- Page 1 e-STREETZONE Notice d'utilisation User's manual...
- Page 3 Owner’s manual Lore...
-
Page 5: Table Of Contents
TABLE OF CONTENTS Stopping the vehicle and parking ......17 Traction battery............17 Information..............1 Removable battery............ 17 Introduction..............1 Battery charge level...........17 Safety advice..............1 Battery charger............18 Lithium-Ion batteries: Limit risks and be informed of a problem...........2 Battery charge............18 Environment / Recyclable..........2 Battery storage method..........19 Battery storage method..........3 Service operations............20... -
Page 7: Information
INFORMATION INTRODUCTION SAFETY ADVICE You have just bought a Peugeot vehicle. Your electric scooter is equipped with a permanent- A inexperienced motorcyclist should make himself magnet synchronous motor powered by a completely familiar with his vehicle before going out We would like to thank you for purchasing one of removable 48 volt Lithium-Ion traction battery that in traffic. You are strongly advised not to lend your our products. ... -
Page 8: Lithium-Ion Batteries: Limit Risks And Be Informed Of A Problem
LITHIUM-ION BATTERIES: LIMIT RISKS AND ENVIRONMENT / RECYCLABLE Any electrical appliance represents a BE INFORMED OF A PROBLEM potential danger. Only a suitably qualified Worn parts replaced during routine maintenance repairer can intervene on your electric • Have a smoke detector near your charging (mechanical parts, battery, etc.) must be disposed of scooter. ... -
Page 9: Battery Storage Method
Battery storage method Storage for less than one week: Park the vehicle on flat, stable ground in a dry, well- ventilated place. Charge the battery to between 20% and 80% of its capacity before storage to maximise its service life. Avoid direct exposure to the sun and rain to reduce the damage caused by the weather and ageing. ... -
Page 10: Characteristics
CHARACTERISTICS e-STREETZONE e-STREETZONE e-STREETZONE 25 km/h 45 km/h 45 km/h PRO Official type-approval code K4ABAA K4AAAA (Battery 1) K4AAAB (Battery 1) K4AABA (2 batteries) K4AABB (2 batteries) Dimensions in mm Weight in kg In working order (Without the battery) Authorised maximum. Total weight of the vehicle, the user, the passenger, the accessories and luggage. 230 (Battery 1) 189 (Battery 1) 243 (2 batteries) - Page 11 e-STREETZONE e-STREETZONE e-STREETZONE 25 km/h 45 km/h 45 km/h PRO Official type-approval code K4ABAA K4AAAA (Battery 1) K4AAAB (Battery 1) K4AABA (2 batteries) K4AABB (2 batteries) Performance 66 km (Eco Mode) (Boost Mode) (Boost Mode) Remaining range (at 25°C) 55 km (Battery 1) 50 km (Battery 1) 102 km (2 batteries) 102 km (2 batteries) Maximum speed 25 km/h 45 km/h Anti-pollution standard Euro5 Tyre dimensions Front 110/70 - 12 (53J) Minimum load index and speed rating Rear 110/70 - 12 (53J)
- Page 12 e-STREETZONE e-STREETZONE e-STREETZONE 25 km/h 45 km/h 45 km/h PRO Official type-approval code K4ABAA K4AAAA (Battery 1) K4AAAB (Battery 1) K4AABA (2 batteries) K4AABB (2 batteries) Electrical equipment/Direction indicators Instrument panel 2 inch screen Headlight 12V-35/35W (HS1) "Side light" bulb Rear light 12V-5W Brake light 12V-21W Intermitent signal 12V-10W Traction battery Removable lithium-ion battery 50.4 V 32 Ah (1.6 kW/h) 11kg Charging time 7 hours to reach 100% charge...
-
Page 13: Vehicle Identification
VEHICLE IDENTIFICATION IMPORTANT INFORMATION Products to use Brake fluid Brake fluid DOT 4 Performance Grease Multi-use grease If your vehicle is exposed to Fork oil 10W hydraulic oil temperatures below 0°C, the vehicle's range and battery life will be affected. We recommend that you park your vehicle in a location with a moderate temperature. ... -
Page 14: Information About The Instructions
INFORMATION ABOUT THE INSTRUCTIONS Toxic or fatal Specific information is indicated by the following The product can rapidly be fatal. symbols: It poisons rapidly, even at low doses. Wear protective equipment. Möbius band Avoid any contact (oral, skin, inhalation) Recyclable. with the product and wash all exposed Means that the product or the package can areas carefully after use. ... -
Page 15: Description Of The Vehicle
DESCRIPTION OF THE VEHICLE CONTROLS 1. 2 inch screen. 2. Brake levers. 3. Brake fluid level. 4. Throttle. 5. Ignition switch. 6. Utility hanger. 7. Manufacturer's plate / Fuses. 8. Traction battery. 9. Chassis markings. 10. Grab handle. 11. Central stand. 4. Emergency stop button / Starter switch. 12. ... -
Page 16: Key-Operated Ignition Switch Functions
KEY-OPERATED IGNITION SWITCH INSTRUMENTS 5 - "Bluetooth" connection. FUNCTIONS Depending on model / Availability. 6 - Battery 1 charge status. The bar chart indicates the battery charge level. When the last two segments flash, this means that the energy reserve has been reached. When the energy reserve is reached, the vehicle switches to ECO mode and the vehicle's speed is gradually... - Page 17 Milometer (ODO) / - Tripmeter (Trip) / Fault codes. A short press on the control button switches from one counter to another. Resetting the tripmeter Display the tripmeter and press for more than 3 seconds on the control button (A). Fault code display The fault codes displayed indicate either: •...
