Summary of Contents for Godrej UV Case
- Page 1 Meet UV CASE Antivirus Case Quick, reliable & safe sanitization for all your belongings Kills 99.9% Viruses* Successfully tested at CSIR (ICMR approved laboratory) Conformity Certificate Quick Start Guide...
-
Page 2: Table Of Contents
TABLE OF CONTENT Unboxing the Godrej UV Case Important Instructions Know your product Operation Precaution during placement Precaution during maintenance Do’s and Don'ts Specifications Trouble shooting Information on E- waste and handling management Disclaimer Warranty... -
Page 3: Unboxing The Godrej Uv Case
UNBOXING THE GODREJ UV CASE I come with the following things: UV CASE UV Cabinet Warranty Card User Manual... -
Page 4: Important Instructions
IMPORTANT INSTRUCTIONS: Here’s what you need to know before we begin: 1. Do not look at the UV lamps directly in case the Godrej UV Case is switched on. 2. The UV Case must be installed in a dry place. - Page 5 17. Do not operate the UV case control panel with wet hands. Do not keep corrosive objects in the UV case. In case of fire, unplug the Godrej UV Case & use a CO based fire extinguisher. Do not use water for extinguishing electrical fires.
- Page 6 In case of any problem, please contact our call center - 18002099955 or write to us at secare@godrej.com.
-
Page 7: Know Your Product
KNOW YOUR GODREJ UV CASE Top opening provision Fuse protection UV-C lamp All around reflecting Knob for opening/ surface on internal walls closing... - Page 8 KNOW YOUR GODREJ UV CASE UV process end indicator with buzzer Power On/Off button Protection fuse on the backside wall Inside the case 2 UV lamps on topside 2 UV lamps at bottom Front opening provision Knob for opening/closing...
- Page 9 KNOW YOUR GODREJ UV CASE Protection fuse Knob for opening/closing on the backside wall Programmable timer Inside the case 3 UV lamps on topside Power On/Off button 3 UV lamps at bottom UV process end Front opening provision indicator with buzzer...
- Page 10 COVID-19 virus. My accurate build and design ensure UV energy on each point on the items placed inside the chamber. AND I COME IN THREE SIZES, CATERING TO DIFFERENT NEEDS! 15L UV Case 30L UV Case 54L UV Case...
-
Page 11: Operation
2. Pull the knob to open the lid and put your objects like mobile phone, watches, keys etc. inside the cabinet. 3. Close the lid and switch on the UV case. 4. For best result, the recommended sanitisation time is 12 minutes. - Page 12 1. Connect the case to the AC mains. The On/Off switch on the control panel make the operation easier. 2. The UV Case has an in-built analog timer with the default time set to 5 minutes. 3. Pull the knob to open the lid and put your objects like mobile phones, watches, keys etc.
- Page 13 4. Close the lid and switch on the UV Case. 5. After 5 minutes, the UV Case switches off automatically. A beep is heard to notify the user about the successful sanitization. 6. For best results, the recommended sanitisation time is 5 minutes.
- Page 14 NOTE There is an auto cut-off for safety purposes. If the user opens the lid during the sanitization process, the UV lamp goes off automatically.
-
Page 15: Precaution During Placement
INSTALLATION/PLACEMENT Here’s what you need to keep in mind while installing the UV Case: 1. Always keep the UV Case over a proper levelled surface. 2. Ensure that all 4 base supports touch the surface properly. 3. Improper electrical installation increases the risk of an electrical shock. -
Page 16: Do's And Don'ts
DO’S & DONT’S... - Page 17 4. Maintain the case in a clean condition. 5. Dispose off the replaced UV lamp in an eco-friendly manner. 6. Ensure the power socket is disconnected before cleaning the UV Case. 7. Ensure proper earthing practices before connecting the UV Case to the...
- Page 18 DON'T’S 1. Do not try to operate the UV Case with the lid open. Do not tamper with the safety lock of the lid. 2. Do not place the product on the edge of a surface. 3. Do not operate the UV Case if it is damaged. Ensure there is no damage to the lid, hinges and the safety lock.
