  • Page 1 Caromax 1800 - Operating Instructions SERIAL NUMBER M...

  • Page 3: Table Of Contents

    Safety Warnings for Drills ....... 26 Additional safety warnings ..... 26 This instruction manual has been prepared with the 2.7.1 Operating personnel requirements ..26 greatest possible care. Nonetheless, MAXIMA S.p.A. 2.7.2 Workplace safety ........26 does not accept any liability whatsoever for 2.7.3 Electrical safety ........

  • Page 4: About This Instruction Manual

    CAROMAX 1800 About this instruction WARNING manual “WARNING” indicates an imminent hazard, which This instruction manual contains all important could result in death or severe physical injuries. information necessary for safe handling of the dry Î This arrow indicates appropriate measures to diamond drill.

  • Page 5: Electrical Safety

    CAROMAX 1800 d) Remove any adjusting key or wrench before Electrical safety turning the power tool on. A wrench or a key left attached to a rotating part a) Power tool plugs must match the outlet. of the power tool may result in personal injury.

  • Page 6: Service

    Wherever possible, use a dust extractor suitable for the material you are working on (e.g. a special MAXIMA dust extractor). f Ensure the workplace is properly ventilated. f We recommend wearing a face mask respirator with filter class P2 or P3 (to EN 149:2001).

  • Page 7: Electrical Safety

    Never use be used in conjunction with a suitable liquids. Never insert screwdrivers or any dust extractor (e.g. a special MAXIMA other objects into the ventilation slits. Do S.p.A. dust extractor). not cover the ventilation slits.

  • Page 8: Hazards When Using And Handling The Power Tool

    Disconnect the mains • Ensure that original MAXIMA spare parts and plug before changing the insert tool. original MAXIMA accessories only are used Use of the mounting tool provided prevents when needed.

  • Page 9: Explanation Of The Pictograms On The Machine

    CAROMAX 1800 2.7.7 Explanation of the pictograms on the machine The CE mark on a product means that the product conforms with all the applicable European regulations and has been subjected to the prescribed conformity assessment procedures. Protection class II equipment...

  • Page 10: Technical Characteristics

    CAROMAX 1800 Technical Characteristics Technical specifications Dry diamond drill type CAROMAX 1800 Manufacturer MAXIMA S.p.A. Operating voltage (V / Hz) ~230 / 50 / 60 Power consumption (watt) 1800 Protection class / II Speed (min 1650 Core drill bit diameter, hand-guided (mm) 32 –...

  • Page 11: Ec Declaration Of Conformity

    MAXIMA S.p.A. resettable centring drill bit Via Matteotti,6 - 42028 Poviglio (RE) 10 MAXIMA dry diamond core drill bit Ø 82 mm 11 Soft impact feature ON / OFF switch 12 Outside thread (M16) of the output shaft 13 Output shaft...

  • Page 12: Before Starting Work

    If harmful dust is produced during the work, a suitable dust extractor must be connected to Inserting a core drill bit shank without the dry diamond drill (e.g. MAXIMA special dust extraction dome extractor). Screw the core drill bit shank (4) with resettable centring drill bit (5) on the output shaft (1).

  • Page 13: Inserting The Dry Diamond Core Drill Bit On The Core Drill Bit Shank

    If dry diamond core drill bits with 1¼" connection are core drill bit shaft (4). Hold the output shaft (1) in used, the dust is extracted using the MAXIMA suction position with an open-ended spanner size 22 rotor (available as accessory, see MAXIMA catalogue...

  • Page 14: Drill Centring Hole

    Push the centring drill bit (1) with the Blunt dry diamond core drill bits can be knurled sleeve (3) towards the front (A) and lock resharpened if necessary using MAXIMA by turning anti-clockwise (B). whetstones or other suitable materials. •...

  • Page 15: Cleaning

    Only servicing and repair firms authorised by MAXIMA may carry out maintenance of the machine. ASPIRAZIONE 300 Tabella Tecnica Also ensure that original MAXIMA spare parts and original MAXIMA accessories only are used.

  • Page 16: Handling Dry Diamond Core Drill Bits

    MAXIMA suction rotor M18 to 1¼" against “soft” drill dust. The core bit segments • heat as a result, they become soft and the MAXIMA adapter for suction rotor M18 to 1¼" • diamond splinters sink into the substrate. The MAXIMA special dust extractor •...

