- Page 1 Model: Air Mask II User manual Bedienungsanleitung www.evolu.health Инструкция по применению USER MANUAL PORTABLE MESH NEBULIZER YES, YOU the best reason to take care of yourself...
-
Page 2: Table Of Contents
Content 1. Important Safety Notes ......... . . 3 2. -
Page 3: Important Safety Notes
Thank you very much for purchasing EVOLU Portable Mesh Nebulizer Nano AiR MINI •In order to make sure that this product can be used correctly, please read this manual carefully before use. •Please keep this manual in a convenient place for easy access. -
Page 4: Product Description
2. Product Description 2.1. Product Name: EVOLU Portable Mesh Nebulizer Nano AIR MINI. 2.2. Model: Air Mask II 2.3. Working Principle and Mechanism The working principle of the product is driven by the rapid oscillation of the circuit, making the piezoelectric ceramic transducer chip resonant oscillation,... - Page 5 The right vertical axis is the volume percentage of a certain section, correspond- ing to the histogram or undulating; 2.6. Product Composition Nebulizer nano AIR MINI is composed mainly by the main unit and medication cup, spray nozzle and micro USB cable. 2.7. Product Contents 1.
-
Page 6: Installation Instructions
3. Installation Instructions 3.1. Remove all packings, then remove the unit and accessories. 3.2. Install the assembled bottle on the main body. When you install it, you should hear the crisp clasp sound (as shown in the schematic diagram of the installation of the liquid bottle). -
Page 7: Use Instructions
b. When the low battery level is detected, the blue indicator flashes for 5 times and then turns off. c. Please use the power adapter (DC 5.0 V, 1 A) to charge the batteries for about 2 hours. d. The blue indicator flashes when charging and keeps lighting when full- charging. - Page 8 Green light keeps on (uniform nebuli- zation mode): Working Green light flashes (micro-wave mode): Long press for 3 seconds to switch Green light fleshes 3 times: the atomization mode Blue light flashes 5 times: Battery low, shut down Orange light flashes 10 times: Without medicine and shut down Blue light flashes: Charging...
- Page 9 4.4. Nebulization 1) Connect mask or mouthpiece, press power button to turn on, start nebulization. 2) It starts with a medium spray rate, and the spray rate can be adjusted by pressing & as needed. 3) This device has a Micro-wave mode in which the spray rate is changed automatically from max to mini rate or converse in 6 seconds.
-
Page 10: Cleaning And Disinfection Method
8) Use purified water to clean the medication cup, spray assembly, lid, thread assemblies and accessories, and then follow the recommended method of disinfection. Note: 1) Host nebulizer to keep the liquid and nebulization mesh disc in full con- tact. Slight swing does not affect the use but do not lean back the nebulization. 2) Receiving treatment according to the doctors’... -
Page 11: Storage And Maintenance
After each use, it is necessary to disinfect the components of the cup, spray nozzle, mask, mouthpiece, etc., as follows: 1) Disinfection with hydrogen peroxide: Disinfect all the components by placing them in 3% hydrogen peroxide for 10 minutes, including cup components (medication cup, lid), spray assembly, mask or mouthpiece, the main unit excluding. -
Page 12: Contraindications, Precautions, Notices And Warnings
and direct sunlight. 2) Storage instructions: a. The device is valid for 5 years in the above mentioned storage condition. b. The nebulizer should be promptly cleaned and disinfected after use, the medication cup and other accessories should store into the packing box after completely drying. - Page 13 •The equipment waterproof classification is IP22, main unit can’t be washed, and prevent the ingress of water. •Please refer to Chapter 8 (Trouble Shooting Tips) when there are problems or contact the distributor for maintenance. Do not attempt to repair the equipment personally.
-
Page 14: Trouble Shooting Tips
7.3. Warning •Please refer to the doctor before use the device if you have diabetes or other illnesses. •Using and purchasing the device should be advised by a doctor, please refer to the doctor’ s advisements regardign the medication type, dosing and way of use. •Please stop using the device if feeling uncomfortable and ask for a doctor for help. -
Page 15: Disposal
What medication 1) Please refer to and follow doctor’ s advise. is more suitable 2) Don’t use over sticky medication. for nebulization It is a normal sign, if there is some strange noises Some medication or the unit shut off due to insufficient medication, residual please stop nebulization. -
Page 16: Symbol Description & Electromagnetic Compatibility
11. Symbol description & Electromagnetic compatibility 11.1. Signs and symbols Refer to instruc- Separate collec- General tion manual/ tion for electrical ON/OFF Switch imperative booklet NOTE On and electronic ME EQUIPMENT equipment keep away from Waterproof Fragile Keep dry sunlight Grade Authorized Note, Warning... - Page 17 (for which CISPR 11 class B is normally required) 2. WARNING: The use of accessories and cables other than those specified, with the exception of cables sold by EVOLU as replacement parts for internal compo- nents, may result in increased emission or decreased immunity of the device.
- Page 18 Cables: Length (m): Whether to block: Note: USB Cable Guidance and Manufacturer’ s declaration – electromagnetic emissions This device is intended for use in the electromagnetic environment specified below. The customer or the user of the device should assure that it is used in such environment. Electromagnetic emission IEC 60601-1-2 Emissions text Compliance...
- Page 19 Power frequency magnetic Power frequency fields should be at levels (50/60 Hz) 30 A/m 30 A/m characteristic of a typical magnetic field location in a typical commer- IEC 61000-4-8 cial or hospital environment. Conducted RF 3V rms 3V/m Portable and mobile RF IEC 61000-4-6 150KHz to 80 MHZ communications equipment...
- Page 20 1) In order to regulate the requirements for EMC with the aim to prevent unsafe product situations, the EN 60601-1-2 standard has been implemented. The nebulizer Nano AIR MINI conforms to the EN 60601-1-2 standard for both immunity and emissions.
-
Page 21: Configuration List
Configuration list If Included Item Quantity Main unit Medication cup Adult mask Child mask Mouthpiece User Manual Warranty Card User Guidance Storage bag Micro USB Cable Warning badge Warning card... -
Page 22: Warranty Card
warranty card stamp Type of product: Serial No: Name of customer: Date of purchase: Contact number: Address: Sale company: Contact number: Address of sales company: warranty card stamp Type of product: Serial No: Name of customer: Date of purchase: Contact number: Address: Sale company: Contact number:... - Page 23 • The period of host free for maintain service is 2 years. Medication cup is 6 months. • During the warranty period, we will decide to repair or replace damaged parts or accessories according to the case. • The accessories (mask, mouthpiece) does not come in the warranty category since it is consumable item, details please refer to the manual.
-
Page 24: Manufacturer Information
EVOLU® is a registered Trade Mark of FORANS International AG, Switzerland FEELLIFE HEALTH INC. Room 1903, Building A, No.9 Furong Road, Tantou Community, Songgang Subdistrict, Bao’ an District, Shenzhen 518104 Guangdong, China. Tel.: 0086-755-6686 7080, e-mail: info@feellife.com Lotus NL B.V., Koningin Julianaplein 10, 1e Verd, 2595AA, The Hague, Netherlands.
