Page 1
A S S E M B L Y M A N U A L T H E E R G A T T A I T E...
Page 2
Pow r Button Touchscr n Handl R st Handle R ar Spac r (Attach d to Handl B lt) S at (With Bung attach d) Forward Ris r Footpads Top & Bottom D ck Rails Footboard Tank...
Page 4
Lay the rails on the floor parallel to one another. Make sure that the black extrusions are facing the inside of the rails.
Page 5
Unscrew the four JCN Nuts from the rear spacer, then align the rear spacer with the holes on the rails such that the Ergatta logo is facing upwards and the bungee cord is facing towards the front of the rails. Fasten the rear spacer to the rails using the four JCN Nuts and 5mm Allen Key without fully tightening at this time.
Page 6
Place the seat between the rails. The indent on the seat should face the rear spacer. All four load wheels should sit on the black extrusion, with the guide wheels locked under the black extrusion such that the seat cannot be lifted off the rails. Note: It may be necessary to separate the rails slightly to fit.
Page 7
Place the tank assembly onto the rails, then using the JCB Bolts and 5mm Allen Key, attach the tank to the rails. At this stage they should not be fully tightened. JCB Bolt (x4) Allen Key...
Page 8
Raise the mounting arm until the legs fully extend from under the arm, then release the arm to lock into place...
Page 9
Loosen the 2 bolts on the top deck using the 4mm Allen key. Assemble the footboard between the rails to lean against the top deck. Fasten the footboard to the rails using the JCB bolts and 5mm Allen key. JCB Bolt (x4) Allen Key...
Page 10
Using the handle rest bolts and the 5mm Allen key, secure the handle rests in place with the the handle notch facing downwards. Handle Rest Bolt (x2) Handle Rests (x2) Allen Key...
Page 11
Place the provided Footboard Assembly Card on the opposite side of the straps, pushing it all the way through the slot for the Footpads. Using the Assembly Card as a ramp, install the Footpads onto the Footboard. Footpads (x2)
Page 12
Assemble the dolly wheel and washers onto the provided bolt in the order shown below, the using the 5mm Allen key fasten the dolly wheel assembly onto the rails. Wheel Assembly (x2) Allen Key...
Page 13
Using the 5mm Allen key, fully tighten the nuts and bolts connecting the tank, footboard and rear spacer to the rails. Then, using the 4mm Allen key to fully tighten the top deck JCB’s. Place the 5mm Allen Key back under the rear spacer for easy access later. Do NOT use power tools to tighten the bolts, as this may lead to them becoming stripped.
Page 14
Lower the tablet arm and stand the machine upright. Release the recoil belt and connect the bungee to the recoil strap. Note: the recoil belt should go under the pulley (center diagram)
Page 16
Before placing the touchscreen onto the rower, connect to USB cable to the touchscreen and mount as shown below. Back of Touchscreen USB Cable (USB-A End) USB Cable (Micro-USB End)
Page 17
Slide the touchscreen onto the end of the mounting arm until it locks into place (the speakers should be on the top). Using the touchscreen bolt and 1/8" Allen key, secure the touchscreen to the arm. Touchscreen Bolt Allen Key...
Page 18
Before placing the touchscreen onto the rower, connect to USB cable to the touchscreen and mount as shown below. Back of Touchscreen USB Cable (USB-A End) Power Cable Sensor USB Cable Cable (Micro-USB End) To Wall To Mounting Outlet...
Page 19
If you require additional assistance with assembly or with any other troubleshooting, please contact us. For orders outside the US, please use the above QR code for relevant contact info. 718-866-4935 Phone: supp rt@ergatta.c m Email: supp rt.ergatta.c m Web:...
