Summary of Contents for UNV OFG5312
- Page 1 OFG5312 Installation Guide V1.0.0 Internal Use Only OFG5312 Installation Guide V1.0.0 Zhejiang Uniview Technologies Co., Ltd.
- Page 2 OFG5312 Installation Guide V1.0.0 Internal Use Only Revision History Date Manual Version Description Author 2023/07/31 V1.0.0 Initial release W3317...
-
Page 3: Table Of Contents
OFG5312 Installation Guide V1.0.0 Internal Use Only Contents 1 Overview · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2 2 Site Survey ·... - Page 4 OFG5312 Installation Guide V1.0.0 Internal Use Only NOTE! This manual mainly introduces the design and installation of face turnstile. It is intended for Uniview’s checkpoint installation and maintenance engineers, and implementation and maintenance staff of integrators and contractors. It is strongly recommended to read through this guide before starting site design and...
-
Page 5: Overview
OFG5312 Installation Guide V1.0.0 Internal Use Only Overview Figure 1-1 OFG5312 Tripod Turnstile... -
Page 6: Site Survey
OFG5312 Installation Guide V1.0.0 Internal Use Only Site Survey Before the site survey, you need to have a comprehensive understanding of the project, including background, scale, quality objectives, cycle, bidding documents, contracts, design plans, and drawings. Then you can conduct a survey on site based on the above information, and combine the survey results with the customer’s needs to decide the exact installation location of the device. -
Page 7: Safety Instructions
OFG5312 Installation Guide V1.0.0 Internal Use Only length/type and the number/type of devices required, estimate the number of technicians required, and produce a site survey report. Safety Instructions Ensure that the device is placed or installed firmly and reliably. Ensure that the device is installed properly before you connect it to power, otherwise it may cause personal injury and device failure. -
Page 8: Installation Environment
OFG5312 Installation Guide V1.0.0 Internal Use Only Marker Used to mark mounting holes. Tape measure Used to measure dimensions. Electric hammer drill (14mm drill bit is recommended) Used to drill holes. Hammer Used to hammer expansion screws into the ground. -
Page 9: Renovation Installation
OFG5312 Installation Guide V1.0.0 Internal Use Only 1. Install Power Cables Install power cables at the appropriate location according to the design layout of the device. See the table below for power cable specifications. Table 4-3 Power Cable Requirements Number of Lanes Power Cable Requirements ≤... -
Page 10: Installation
OFG5312 Installation Guide V1.0.0 Internal Use Only An extender or a fiber optic cable is required if the network communication distance exceeds 80m. Prepare RVV2*1.0 cables (1 for each lane) on the main controller, and connect the cables to the nearest security booth, monitoring room or management center through the pre-buried cable conduits to realize the control of a lane by the corresponding lane switch. -
Page 11: Ofg5312 Arm Bar Installation
OFG5312 Installation Guide V1.0.0 Internal Use Only 3. Move the pedestal, and drill holes at the marked points. Figure 5-3 Drill Holes 4. Align the mounting holes at the bottom of the pedestal with the expansion bolts on the ground, and then tighten the bolts to secure the pedestal. -
Page 12: Ofg5312 System Wiring
OFG5312 Installation Guide V1.0.0 Internal Use Only Figure 5-5 Install Arm Bars OFG5312 System Wiring 5.3.1 System Wiring Connect the AC220V mains supply to the air circuit breakers in the right and middle pedestals. Connect the L (live wire) and N (neutral wire) wires to the air circuit breaker and connect the PE wire (yellow and green wire) to a grounding terminal (as in figure 5-6 below). -
Page 13: Control Board Wiring
OFG5312 Installation Guide V1.0.0 Internal Use Only 5.3.2 Control Board Wiring 1. The device has no interconnection cables, while the rest of the mainboard cables are already connected at factory. 2. The IN and OUT terminals separately control the gate opening in the IN direction and OUT direction. -
Page 14: Face Recognition Terminal Wiring
OFG5312 Installation Guide V1.0.0 Internal Use Only Figure 5-9 Remote Control Wiring 5.3.4 Face Recognition Terminal Wiring Figure 5-10 Face Recognition Terminal Wiring Parameters Settings Parameter Value Function Function Description Default Type Range Set the passing time. If a person passes through the gate Passing within the set time, the time will be automatically reset;... - Page 15 OFG5312 Installation Guide V1.0.0 Internal Use Only It is generally used for gate control by card authentication. Choose to allow or forbid the gate control system to remember the card swiping information of the previous person when other person is entering or exiting the gate. 0:...
