RJ-761 Multi-function Keyboard
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RJ-761 and is the answer not in the manual?

Questions and answers

Summary of Contents for RockJam RJ-761

  • Page 1 RJ-761 Multi-function Keyboard User Guide...
  • Page 2: Important Information

    Important Information Be sure to obey the following information so as not to harm yourself or others or damage this instrument or other external equipment. Power adapter: • Please use only the specified AC adapter supplied with the product. An incorrect or faulty adapter can cause damage to the electronic keyboard.
  • Page 3: Table Of Contents

    Contents Important Information ........................... 1 Controls, Indicators and External Connections .................... 4 Front Panel .............................. 4 External Connections ..........................5 LCD Display ............................. 5 Preparation Before First Use ........................6 Power ............................... 6 Use of AC/DC power adapter: ......................6 Battery operation: ..........................
  • Page 4 Start / Stop: ............................12 Sync: ..............................13 Fill in: ..............................13 Accompaniment Volume Adjustment: ....................13 Tempo Adjustment: ........................... 13 Chord Accompaniment .......................... 14 Single Finger Chords: ........................14 Chord Tones: ............................ 14 Intro / Ending: ............................ 14 Recording Function ..........................15 Rhythm Programming ..........................
  • Page 5: Controls, Indicators And External Connections

    Controls, Indicators and External Connections Front Panel 17. Transpose 1. Speaker 18. Rhythms List 2. Power Switch 19. Tones List 3. Start / Stop 20. LCD Screen 4. Dual / Split 21. Demo 5. Sync / Fill in 22. Tone 6.
  • Page 6: External Connections

    External Connections 1. MIDI Output 2. Sustain Pedal Input 3. AUX IN 4. Headphone Output 5. DC 12V Power Input LCD Display 1. TONE, RHYTHM or DEMO song 2. Digital display for song, rhythm and tone number 3. Metronome for rhythm and song 4.
  • Page 7: Preparation Before First Use

    Preparation Before First Use Power Use of AC/DC power adapter: Please use the AC/DC power adapter that came with the electronic keyboard or a power adapter with DC 12V output voltage and 1,000mA output current with a centre positive plug. Connect the DC plug of the power adapter into the DC 12V power socket on the rear of the keyboard and then connect the other end into the mains wall socket and switch on.
  • Page 8: Connecting The Sustain Pedal

    Connecting the sustain pedal: This electronic keyboard has a 6.35mm socket for connecting a sustain pedal (included). Connect the pedal to the 6.35mm socket. Connecting an Amplifier or Hi-Fi Equipment: This electronic keyboard has a built in speaker system but it can be connected to an external amplifier or other hi-fi equipment.
  • Page 9: Connecting A Phone Or Audio Device To The Aux Input To Play Music Through The Keyboard

    Connecting a phone or audio device to the AUX Input to play music through the keyboard: This keyboard has a built-in speaker system that can be used to play music from your phone or mobile device. Insert one end of a stereo audio cable into the AUX IN socket on the back of the keyboard and connect the other end into your phone or audio device.
  • Page 10: Keyboard Operation

    Keyboard Operation Power and Volume Power control: Press the [POWER] button to turn the power on and again to turn the power off. The LED will light blue to indicate standby and red for power on. Adjustment of the Master Volume: The keyboard has 16 levels of volume from 000(off) - 015.
  • Page 11: Effect & Control

    Effect & Control Dual Tone Keyboard: Dual Tone mode allows the keyboard to mix two tones and play them at the same time. To switch on Dual Tone Keyboard mode touch the [DUAL / SPLIT] button. The LCD display will show that Dual tone mode is active by showing [Dual] in the left side mode indicator.
  • Page 12: Vibrato

    Vibrato: Touch the [VIBRATO] button to enter Vibrato mode. The LCD display will display that [VIBRATO] is on. Once this mode is selected each time a note is played a trembling effect is added to the end of the note. Touching the [VIBRATO] button again will turn the Vibrato feature off and exit this mode.
  • Page 13: Panel Percussion Instruments

    Panel Percussion Instruments: When the [RE-PLAY/ PERCUSSION] button is touched the keyboard’s keys turn into a percussion instrument, the LCD will show ‘Perc’ to indicate percussion mode. Play the keyboard accordingly and the percussion sounds will be heard. Touch the [RE-PLAY/PERCUSSION] button again to exit Percussion mode.
  • Page 14: Sync

    Sync: Touch the [SYNC / FILL IN] button to select the sync accompaniment function. Pressing any of the first 19 keys on the left hand side of the keyboard will start the rhythm playing. Touch the [START / STOP] button to stop the rhythm and exit the sync function.
  • Page 15: Chord Accompaniment

