Summary of Contents for TYVA PowerBox Moduloo Ex
- Page 1 PowerBox Portable power station Moduloo Ex range Quick start guide V1.0 - 20/09/2023...
-
Page 2: User Interface
User interface PowerBox Emergency stop button Solar input 120 - 500 VDC / 18 A ON / OFF button AC charge outlet 220 VAC / 16 A / 50 Hz Signal connector LED displays Battery state of charge Breaker box Power outlets 220 VAC / 16 A / 50 Hz / 3.5 kW max Ethernet connectors... -
Page 3: Electrical Specifications
Electrical specifications PowerBox Available energy /kWh 5 kW DC / AC single-phase converter Output power /VAC Frequency 16 A output Maximum continuous discharge power 50 A output Maximum continuous discharge power Recommended charge time /hours Power outlet Input power /VAC Maximum continuous charge power Maximum continuous charge current Solar recharge... -
Page 4: Package Content
220 VAC 16 A 32 or 63 A 220 VAC adapter Portable power station Quick start guide PowerBox Optional accessories Obtain additional accessories for your PowerBox by contacting TYVA Energie: Additional 220 VAC 32 A Communication Power beam Marechal adapter... - Page 5 Starting up Control before use Power up / down Make sure the emergency stop button is Press the ON / OFF button once. disarmed. 2. The indicator light on the button and both 2. Put every switches of the breaker box on the LED displays are blinking twice to indicate the position ON.
- Page 6 You can recharge the PowerBox with solar panels by connecting it to the plug provided for this purpose. To this end, you must get hold of the suitable solar Solar power cable power cable among TYVA Energie’ s optional accessories. 120-500 VDC 18 A 6/10...
- Page 7 Parallelization You have the possibility to parallelize up to 12 successive PowerBox in order to aquire autonomy or power. Please refer to the user manual to learn more and contact TYVA Energie to obtain the necessary additional accessories. Autonomy gain...
- Page 8 Download the app via Download the app via the Google Play Store the App Store By downloading the TYVA Smart Dashboard app, you accept the terms and conditions of TYVA Energie’ s Privacy policy. Learn more: https://tyva-energie.com/en/privacy-policy/ Interface The TYVA Smart Dashboard digital app allows you to supervise the global system of your portable power station made up of TYVA Energie’...
-
Page 9: Indicator Light
Charge mode disrupted by 1 flash Continuous light Discharge mode disrupted by 2 flashes Digital alerts Notifications can be seen in the « Alerts » tab of TYVA Smart Dashboard app: • Low Voltage • Under-temperature • PDU Lock •... - Page 10 Any question? Access to the Moduloo Ex range’s guides, user manuals and support Prior to this guide, you must imperatively refer to the safety instructions and the directives listed in the user manual of the PowerBox...