  • Page 17: Warranty

    CAROMAX 1800 Warranty The power tools placed on the market and 4. Use of original MAXIMA spare parts distributed by MAXIMA S.p.A. Ensure that original MAXIMA spare parts and take into account the regulations of the laws MAXIMA concerning engineering tools and equipment to accessories only are used.
  • Page 18 CAROMAX 1800 | 3 |...
  • Page 19 CAROMAX 1800 Core drill bit shank without extraction dome Core drill bit shank with extraction dome | 4 |...
  • Page 20 CAROMAX 1800 Core drill bit shank without extraction dome Core drill bit shank with extraction dome | 5 |...
  • Page 21 CAROMAX 1800 Core drill bit shank without extraction dome Core drill bit shank with extraction dome | 6 |...
  • Page 22 CAROMAX 1800 POS. COD. DESCRIPTION CMAX65870 MOTOR SHAFT CMAX22475 SPHERE 4 DIN5401 CMAX66571 CYLINDRICAL SPINDLE 4X18 GEH CMAX65904 SECURITY RING JL 42 CMAX65920 SPACING RING J42 29X42X3 CMAX65912 NILOS RING 61905 JV 28X42X0,3 CMAX29744 BEARING 6905 LLU CMAX37705 RING OR 18X3,5...
  • Page 23 It is the customer's responsibility to ensure that, Foreword ............25 in the event that this document undergoes changes by MAXIMA SpA, only updated versions Purpose of the supplement to the use and of the Manual are actually present at the point of maintenance manual ..........25...
  • Page 24 CAROMAX 1800 Use of equipment ..........31 Controls ..............31 Commissioning ............31 Operating modes ............ 31 Maintenance ............31 Maintenance status ..........31 Electrical system functional checks ..... 31 Equipment insulation ..........31 Special precautions ..........31 Cleaning ..............31 Lubrication ...............
  • Page 25 Foreword The instructions, documentation and drawings contained in this supplement to the Manual are of a reserved technical nature and are the strict property of MAXIMA SpA. Purpose of the supplement Therefore, outside the purposes for which it was produced,...
  • Page 26 SpA is not responsible for translations that have not been The sequential number starts again from 1 with each new approved by MAXIMA SpA itself, so if an inconsistency is paragraph. detected, attention should be paid to the original language...
  • Page 27 Declaration COMPLIES WITH THE DIRECTIVES of Conformity, by the Company Maxima Spa, in the heading. Directive 2006/42/EC of the European Parliament and of the Council of 17 May 2006 on machinery, and amending Directive 95/16/EC.
  • Page 28 Maxima SpA has put a lot of effort into designing this conformity with the requirements of Directive 2006/42/EC equipment to make it as SAFE as possible, also as a result and the applicable EC Directives.
  • Page 29 The equipment is supplied without tools. These are described in the supplied Use and Maintenance Manual, a separately supplied product; it is the end user's the original Maxima coring tools are the reason for this responsibility to couple them correctly to the equipment supplement.
  • Page 30 Ø LASER requirements of Legislative Decree 81/08 et seq. GOLD SPIRAL core bit is supplied by Maxima for Noise emissions dry drilling in reinforced concrete. It is equipped with a spiral and the...
  • Page 31 CAROMAX 1800 Electromagnetic Environment The VACUUM 300 core bit is the tool in the range suitable machining For electromagnetic compatibility, see the Use and operations requiring Maintenance Manual. vacuuming dust. Vacuum 300 Core bit also mounts the same Use of equipment...
  • Page 32 Maxima S.p.A. The use of non-original spare parts is discouraged: if this occurs, Maxima SpA's Warranty conditions (if still valid) and liability for the use of the equipment and for any damage to persons and/or things as indicated in the Use and Maintenance Manual will be forfeited.
  • Page 36 CAROMAX 1800 Maxima SpA - Via Matteotti, 6 - 42028 Poviglio (Re) Italia Tel: 0039 0522 968011 - Fax: 0039 0522 967536 info@maxima-dia.com - www.maxima-dia.com...
