Page 2
SUMMARY PRECAUTIONS AND SAFETY MESURES MODULES AND ACCESORIES TYVA MODULOO MODULOO HOUSING DETAILS PCB SETTING IN HOUSING VERSIONS OF LIDS ELECTRICAL SPECIFICATIONS OF VARIOUS PCB 2.4.1 PCB 4S/2P (12,8 to 14,8 V) ...
Page 3
Do not subject modules to shocks or falls Use a suitable battery charger (voltage and load current) Use only accessories and screws supplied with TYVA MODULOO modules For higher voltages up to 48 volts, use personal protective equipment, gloves, goggles and face shield, hearing protection.
Page 4
TYVA MODULOO MODULES AND ACCESSORIES Housing TYVA MODULOO Assembled positive cover Assembled negative cover T10 M3x14 screws Mounting tool Cells spacers Horizontal Busbar Vertical clip Protective cover - Busbar HO 1.0 - Busbar VE 1.0 - Maximum current : 140 A - Maximum current: 30 A Manuel UK 2.0...
Page 5
MODULOO CASES DETAILS Slots available for PCM ou BMS POSITIVE LID NEGATIVE LID Landmarks Manual UK 2.0...
Page 6
FIXING THE PCB IN THE HOUSING POSITIVE LID NEGATIVE LID Fixing holes Optional fixing holes for power PCB range Manual UK 2.0...
Page 7
VERSIONS OF LIDS Pins Negative lid Positive lid Negative hole Pins Positive lid Positive lid Positive lid Version 1S/8P Version 4S/2P Version 8S/1P (3,2 to 3,6 V ) (12,8 to 14,8 V ) (25,6 to 29,6 V ) Manual UK 2.0...
Page 8
-30 à +80°C * Its is possible to increase the discharge current by fixing the two positive and negative PCBs on the inner holes of TYVA MODULOO housing (see section 2.2). For high discharge rate, air cooling of the modules must be taken into account.
Page 9
2.4.1 PCB 4S/2P (12,8 to 14,8 V) Version 4S/2P (12,8 to 14,8 V Fuse SMD 20A Manual UK 2.0...
Page 10
2.4.2 PCB 8S/1P (25,6 to 29,6 V) Version 1S/8P (25,6 to 29,6 V Manual UK 2.0...
Page 11
INSTALLATION OF 18650 CELLS The 3 PCB openings from positive cover must be placed on the 3 pins housing Manual UK 2.0...
Page 12
18650 Li-ion CELLS 18650 cells size must have the same batch, voltage and identical chemistry The voltage difference between each cell must be less than 1.5 mV, it’s advised to measure the voltage of each cell before module integration 18.1 mm < 18650 cell diameter < 18.6 mm 64,9 mm <...
Page 13
POSITIONING THE HOUSING Position the positive cover on the positive side of the housing and then return the assembly on a flat surface. Manual UK 2.0...
Page 14
INSTALLATION OF 18650 CELLS Installation of 18650 cells into 8 housings on the negative side of the housing . Version 1S/8P Version 4S/2P Version 8S/1P (3,2 à 3,6 V ) (12,8 à 14,8 V ) (25,6 à 29,6 V ) Keying pins Manual UK 2.0...
Page 15
INSTALLATION OF SPACERS Insert 4 spacers with the included tool Manual UK 2.0...
Page 16
MOUNTING NEGATIVE COVER The 3 PCB openings from positive cover must be placed on the 3 pins of the housing Manual UK 2.0...
Page 17
Screwing the M3 screw on negative cover Setting the screwdriver with a maximum torque 3 Nm . Place into position the negative cover and tighten the screw in the order 1,2,3,4 while pressing down firmly on the cover. Manual UK 2.0...
Page 18
POSITIVE COVER MOUNTING Return the positive side module upwards taking care to maintain the unbound positive cover. The cells and spacers must always remain in place during this operation Then remove the positive cover Manual UK 2.0...
Page 19
POSITIVE COVER MOUNTING The 3 PCB openings from positive cover must be placed on the 3 pins of the housing Manual UK 2.0...
Page 20
SCREWING THE M3 SCREW ON POSITIVE COVER Placing into position the positive cover Tighten the screws in the 1,2,3,4 order Positive landmark Manual UK 2.0...
Page 21
MOUNTING COVER POSITIVE and NEGATIVE version 4S-2P and 8S-1P Insert the + connector of the negative PCB into the box housing After setting up the negative cover screws, release the connector Before securing the 4 screws on the PCB positive, connect the two connectors of the positive and negative cards Manual UK 2.0...
