Page 1: Table Of Contents
Instructions for use WASHING MACHINE Contents Installation, 2-3-4-5 Unpacking and levelling Connecting the electricity and water supplies English,1 The first wash cycle Technical data Description of the washing machine and starting a wash cycle, 6-7 Control panel Indicator lights Starting a wash cycle Wash cycles, 8 Table of wash cycles Personalisation, 9...
Page 2: Unpacking And Levelling
Installation 2. If the floor is not perfectly level, compensate for any Keep this instruction manual in a safe place for future unevenness by tightening or loosening the adjustable front reference. Should the appliance be sold, transferred or feet (see figure); the angle of inclination, measured accor- moved, make sure the instruction manual accompanies ding to the worktop, must not exceed 2°.
Page 3 Connecting the drain hose • the supply voltage is included within the values indica- ted on the Technical Data Plate fixed on the machine. Connect the drain hose, without bending it, to a • the socket is compatible with the washing machine’s draining duct or a wall drain plug.
Page 4: The First Wash Cycle
The first wash cycle As the colours of the wires in the lead may not correspond with the coloured markings identifying the terminals in your Once the appliance has been installed, and before you use plug, proceed as follows: it for the first time, run a wash cycle with detergent and no Connect Green &...
Page 5: Technical Data
Technical data Model HY6F 5551 width 59.5 cm Dimensions height 85 cm depth 53.5 cm Capacity from 1 to 6 kg Electrical please refer to the technical data plate fixed to the machine connections maximum pressure 1 MPa (10 bar) Water connections minimum pressure 0.05 MPa (0.5 bar) drum capacity 52 litres...
Page 6: Description Of The Washing Machine And Starting A Wash Cycle
Description of the washing machine and starting a wash cycle Control panel WASH CYCLE PROGRESS indicator lights DISPLAY DOOR ON/OFF TEMPERATURE LOCKED button button indicator light START/PAUSE SPIN SPEED button with FUNCTION Detergent dispenser drawer button indicator light buttons with indicator lights WASH CYCLE knob...
Page 7: Indicator Lights
Indicator lights Temperature indicator light When a temperature value is selected, the corresponding The indicator lights provide important information. indicator light will illuminate. This is what they can tell you: Wash cycle phase indicator lights As the WASH CYCLE knob is rotated, the indicator lights illuminate, indicating the stages which will be performed by the machine in accordance with the selected wash cycle.
Page 8: Wash Cycles
Wash cycles Table of wash cycles Detergents Max. Max. Description of the wash cycle temp. speed (°C) (rpm) Essentials 1 Anti Stain 40° 1550 180’   2 Whites 60° 1550 180’   60° Cotton Standard 60° (1): heavily soiled whites and resistant colours. 1550 1.03 190’...
Page 9: Personalisation
Personalisation Setting the temperature Turn the TEMPERATURE knob to set the wash temperature (see Table of wash cycles). The temperature may be lowered, or even set to a cold wash ( ). The washing machine will automatically prevent you from selecting a temperature which is higher than the maximum value set for each wash cycle.
Page 10: Detergents And Laundry
Detergents and laundry Detergent dispenser drawer Cotton Standard 20°: use this cycle 5 for heavily soiled cotton loads. The effective performance levels achieved at Successful washing results also depend on the correct cold temperatures, which are comparable to washing at dose of detergent: adding too much detergent will not 40°, are guaranteed by a mechanical action which opera- necessarily result in a more efficient wash, and may in fact...
Page 11: Precautions And Tips
Precautions and tips This washing machine was designed and constructed in accordance with international safety regulations. The fol- lowing information is provided for safety reasons and must therefore be read carefully. General safety • This appliance was designed for domestic use only. •...
Page 12: Care And Maintenance
Care and maintenance Cutting off the water and electricity 2. unscrew the lid by rota- supplies ting it anti-clockwise (see figure): a little water may trickle out. This is perfectly • Turn off the water tap after every wash cycle. This will limit normal;...
Page 13: Troubleshooting
Troubleshooting Your washing machine could fail to work. Before contacting the Technical Assistance Centre (see “Assistance”), make sure that the problem cannot be solved easily using the following list. Problem: Possible causes / Solutions: The machine does not switch on. •...
Page 14 The machine is noisy. • There will always be some motor, pump and drum noise during spin. The machine wont spin properly. • Out of Balance detected when attempting to go into a spin cycle - If this happens the machine will continue to try to repeat the distribution of the load required before the machine will go into higher spin speeds - This will increase the programme time accordingly.
Page 15: Assistance
OR NON-DOMESTIC PREMISES. 5 Year Parts Guarantee Hotpoint also offers you a free 5 year parts guarantee. This additional guarantee is conditional on you registering your appliance with us and the parts being fitted by one of our authorised engineers. There will be a charge for our engineer’s time.
Page 16 Republic of Ireland: 0818 313 413 www.hotpointservice.co.uk Appliance Registration We want to give you additional benefits of Hotpoint ownership. To activate your free 5 year parts guarantee you must register your appliance with us. UK: 08448 24 24 24 Republic of Ireland: 01 230 0800 www.hotpointservice.co.uk...
