Joranalogue TEST 3 Build Instructions

INTRODUCTION

Test 3 is a purpose-designed tool for measuring
voltages and currents in your Eurorack system.
This means that just a single circuit board or
module can now replace a convoluted test setup
with multiple multimeters, custom cables etc.
Two push buttons allow you to cycle the value
shown on the LED display between three
measurements (voltage, current and stored peak
current) of the three power rails. The peak
currents continually update in the background
on all rails, making it ideal for quickly getting
maximum current figures.
Apart from measuring the current draw of a
single module, Test 3 also supports testing power
supplies and cables, measuring an entire system
(up to 1 A of current on each rail), troubleshooting
DIY modules, powering a skiff or breadboard
from a larger system...
BUILD INSTRUCTIONS
Test 3 is available as a Do-It-Yourself ('DIY') Kit
with an optional Front Panel Kit.
For detailed build instructions, scan the QR code
below with your mobile device or visit this URL:
https://joranalogue.com/test3/build
The Build Instructions document also lists the
package contents for both the DIY Kit and Front
Panel Kit.
