  • Page 2: Table Of Contents

    6. Rack Mounting Instruction..............4 6.1 6U Rack Mounting................4 6.2 1U Rack Mounting................6 7. Web GUI User Guide................7 7.1 Preparation before Entering the System........7 7.2 Functions and Operation..............11 8. Application Example................23 Copyright Smart-e (UK) Ltd e&oe...

  • Page 3: Introduction

    ④ 1 ⅹ 6-pin 3.81mm Phoenix Connector (Male) ⑤ 2 ⅹ Mounting Ears ⑥ 4 ⅹ Machine Screws (KM3*6) ⑦ 1 ⅹ 12V/1A Locking Power Adaptor ⑧ 1 ⅹ User Manual VHX-7000-H Controller User Manual V1.0 Page 1 / 24 © 2023 Smart-e (UK) Ltd...

  • Page 4: Specifications

    -20°C ~ 60°C / -4°F ~ 140°F Temperature Relative Humidity 20~90% RH (non-condensing) 5. Operation Controls and Functions 5.1 Front Panel POWE R STATUS RE S E T VHX-7000-H Controller User Manual V1.0 Page 2 / 24 © 2023 Smart-e (UK) Ltd...

  • Page 5: Rear Panel

    Switch to left: 5V I/O level output, VOUT DIP Switch is 5V. Switch to right: 12V I/O level output, VOUT is 12V. 12V IR signal input port. IR IN VHX-7000-H Controller User Manual V1.0 Page 3 / 24 © 2023 Smart-e (UK) Ltd...

  • Page 6: Ir Pin Definition

    6U rack sale). The mounting steps are as follows: Step 1: Use included screws to fix two mounting ears on the Controller, as shown in the figure below: VHX-7000-H Controller User Manual V1.0 Page 4 / 24...
  • Page 7 10 units can be installed vertically), as shown in the figure below: Step 3: Use screws to fix mounting ears on the rack to complete the mounting, as shown in the figure below: VHX-7000-H Controller User Manual V1.0 Page 5 / 24...

  • Page 8: Rack Mounting

    Step 3: Fasten screws between two 1U rack panels, so that four Controllers are mounted in a 1U rack, as shown in the figure below: VHX-7000-H Controller User Manual V1.0 Page 6 / 24 © 2023 Smart-e (UK) Ltd...

  • Page 9: Web Gui User Guide

    Then, click “Log In” to enter the Web GUI interface. For the first time, you need to setup the project, as shown in the following figure: VHX-7000-H Controller User Manual V1.0 Page 7 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 10 H DM I I N H DM I O UT AU DI O O UT R S-2 3 2 I R I N IR O UT Video Wall VHX-7000-H Controller User Manual V1.0 Page 8 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 11 If you select “List all discovered Encoders and Decoders”, and click ▪ the “Scan” button to enter the Project page. All the connected devices will be listed in the Unassigned Devices list. VHX-7000-H Controller User Manual V1.0 Page 9 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 12 Encoder or Decoder to add the device to the project one by one. Encoders and Decoders that have been added to the project will appear in the Current Devices list, as shown in the figure below. VHX-7000-H Controller User Manual V1.0 Page 10 / 24...

  • Page 13: Functions And Operation

    ② Decoders: Display all the current Decoders. The text on the first line is the name of the Decoder, and the text on the second line refers to the Encoder where the signal resource is from. VHX-7000-H Controller User Manual V1.0 Page 11 / 24...
  • Page 14 Click “Start Scan & Auto Assign” to search devices that do not appear in the current project; Click again to stop searching. VHX-7000-H Controller User Manual V1.0 Page 12 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 15 Click the drop-down list of Audio Selection to set the current Encoder’s audio output. Click the icon on the left of ID to check the detail information about the current Encoder, as shown on next page: VHX-7000-H Controller User Manual V1.0 Page 13 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 16 Replace (Must be off11ne) Remove from Project Remove from ProJeCt Factory Default Reset Factory Default Reset On this page, you can setup the current Encoder as r equired. VHX-7000-H Controller User Manual V1.0 Page 14 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 17 Click the drop-down list of Function to select the current Decoder‘s mode. Click the icon on the left of ID to check the detail information about the current Decoder, as shown on next page: VHX-7000-H Controller User Manual V1.0 Page 15 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 18 §I If', Replace (Must be offiine) Remove from Project Remove from ProJect *fl' iiii•iii Focto<YOof'"ltRmt On this page, you can setup the current Decoder as required. VHX-7000-H Controller User Manual V1.0 Page 16 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 19 On this page, you can create and configure video wall as required. Please follow below steps to create a video wall. Step 1: Click “Create”, a pop-up window will be shown as below: VHX-7000-H Controller User Manual V1.0 Page 17 / 24...
  • Page 20 Wall List”, then click “Assign Decoder” to enter the Decoder assignment page. Click each screen to select the corresponding Decoder device, then click “Apply”. Note: A Decoder can only be assigned to one video wall. VHX-7000-H Controller User Manual V1.0 Page 18 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 21 Note: Up to eight configurations can be set up for different application scenarios. Step 4: After configuration, you can switch to “Video Wall Control” page for video preview, as shown in below. VHX-7000-H Controller User Manual V1.0 Page 19 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 22 1x2 up to 9x9. (2) The controller creates and manages the video wall configurations and provides a simplified control interface and API commands to third party control system. VHX-7000-H Controller User Manual V1.0 Page 20 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 23 Switch. ③ Video Network:The network port configuration of the Controller connected to video source devices. You can update the settings or reset the Controller. VHX-7000-H Controller User Manual V1.0 Page 21 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 24 Web browser home page or the Web GUI login interface automatically. You need to log in the Web GUI again with the new password. VHX-7000-H Controller User Manual V1.0 Page 22 / 24 © 2023 Smart-e (UK) Ltd...

  • Page 25: Application Example

    H DM I I N H DM I O UT AU DI O O UT R S-2 3 2 I R I N IR O UT Video Wall VHX-7000-H Controller User Manual V1.0 Page 23 / 24 © 2023 Smart-e (UK) Ltd...
  • Page 26 Box, as they are managed by Controller automatically (Default). (5) When the Network Switch does not support POE, the Encoder, Decoder and Controller Box should be powered by DC power adapter. VHX-7000-H Controller User Manual V1.0 Page 24 / 24 © 2023 Smart-e (UK) Ltd...
