SEA 23110550 Manual

Sistemi Elettronici
di Apertura Porte e Cancelli
International registered trademark n. 804888
The 433.920 Mhz FM transmission module (TX) 23110550, has been projected by SEA S.r.l. to accelerate the inherent activities of installation and to guarantee
the maximum reliability in the field of long distance transmission of an opening and/or closing command of doors, gates and shutters, to a compatible receiver
module; the available functions are: presence of two (two channel version) or four (four channel version) command buttons.

TECHNICAL SPECIFICATIONS

Power supply:
Absorption:
Transmission frequency:
Range:
Code:
N.of channels:
Working Temperature:
Warehousing Temp.:
Dimensions:
Humidity:
* Note: The operating ranger of this device (as that of all the devices operating with radio frequency), can vary in base of the electromagnetic pollution, the entity of
the spurious signals RF on the installation site, or by possible obstacles postioned within the radio transmitter and the relative receiver.

DESCRIPTION OF THE TRANSMITTERS' FUNCTION

Code setting
Set the desired code using the micro-switch with 10 positions
producer as damaged device which has to be repaired, make sure that it doesn't simply concern unloaded battery. On average replace the battery of the
transmitters every 6-12 months.
Functioning of the red led
- RED LED ON: Command in phase of transmission
- RED LED OFF: No command in phase of transmission
SPARE PARTS
To obtain spare parts contact:
SEA s.r.l. Zona Ind.le, 64020 S.ATTO Teramo Italia

INTENDED USE

The 433.920 MHz FM transmission module (TX) 23110550 has been planned to be used exclusively as a transmitter of digital data at 433.920 Mhz FM frequency
send to a receiver produced by SEA S.r.l. which receives in the same frequency and is codified to be interfaced with a 433.920 Mhz FM transmission module (TX)
23110550; the transmitter module must be used only as generator of commands to be sent to a SEA S.r.l receiver for the automation of openings and / or closings
of doors, gates and leaves and must be power supplied with security tension (12 Vdc, 23 A battery).

SAFETY AND ENVIRONMENTAL COMPATIBILITY

It is strongly recommended to not spoil the environment with product and circuit packing material.

CONFORMITY

The 433.920 MHz FM transmission module (TX) 23110550 is conform with the following rules:
• Ruel 1999/5/CE (R&TTE)
• ETS 300 683, ETS 300 220
• EN 60065
The user of this device must respect the valid Laws in the Country of application.

STORAGE

T
min
- 30°C
When being transported this product must be properly packaged and handled with care.
DISTRIBUTION COUNTRIES
SEA S.r.l. Sells the products 23110550 in the Countries ofthe European Community.

MAINTENANCE

The only intervention of maintenance applicable to this device is the replacement of the battery, when there occurs a drastic reduction of range or no functioning at
all.

LIMIT OF GUARANTEE

The 433.920 MHz FM transmission module (TX) 23110550 is guaranteed for a period of 24 months. The guarantee period starts from the date stamp printed on the
unit. The module (TX) guarantee will be void if the unit has been incorrectly installed, not used for the purpose intended, tampered with, or modified in any way The
validity of this guarantee only extends to the original purchaser of the unit.
NOTE: THE MANUFACTURER CAN NOT BE DEEMED RESPONSIBLE, FOR ANY DAMAGE OR INJUR Y CAUSED BY IMPROPER USE OF THIS
PRODUCT
SEA reserves the right to do changes or variations that may be necessary to its product s and/or to the present manual with no obligation to notice.
Correct Disposal Of This Product (Waste Electrical & Electronic Equipment) - Europe only
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To
prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle
it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they
can take this item for environmentally safe recycling.
Cod. 67410960
®
433.920 MHz FM TWO /
FOUR CHANNEL TRANSMITTERS
Cod. 23110550
12 Vdc (23A battery)
10 mA max (in transm.)
433.920 Mhz FM
300 m *
digital 4096 combinations
2/4
- 10°C / +60°C
-30°C / +80°C
70 x 42 x 14 mm
from 5% to 90% not condensing
WAREHOUSING TEMPERATURES
T
Max
+ 80°C
(2 CH)
(12 bit)
(Fig.1-2) . In case of bad functioning of the transmitter, before sending it back to the
Humidity
5% Not condensing
Rev. 01, 07/2009
Humidity
min
90% Not condensing
GB
Max