    Chord Accompaniment Single Finger Chords: Touch the [CHORD] button to activate the combined single and multi finger chord function. The LCD screen will display this once the function is activated. Chords are played by pressing certain keys in the chord area on the left hand side of the keyboard (keys 1-19). The finger patterns required are shown in Appendix V.
  • Page 16: Recording Function

    Recording Function Touch the [REC / PROGRAM] button to enter the recording mode. The LCD will indicate that the recording function is on by showing [Record] in the left side Mode display. Press any key to start recording. The maximum recording capacity is 118 notes. When the recording capacity is full the LCD display will show [FL].
  • Page 17: Demo Songs

    Demo Songs: Touch the [DEMO] button to play a demo song. The LCD display will show [XXX DEMO] where xxx is the number of the demo song. By pressing the + and - button on the numerical keypad you can choose the demo song you require.
  • Page 18: Synchronised Course

    Synchronised Course: Touch the [TEACH] button x 2 to enter the Synchronised teaching mode. The LCD screen will display [Course 2] in the Mode display area. This mode is suitable for more advanced users. The LCD display will show [XXX DEMO] where xxx is the number of the demo song selected. Select a different song using the +/- or number keys.
  • Page 19: Appendix I. Percussion Instruments

    Appendix I. Percussion Instruments Percussion Instrument Percussion Instrument Percussion Instrument C1 Click (Square Wave) G#2 Hi-Hat Pedal E4 Conga L C#1 Brush Tap A2 Low Tom F4 Timbale H D1 Brush Swirl A#2 Hi-Hat Open F#4 Timbale L D#1 Brush Slap B2 Mid Tom L G4 Agogo H E1 Brush Swirl W/Attack...
  • Page 20: Appendix Ii. Rhythm Table

    Appendix II. Rhythm Table No. Rhythm Rhythm Rhythm Rhythm Name Name Name Name 8 Beat Swing Beat Jazz Samba Soul Psychedelic 16 Beat 8 Ballad March 1 Classical ballad 1 Soul 16 Beat Step March 2 Classical ballad 2 Rock Beat Big Band1 March 3 Classical ballad 3...
  • Page 21 16 Beat 1 Tango 1 Jazz Waltz 3 Modern Lyric 1 16 Beat 2 Tango 2 Country Waltz 1 Modern Lyric 2 16 Beat 3 Tango 3 Country Waltz 2 Modern Lyric 3 16 Ballad 1 Mambo 1 Punk Swing 1 Middle East pop 16 Ballad 2 Mambo 2...
  • Page 22: Appendix Iii. Tone Table

    Appendix III. Tone Table Tone Name Tone Name Tone Name Tone Name Acoustic Grand Synth Strings 1 FX 5 Flute String Piano (Brightness) Bright Acoustic Synth Strings 2 FX 6 (Goblins) Synth Piano Harmonica Electric Grand Choir Aahs FX 7 (Echoes) Synth Piano Xylophone...
  • Page 23 Acoustic Guitar Recorder Telephone Ring Rhythm (Nylon) Orchestra Acoustic Guitar Pan Flute Helicopter Pizzicato Violin (Steel) Electric Guitar Bottle Blow Applause Pizzicato (Jazz) Ensemble 1 Electric Guitar Shakuhachi Gunshot Pizzicato (Clean) Ensemble 2 Electric Guitar Whistle Perc Board Percussion (Muted) Band Overdriven Ocarina...
  • Page 24: Appendix Iv. Demo Song Table

    Appendix IV. Demo Song Table Name of Song Name of Song Beautiful Prairie My Home Liuyang River Rose Waiting For Love Little Star Fascinated Water Village In My Dream Hot dance Music Cucurbit Flute Song Of Herding Sheep Happy Birthday To You Passionate Music Rhythm Of Rain Passionate...
  • Page 25: Appendix Vi. Chord Tables

    Appendix VI. Chord Tables Single Finger Chords Page | 24...
  • Page 26: Fingered Chords

    Fingered Chords Page | 25...
  • Page 27: Appendix Vii. Technical Specification

    Appendix VII. Technical Specification • Display LCD Display with staff and key Indication • Touch control and MIDI Output • Tone 200 tones • Rhythm 200 rhythms • Demo 30 different demo songs • Effect and Control Dual keyboard, Split keyboard, Sustain, Sustain pedal, Vibrato, Transpose •...
  • Page 28: Fcc Compliance Statement

    FCC Compliance Statement FCC Class B Part 15 This device complies with Part 15 of the Federal Communications Commission (FCC) Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
