Installation instructions
Filling pump
EN
Dear customer,
We thank you for your confidence demonstrated by the purchase of this MELAG product. As an owner-run and operated
family concern founded in 1951, we have a long history of successful specialization in hygiene products for practice-
based use. Our focus on innovation, quality and the highest standards of operational reliability has established MELAG
as the world's leading manufacturer in the instrument reprocessing and hygiene field.
You, our customer are justified in your demand for the best products, quality and reliability. Providing
hygiene"
and
"Quality – made in
management system is subject to close monitoring: one instrument to this end is our annual multi-day audit conducted in
accordance with EN ISO 13485. This guarantees that all MELAG products are manufactured and tested in accordance
with strict quality criteria.
The MELAG management and team.
This device is to be maintained exclusively by a qualified service technician trained by MELAG and working in
accordance with the valid directives.
Germany", we guarantee that these demands will be met. Our certified quality
"competence in

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ME65010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MELAG ME65010

  • Page 1 Filling pump Dear customer, We thank you for your confidence demonstrated by the purchase of this MELAG product. As an owner-run and operated family concern founded in 1951, we have a long history of successful specialization in hygiene products for practice- based use.
  • Page 3: Table Of Contents

    Contents Contents 1 General guidelines ................................ 4 Symbols used .................................. 4 Disposal .................................... 4 2 Safety..................................... 5 3 Description of the device.............................. 6 Intended use .................................. 6 Scope of delivery ................................. 6 View of filling pump................................ 6 4 Assembly .................................... 7 Vacuclave 550 .................................. 7 Careclave 618.................................. 10 5 Electrical test in accordance with EN 50678 (VDE 0701) or national standard ............ 13 6 Maintenance.................................. 14 7 Technical data .................................. 15 8 Spare parts.................................. 16...
  • Page 4: General Guidelines

    Please store this user manual carefully and in close proximity to your device. It represents a component of the product. Should the manual no longer be legible, is damaged or has been lost, you can download a new copy from MELAG download centre at www.melag.com.
  • Page 5: Safety

    2 Safety 2 Safety When operating the device, comply with the following safety instructions as well as those contained in sub- sequent chapters. Use the unit only for the purpose specified in these instructions. Also observe the safety instructions in the user manual of your steam sterilizer. Failure to comply with the safety instructions can result in injury and/or damage to the unit.
  • Page 6: Description Of The Device

    3 Description of the device Intended use The filling pump (art. no. ME65010) is intended for the semi-automatic filling of the feed water tank of the steam sterilizer with feed water. The feed water tank can be filled from any feed water supply storage container using the suction hose.
  • Page 7: Assembly

    4 Assembly 4 Assembly Vacuclave 550 Mains cable connection (safety clip) Overflow funnel Rear device cover (left) Electrical connection of filling pump (cover plug) Feed water connection of the filling pump Mounting holes of the filling pump Feed water connection, water treatment unit The following must be fulfilled or present: ü...
  • Page 8 4 Assembly Make the electrical connections inside the unit (2 connectors). Insert the wellnuts (Pos. 4) into the mounting holes of the rear device cover (Pos. 11), and tighten the screws. Mount the rear device cover (Pos. 8) with the 6 screws (TX20). Remove the screw plug with Cu seal from the feed water connection of the filling pump (Pos.
  • Page 9 4 Assembly Align the connection hose (Pos. 3) according to the illustration. Tighten the connection screw (Pos. 13) with two open-end spanners. NOTICE! Ensure that the feed water connection of the filling pump does not move by holding it in the opposite direction.
  • Page 10: Careclave 618

    4 Assembly Careclave 618 Feed water connection of the filling pump Opening for electrical connection, filling pump Mounting holes of the filling pump Feed water connection, water treatment unit The following must be fulfilled or present: ü 2x open-end spanner (AF17) ü...
  • Page 11 4 Assembly Insert the connection socket of the wiring harness of the filling pump from the inside through the cut-out (Pos. 7). PLEASE NOTE: The detent at the opening of the connection socket determines the alignment. Hand-tighten the ring nut of the wiring harness. Make the electrical connections inside the unit (2 connectors).
  • Page 12 4 Assembly Align the connection hose (Pos. 3) according to the illustration. Tighten the connection screw (Pos. 10) of the filling pump with two open-end spanners. NOTICE! Ensure that the feed water connection of the filling pump does not move by holding it in the opposite direction.
  • Page 13: Electrical Test In Accordance With En 50678 (Vde 0701) Or National Standard

    5 Electrical test in accordance with EN 50678 (VDE 0701) or national standard 5 Electrical test in accordance with EN 50678 (VDE 0701) or national standard After closing the unit, perform an electrical test according to EN 50678 (VDE 0701). Comply with the applicable national specifications.
  • Page 14: Maintenance

    The maintenance work described below can be performed by the user as part of in-house maintenance. All maintenance activities beyond this may only be carried out by an authorised technician. Comply with the following for safe handling: Maintain the specified maintenance intervals. Only original MELAG spare parts may be used. Interval Measure Unit component...
  • Page 15: Technical Data

    7 Technical data 7 Technical data Supply voltage DC 16 V ( ±1) Volume flow 1 l/min Maximum suction lift 1.2 m Maximum installation altitude 3000 m Minimum feed water temperature 5 °C Maximum feed water temperature 40 °C Weight, including suction hose approx.
  • Page 16: Spare Parts

    8 Spare parts 8 Spare parts All specified articles are available through specialist dealers. Article Art. no. Silicone hose 12/6 mm, 2 m ME51450 Hose clamp, 12/8 mm ME35480 Filter with sieve insert ME34010 10x Cu seal 1/2” for internal thread ME36060...
  • Page 18 MELAG Medizintechnik GmbH & Co. KG Geneststraße 6-10 10829 Berlin Germany Email: info@melag.com Web: www.melag.com Original instructions Responsible for content: MELAG Medizintechnik GmbH & Co. KG We reserve the right to technical alterations Your stockist...
