- Page 1 Operator’s Product HandBook PantherPatrol ™ Fire Fighting Trailer “HELPING TO DEVELOP AND PROTECT THE LAND”...
-
Page 2: Table Of Contents
Description Machine Limitations Driving Stability Operating Instructions Before First Use Pump Operation – Petrol Engine Pump Operation – Diesel Engine Option Filling the Tank PantherPatrol Operation Risk Assessment Maintenance Periodic Checks Maintenance Schedule Trouble Shooting Warranty Warranty Policy What this Warranty Does Not Cover? - Page 3 The PantherPatrol is a trailer-mounted tank water dispensing system designed for firefighting, tree watering and similar manually conducted watering activities. With the optional single or dual deflector system fitted, the PantherPatrol can be used for dust suppression on unmade roads, construction sites, etc.
-
Page 4: Safety
PantherPatrol ™ PRODUCT HANDBOOK Safety This manual is intended for use by personnel experienced in the use of this and similar equipment. Read and understand this manual before attempting to operate or perform routine maintenance on this equipment. Your safety is of prime priority. -
Page 5: General Safety Instructions
7. Disconnect the battery, if fitted, before conducting any electrical maintenance work. 8. Ensure the capacity of the vehicle is suitable for the loaded mass of the PantherPatrol. Refer to the vehicle’s operator manual for safe working loads and relevant safety instructions. Do not exceed the carrying and braking capacity as specified by the vehicle manufacturer. -
Page 6: General Information
PantherPatrol ™ PRODUCT HANDBOOK General Information Specifications Tank UV resistant polyethylene tank (1,100 litre capacity), integrated 10 litre handwash tank with tap and 70 litre flush tank Trailer Fully welded and galvanised heavy duty steel frame, single axle with 15”... -
Page 7: Description
The factory-set regulator feeds excess water back to the tank and is set to relieve at 50 – 60 psi. Hose Reel Each PantherPatrol is fitted with a 36m 19mm diameter fire hose mounted on a manually operated hose reel. The hose is fitted with an adjustable nozzle which locates in a securing bracket on the hose reel support when the hose is stowed. - Page 8 Quick Fill Hose Kit Each PantherPatrol is fitted with a front-mounted hose bracket, housing the 6m quick fill hose. The hose is fitted with a filter at one end and a camlock coupling on the opposite end, for direct connection to the pump.
-
Page 9: Machine Limitations
PantherPatrol ™ PRODUCT HANDBOOK control box mounted at the rear of the PantherPatrol. This should only be used where power is not available via the Anderson plug from the tow vehicle. Remote Control Unit An optional remote control unit enables the operator to start the optional dual water deflector spray system while in the tow vehicle’s cab. - Page 10 Connect the 7-pin trailer plug to the tow vehicle, ensuring it locks firmly, refer to Figure 2. Check lights and indicators operate correctly. • If fitted, connect the PantherPatrol’s Anderson plug socket to the tow vehicle for power supply to the optional solenoid operated ball valve, refer to Figure 2. Figure 2 – Anderson Plug and 7-Pin Plug CAUTION! The engine must be inspected and prepared in accordance with the manufacturer.
-
Page 11: Pump Operation - Petrol Engine
When the engine needs to be stopped, turn the power (manual start) or key switch (electric start) to the OFF position. For the remote control option, press the No. 2 button. If the PantherPatrol is not going to be used within the next few hours, shut the system down by turning the fuel tap to OFF. -
Page 12: Pump Operation - Diesel Engine Option
Turn the key switch to the OFF position. For the remote control option, press the No. 1 button to turn the ignition OFF. If the PantherPatrol is not going to be used within the next few hours, shut the system down by turning the fuel tap to OFF. - Page 13 Release the camlock fittings and disconnect the suction line from the pump, then connect it to the pump’s discharge manifold port above. • A bottom fill supply hose is located on its bracket at the front of the PantherPatrol’s trailer. Remove it from the bracket and attach the camlock end to the pump’s suction port. •...
-
Page 14: Pantherpatrol Operation
Fire Hose Use With the PantherPatrol unit operating as described above, the fire hose is used as follows, refer to Figure 5: • Unlock the hose reel and release the hose’s nozzle from its retaining bracket. Pull out the length of fire hose required. - Page 15 POWERED position at the three-way switch. If fitted with the optional solenoid actuated valve, move the three-way switch at the rear of the PantherPatrol from OFF to the POWERED position, refer to Figure 6. This will draw power from the tow vehicle via the Anderson plug.
- Page 16 Figure 7. Lock the spray head back into place, ensuring the camlock levers are fully home. • Start the PantherPatrol’s pump system as described above. • For manual operation of the deflector spray head, open the ball valve. Water will spray from the deflector.
- Page 17 Figure 7. Lock the spray head back into place, ensuring the camlock levers are fully home. • Start the PantherPatrol’s pump system as described above. • At each deflector spray head, open the ball valve. Water will spray from the deflector.
-
Page 18: Risk Assessment
PantherPatrol ™ PRODUCT HANDBOOK Risk Assessment Task Hazard Risk Control Measure/Mitigation Partially fill the tank Manual handling; slips, Medium Concentrate on task; follow safe manual handling techniques: with water, start trips or falls; petrol; • Don’t lift on your own if > 20kg, the motor &... -
Page 19: Maintenance
• If the PantherPatrol is to be stored for an extended period, ensure the tank and all pipelines are empty and are not pressurised. Store the unit is a clean, dry and well-ventilated area. - Page 20 PantherPatrol ™ PRODUCT HANDBOOK Daily Tasks The following tasks are to be undertaken daily, or prior to each use, of the PantherPatrol unit. Task Notes Inspect the PantherPatrol for any signs of damage or wear Clean, repair or replace Check plug connections and test lights/indicators...
- Page 21 PantherPatrol ™ PRODUCT HANDBOOK Three Monthly Tasks The following tasks are to be undertaken every three months or 50 operating hours, whichever occurs first. Task Date Signed All Daily, Weekly and Monthly tasks * Re-tension axle U-bolts (first time, thereafter every six...
-
Page 22: Trouble Shooting
PantherPatrol ™ PRODUCT HANDBOOK Two-Yearly tasks The following tasks are to be undertaken every 24 months or 500 operating hours, whichever occurs first. Task Date Signed All Daily, Weekly, Monthly, 3-Monthly, 6-Monthly and 12-Monthly tasks Disassembly, clean and repack wheel bearings... -
Page 23: Warranty
PantherPatrol ™ PRODUCT HANDBOOK Warranty Warranty Policy TTI will, at its option, repair or replace without charge any part covered by this warranty which is found to be defective in material and/or workmanship within one (1) year after date of sale to the original retail purchaser. - Page 24 1800 816 277 sales@tti.com.au PO Box 137, Nathalia, VIC, 3638 Murray Valley Hwy, Nathalia, VIC 3638 Proudly Built By: Quality Checked By: Signature Date Signature Date www.tti.com.au...
