Toshiba Tecra M8-ST3094 Specifications

Tecra M8-ST3094 Detailed Product Specification
Model Name Description
M8-ST3094 Genuine Windows® XP Professional, Intel® Core™ 2 Duo Processor T7100, 1024MB
DDR2, 80GB 5400rpm (S-ATA), DVD SuperMulti Drive, 13.3" WXGA, Intel® Graphics
Media Accelerator X3100, Built-in Webcam, Intel® PRO/Wireless 3945ABG
(802.11a/b/g), 1-year standard limited warranty.
C1
Operating System
• Genuine Windows® XP Professional
Processor and Chipset
Intel® Centrino® Duo processor technology featuring:
o Intel® Core™ 2 Duo Processor T7100
1.8GHz, 2MB L2, 800MHz FSB with 64-bit
o Intel® Core™ 2 Duo Processor T7250
2.0GHz, 2MB L2, 800MHz FSB with 64-bit
o Intel® Core™ 2 Duo Processor T7300
2.0GHz, 4MB L2, 800MHz FSB with 64-bit
o Intel® Core™ 2 Duo Processor T7500
2.2GHz, 4MB L2, 800MHz FSB with 64-bit
o Intel® Core™ 2 Duo Processor T7700
2.4GHz, 4MB L2, 800MHz FSB with 64-bit
• Chipset
o Mobile Intel® GM965 Express Chipset
• Choice of Integrated Wi-Fi® compliant wireless LAN
o Intel® PRO/Wireless 3945ABG (802.11a/b/g) or
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
4
Memory
• Configured with 1024MB PC2-5300 DDR2 SDRAM (both memory slots
may be occupied)
• 512MB (Min)/4096MB (Max), with 256MB, 512MB, 1024MB or 2048MB
PC2-4200 or PC2-5300 DDR2 memory modules
5
Hard Disk Drive
• Choice of: 80GB (5400 RPM), 120GB (5400 RPM), 160GB (5400RPM),
or 200GB (4200 RPM); Serial ATA hard disk drive; 9.5mm height;
user removable
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (4x), DVD-ROM (8x), DVD-R (Single Layer, (8x)), DVD-
R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single Layer,
(8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-RAM
(5x)
7
Display
• 13.3" diagonal widescreen TruBrite® TFT LCD display at 1280 x 800
native resolution(WXGA)
8
Graphics
• Mobile Intel® Graphics Media Accelerator X3100 with 64MB-251MB
dynamically allocated shared graphics memory. (Video size
Sound
• Built-in stereo speakers
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• 85 key US keyboard
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Toshiba Assist button to launch Toshiba Assist control panel
o Presentation button to quickly connect to projectors
Communications
• Webcam and microphone built into LCD bezel
• Modem 9
2
3
6
© Copyright 2006 – 2007 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
TECRA M8-ST3094 BTO Rev. 1.03 2008-01-16 SK T20070402 CB1.20
1
• 10/100 Ethernet
• Choice of Integrated Wi-Fi® compliant wireless:
o Intel® PRO/Wireless 3945ABG (802.11a/b/g)
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n)
• Optional Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
Expandability
• 2 main memory slots. Both slots may be occupied.
C1
• One PCMCIA – Type II Card Slot
• Bridge Media Adapter
C1
o Secure Digital, miniSD, SDHC, Memory Stick™, Memory Stick
PRO™, Multi Media Card, xD Picture Card [shared slots]
C1
Ports
• Video
C1
o RGB (monitor) output port
• Audio
C1
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o USB v2.0 – 3 ports
• Security
o Fingerprint reader
Physical Description
• Dimensions (WxDxH Front/H Rear): 12.2" x 8.94" x 1.19" /1.34" without
feet
• Weight: Starting at 4.5lbs depending upon configuration
• LCD Cover Color: Titanium Silver
Power
• 75W (19V x 3.95A) 100-240V AC Adapter.
• Dimensions (WxDxH): 5.04" x 1.20" x 2.01"
• Weight: starting at 0.77 lbs
12
Battery
• (5200mAh) Lithium Ion battery pack
• Dimensions (WxDxH): 8.11" x 2.01" x 0.87"
• Weight: starting at 0.75 lbs
Toshiba EasyGuard®
• Protect & Fix
o Hard Disk Drive Protection
o Spill-Resistant Keyboard
o TOSHIBA PC Diagnostic Tool
o Key Component Access
• Secure
o Multiple-Level Password Utilities
o Fingerprint Reader (includes software for password and identity
management)
o UPEK Protector Suite™ QL
o Reinforced Security Cable Lock Slot
o Execute Disable Bit
o Optional Services and Accessories (additional purchase required)
• Connect
o Diversity Antenna
o TOSHIBA ConfigFree®
o Voice-over-IP Ready Design
o TOSHIBA Bluetooth® Stack
• Optimize
Part Number UPC
PTM80U-00E00F 032017933811
10
13
3D Accelerometer
HDD Dome Shock Protector
HDD Shock Absorber
14
HDLock™ for Toshiba Notebooks
11
Page 1 of 5