-
Page 18: Fault Codes
FAULT CODES Fault Description Cause Solution codes 0001 Engine The temperature values are close to If the ambient temperature is between 0°C and -15°C: Continue to drive. temperature / Engine the maximum/minimum limit: Error If not at ambient temperature: Stop driving or drive in Eco mode (Temperature controller temperature code generated and the vehicle is below -15°C), or wait for the vehicle to cool down (Temperature above 0°C). ... - Page 19 Fault Description Cause Solution codes 0011 Vehicle configuration error The engine controller is not compatible You are advised to have the vehicle checked by an authorised dealer. with the vehicle version 13/22...
-
Page 20: Equipments
EQUIPMENTS Accessory socket (USB) Central stand An accessories socket placed in the rear storage The central stand is fitted with a circuit breaker Storage compartment compartment and powered when the ignition is which prevents the motor from being started if the •... -
Page 21: Checks To Perform Before Use
CHECKS TO PERFORM BEFORE USE ADVICE FOR STARTING UP AND DRIVING If you cannot avoid driving through flood water: • Check that the water depth does not exceed 100 The user must personally ensure that his vehicle Warning mm, taking into account waves which could be is in good condition. Certain safety elements may Before using the vehicle for the first time, make generated by other road users. ... -
Page 22: Inspection Before Setting Off
IGNITION METHOD Inspection before setting off Driving Accelerating and decelerating Component Checks Before using the vehicle for the first time, charge the battery to 100%. Instrument • No faults. panel The emergency stop switch must be in Battery • Battery charge status. the ON position. ... -
Page 23: Stopping The Vehicle And Parking
Stopping the vehicle and parking will maximise its life and provide with the best Removal possible performance. • Turn off the ignition. • Place the vehicle on its central stand on flat If your vehicle is exposed to • Lift the saddle. ground. ... -
Page 24: Battery Charger
Battery charge Charging environment The charging area must be located in a well- ventilated dru place at a distance from any heat source. It must be equipped with a 230 V electrical socket, protected by a 16 A circuit-breaker, a ground connection and coupled with a 30 mA differential switch. ... -
Page 25: Battery Storage Method
The battery can be charged either in the Pass the cord through the opening in the The ignition must always be switched off vehicle or out of the vehicle. seal at the rear of the compartment before before removing the battery from the closing the saddle. Do not pull on the power vehicle. ... -
Page 26: Service Operations
SERVICE OPERATIONS If the wear limit on the tread is reached ((A)), you are Do not use high pressure cleaners advised to go to a registered dealer to change the which may cause water to infiltrate Maintenance advice tyres. the following parts: seals, bearings and hinges, electrical components such as Ensure the servicing schedule for your vehicle connectors, contactors and lighting. ... -
Page 27: Brake Fluid
touches the brake disk, have the pair of brake pads Brake fluid Fuses replaced by an approved distributor. The brake fluid levels must be checked regularly The electrical installation is protected by the fuses, through the braking unit inspection window . which are accessible after removing the floor hatch. ... -
Page 28: Fuse Allocation
BULB REPLACEMENT HEADLIGHT ADJUSTMENT Fuse allocation The headlight is adjusted using a screw which can be Headlight bulb / Indicator bulbs F1 15A Battery positive power accessed from the rear shield panel. • Remove the side trims (1). F2 5A Engine • Remove the front fairing (2). F3 5A Instrument panel F4 5A... - Page 29 Peugeot Motocycles recommends Peugeot Motocycles SA Rue du 17 Novembre F-25350 Mandeure Tél. +33(0)3 81 36 80 00 Fax +33(0)3 81 36 80 80 RCS Belfort B 875 550 667 www.peugeot-motocycles.fr www.peugeot-motocycles.com ISO 9001 (Édition 2015) / N°SQ/1956 0 800 007 216 Dans un souci constant d’amélioration Peugeot Motocycles se réserve le droit de supprimer, modifier ou ajouter toutes références citées.
- Page 30 11.402248.00 07/23.v1 Guide d’utilisation en ligne Online user’s guide Crédits photo : Photographe Benjamin Dauchez...
