration (not verified by Auto-Blip) Version 1.2...
- Page 4 (Ignition must be off during installation!) • Locate OBD2 port • Connect Auto-Blip White wire to car’s wire at pin #16 • Connect Auto-Blip Black wire to car’s wire at pin #4 • You may need to loosen/detach the OBD2 port to better reach wires (rear of port) Connect to 16 (12v) &...
- Page 5 (Ignition must be off during installation!) • Locate accelerator pedal sensor (at or near pedal) • Connect Auto-Blip Red wire to either 2 or 5 2012 Challenger on the diagram (no specific order) • Connect Auto-Blip Green wire to remaining of...
- Page 6 Auto-Blip Break pedal signal wire tap installation (Ignition must be off during installation!) Brake pedal connection: • Locate brake pedal sensor/switch on the break pedal assembly (see diagram on the left; may be same/different in your car) • Connect Auto-Blip Blue wire to the brake light signal wire.
- Page 7 Auto-Blip Clutch pedal signal wire tap installation (Ignition must be off during installation!) Clutch pedal connection: • Locate clutch safety interlock switch. This switch is activated at the bottom of the clutch pedal travel (see Pic 3 bellow/left; may be same/different in your car) •...
-
Page 8: How It Works
How it works:... -
Page 9: Calibration Process
Calibration process... - Page 10 Calibration process...
- Page 11 Auto-Blip Limited Warranty...
