BetterAir BioLogic mini Quick Start Manual

BioLogic mini–first use and refill guide.
The Only technology for total protection of the entire indoor space
1 2 3
Place device Hold the base
and refill on a and the cap counterclockwise
surface
6 7 8
Turn the device Keep unit and bottle Flip device as shown,
vertical while screw the
over the bottle
bottle into base
counterclockwise
4 5
unscrew the empty bottle.
Turn the cap Flip the device on
Carefully unscrew the
the new bottle
refill bottle-cap
9 10
Close the cap Device is ready.
reattach cap clockwise Follow instructions
on your right
The device operates as an electronic fogger where a fast cleaning of
contaminated areas is desired. Fog the area for about 30 seconds by
pointing the device vertically to the floor in all directions of your
room/vehicle/office.
24 X 7 continuous, automatic protection of your space.
The device should momentarily disperse only once an hour for a few seconds
Using Mode 2 alone - the refill should last about 11-12 weeks.
Continued long press the power button for about 3 seconds.
The LED color should turn blank.
Green - device disperses
Blue - Idle between dispersion
Red - Recharge device - connect to the device the supplied C-type cable
to a certified USB charger (not supplied)
Blue & Red - The device is properly recharging.
When LED is Green, but the device does not disperse,
the refill's tank is empty. REPLACE REFILL
www.better-air.com