-
Page 19: Specifications
SPECIFICATIONS - UV Case 15L Short wave UV-C radiation (peak at Operating Principle 253.7 nm) based disinfecting of surfaces from germs, bacteria & viruses 127.6 X 427.8 X 382.4 External Dimensions: HxWxD (mm) Internal Dimensions-Usable: HxWxD (mm) 124 X 326 X 380... - Page 20 SPECIFICATIONS - UV Case 15L UV-C Lights: Life /Tube (Hours) 11000 Lid Opening Ergonomic top opening design Cycle Time Manual control Audio Visual Alarm Auto UV-C Cut - off Safety Switch Supply Voltage 220 V ~ 240V Supply Current 5A...
- Page 21 SPECIFICATIONS - UV Case 30L Short wave UV-C radiation (peak at Operating Principle 253.7 nm) based disinfecting of surfaces from germs, bacteria & viruses External Dimensions : HxWxD (mm) 325 X 297.8 X 476.8 Internal Dimensions-Usable : HxWxD (mm) 298 X 236 X 417...
- Page 22 SPECIFICATIONS - UV Case 30L UV-C Lights: Life /Tube (Hours) 11000 Lid Opening Ergonomic front opening design Cycle Time Predefined Audio Visual Alarm Auto UV-C Cut - Off Safety Switch Supply Voltage 220 V ~ 240V Electrical Specifications Supply Current 5A...
- Page 23 SPECIFICATIONS - UV Case 54L Short wave UV-C radiation (peak at Operating Principle 253.7 nm) based disinfecting of surfaces from germs, bacteria & viruses External Dimensions : HxWxD (mm) 350 X 540 X 519.2 Internal Dimensions-Usable : HxWxD (mm) 241 X 437 X 510...
- Page 24 SPECIFICATIONS - UV Case 54L UV-C Lights: Life /Tube (Hours) 11000 Lid Opening Ergonomic front opening design Cycle Time User selectable Audio Visual Alarm Auto UV-C Cut - off Safety Switch Supply Voltage 220 V ~ 240V Electrical Specifications Supply Current 5A...
-
Page 25: Troubleshooting
2. Check the On/ Off switch and whether it is properly turned on. 3. Check the limit switch functionality (near the closing end of the lid). Can’t figure out what the issue is? Get in touch with our Godrej customer care at 1800-209-9955 or write to us at secare@godrej.com... - Page 26 THE FUSE BLOWS FREQUENTLY Get in touch with our Godrej customer care at 18002099955 or write to us at secare@godrej.com...
-
Page 27: Faq
However, there is no specific study that talks about COVID-19. But it is prolific & clinically accepted. 3. Can we disinfect our hands? No, you cannot disinfect any body parts by using Godrej UV Case or any UV light. We recommend alcohol based liquid sanitizers and/or washing body parts with soap & water. - Page 28 4. What are the precautions to keep in mind while using Godrej UV Case? Godrej UV Case is designed keeping all safety precautions in mind. One should avoid direct contact of any body part with the UVC light or directly looking into the UVC tube.
-
Page 29: Information On E-Waste And Handling Management
Schedule 1 (please refer to our website www.godrej.com in the 'Good & Green' section of CSR module for more details). Under these rules, specific roles and responsibilities are defined for producers, consumers and recyclers handling and managing e-waste. - Page 30 Centre(s) or registered dismantler(s), or recycler(s) or is returned to the pick-up/take back services provided by the producers. (Please refer to our website www.godrej.com in the 'Good & Green' section of CSR module for more details).
-
Page 31: Disclaimer
UV Case/ Home / Office Safes, Video Door Phones, Burglar Alarm Systems, or any theft, fire, robbery, fraud or other wrongful act done by any third Party with regard to UV Case/ Home / Office Safes, Video Door Phones, Burglar Alarm Systems including but not limited to... -
Page 32: Warranty
WARRANTY CARD Please fill your details below for future reference: Date of Purchase: Product Model: Name & Address of Distributor/Dealer: Distributor Phone Number: FOR SAFETY, PLEASE READ THIS MANUAL PRIOR TO USE.
