Land Pride LX3520 Installation Instructions Manual

LX35/4020 Third Function Valve Kit
Installation Instructions
For LX3520 & LX4020 Kubota Tractors with LA545 Loader
Before You Start
When you see this symbol, the subsequent
!
instructions and warnings are serious - follow
without exception. Your life and the lives of others
depend on it!
California Proposition 65
WARNING: Cancer and reproductive harm.
!
www.P65Warnings.ca.gov
IMPORTANT: Before you begin, read these
instructions and check to be sure all parts and tools
are accounted for. Please retain these installation
instructions for future reference and parts ordering
information.
General Information
Your LX20 Third Function Valve Kit has been designed
for the LX20 Kubota Cab and ROPS tractors equipped
with a Kubota LA545 front loader. These assembly
instructions apply to the Third Function Valve Kit
Accessories listed below:
• 380-419A: 3FVK FF LX20 LA545 CAB . . . . . . page 2
• 380-420A: 3FVK FF LX20 LA545 ROPS . . . . . page 2
• 380-429A: 3FBHK LX20 . . . . . . . . . . . . . . . . page 22
Further Assistance
Your Land Pride dealer wants you to be satisfied with your
new LX20 Third Function Valve Kit. If for any reason you
do not understand any part of this manual or are not
satisfied with the service received, the following actions
are suggested:
1. Discuss any problems you have with your Third
Function Valve Kit with your dealership service
personnel so they can address the problem.
2. If you are still not satisfied, seek out the owner or
general manager of the dealership, explain the
question/problem, and request assistance.
3. For further assistance write to:
Land Pride Service Department
1525 East North Street
P.O. Box 5060
Salina, Ks. 67402-5060
E-mail address
lpservicedept@landpride.com
© Copyright 2023 Printed 10/05/23
Manual No. 380-422M
Assembly Instructions
A detailed listing of parts for your Kubota LX3520 and
LX4020 tractors are provided on the following pages:
• LX20 CAB Third Function Valve Kit . . . . . . . page 16
• LX20 ROPS Third Function Valve Kit . . . . . . page 18
• LX20 Backhoe Accessory Hose Kit . . . . . . . page 23
Use the parts list specific to your kit as a checklist to
inventory parts received. Manuals can be downloaded
free-of-charge from our website at www.landpride.com.
Please contact your local Land Pride dealer for any
missing hardware.
NOTE: Unless specified in the procedure's section
title, all procedures apply to both cab and ROPS
tractor Third Function Valve Kits.
Direction Reference
All directional references are made from the operator
seat while facing the direction the machine will operate.
Directional Arrow Key
U
B
R
U = up
L = left
F
L
D
B = back
Initial Preparations
!
CAUTION
To avoid minor or moderate injury:
Hydraulic fluid can become hot as it flows through components
such as hydraulic couplers, hoses, lines, fittings, motors, etc.
Wear gloves when working with hydraulic components
including while connecting and disconnecting couplers. Allow
hydraulic components to cool before touching them.
Follow steps listed below before installing this kit:
1. If attached, dismount loader from tractor. If loader is
not attached, skip to step 5.
2. Turn tractor off, then relieve all hydraulic pressure
from hydraulic lines by operating the loader control
lever in all directions. Proceed with locking the control
lever before dismounting.
3. Disconnect loader hydraulic lines from loader valve.
a. Refer to your tractor/loader Operator's Manual for
additional unhooking instructions.
4. Restart tractor and slowly back away from loader.
5. Park tractor on a flat, level surface. Put tractor in park
or set park brake, turn off engine, and remove ignition
key to prevent unauthorized starting.
6. As a safety precaution, disconnect the negative (-)
battery cable from battery terminal. Move cable away
from terminal to avoid accidental contact.
D = down
R = right
F = front
