Nivian NV-XVR410 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

NV-XVR410 | NV-XVR810
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NV-XVR410 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nivian NV-XVR410

Summary of Contents for Nivian NV-XVR410

  • Page 1 NV-XVR410 | NV-XVR810 USER MANUAL...
  • Page 2 Digital Video Recorder User Manual Legal Information About this Manual The Manual includes instructions for using and managing the Product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 Digital Video Recorder User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 4 Digital Video Recorder User Manual Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.
  • Page 5 Digital Video Recorder User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, Caution could result in equipment damage, data loss, performance...
  • Page 6 Digital Video Recorder User Manual Safety Instruction ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. ● In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region.
  • Page 7 Digital Video Recorder User Manual Preventive and Cautionary Tips Before connecting and operating your device, please be advised of the following tips: ● The device is designed for indoor use only. Install it in a well-ventilated, dust-free environment without liquids. ●...

  • Page 8: Table Of Contents

    Digital Video Recorder User Manual Contents Chapter 1 Startup ........................1 1.1 Activate Your Device ......................1 1.2 Login ............................2 1.2.1 Set Unlock Pattern ..................... 2 1.2.2 Log in via Unlock Pattern ................... 3 1.2.3 Log in via Password ....................4 Chapter 2 Live View ........................
  • Page 9 Digital Video Recorder User Manual 5.2.2 Guarding Vision ......................20 5.2.3 Email ......................... 20 5.3 Camera Management ......................22 5.3.1 Configure Signal Input ....................22 5.3.2 Network Camera ...................... 23 5.3.3 OSD Settings ......................25 5.3.4 Smart Event ......................26 5.4 Recording Management ......................
  • Page 10 Digital Video Recorder User Manual 6.4.3 Configure Arming Schedule ..................64 6.4.4 Configure Alarm Linkage Action ................65 6.5 Recording Management ...................... 67 6.5.1 Configure Recording Schedule ................. 67 6.5.2 Configure Recording Parameter ................69 6.5.3 Storage Device ......................70 6.5.4 Configure Storage Mode ..................

  • Page 11: Chapter 1 Startup

    Digital Video Recorder User Manual Chapter 1 Startup 1.1 Activate Your Device For the first-time access, you need to activate the video recorder by setting an admin password. No operation is allowed before activation. You can also activate the video recorder via web browser, SADP or client software.

  • Page 12: Login

    Digital Video Recorder User Manual Figure 1-1 Activation 1.2 Login 1.2.1 Set Unlock Pattern Admin user can use the unlock pattern to login. You can configure the unlock pattern after the device is activated. Steps 1. Use the mouse to draw a pattern among the 9 dots on the screen. Release the mouse when the pattern is done.

  • Page 13: Log In Via Unlock Pattern

    Digital Video Recorder User Manual Figure 1-2 Set Unlock Pattern 1.2.2 Log in via Unlock Pattern Steps 1. Right click the mouse on live view interface. Figure 1-3 Draw the Unlock Pattern 2. Draw the pre-defined pattern to unlock to enter the menu operation.

  • Page 14: Log In Via Password

    Digital Video Recorder User Manual Note ● If you have forgotten your pattern, you click Forgot My Pattern or Switch User to log in via password. ● If you have drawn the wrong pattern for more than 5 times, the system will switch to the normal login mode automatically.

  • Page 15: Chapter 2 Live View

    Digital Video Recorder User Manual Chapter 2 Live View 2.1 GUI Introduction ● Click to start/stop auto-switch. The screen will automatically switch to the next one. ● Click to start/stop all-day recording. ● Right click a camera, or click to enter full screen mode. ●...

  • Page 16: Ptz Control

    Digital Video Recorder User Manual 2.2 PTZ Control 2.2.1 Configure PTZ Parameter You shall configure PTZ parameters before controlling a PTZ camera. Steps 1. Preview a camera in live view and click on shortcut menu. Figure 2-2 PTZ Settings 2. Click PTZ Parameter Settings.
  • Page 17 Digital Video Recorder User Manual Figure 2-3 PTZ Parameter 3. Set the PTZ camera parameters. Note ● All parameters should be the same as the PTZ camera. ● For the Coaxitron camera/dome connected, you can select the PTZ protocol to UTC (Coaxitron).

  • Page 18: Customize Preset

    Digital Video Recorder User Manual Icon Description Zoom -/+. Focus -/+. Iris -/+. 2.2.2 Customize Preset Set a preset location where the PTZ camera would point to when an event occurs. Steps 1. Preview a camera in live view and click on shortcut menu.

  • Page 19: Customize Pattern

    Digital Video Recorder User Manual Figure 2-4 Patrol Settings 7. Click Apply. What to do next Select a patrol and click Call to call it. The PTZ camera will move according the predefined patrol path. Figure 2-5 Call Preset 2.2.4 Customize Pattern A pattern records the movement path and dwell time in a certain position.

  • Page 20: Chapter 3 Playback

    Digital Video Recorder User Manual Chapter 3 Playback 3.1 GUI Introduction Go to Playback. Figure 3-1 Playback Table 3-1 Playback Interface Description Button Operation Button Operation Switch playback Clip video. stream. 30 s reverse. 30s forward. Reverse playback. Start playback. Speed down.

  • Page 21: Normal Playback

    Digital Video Recorder User Manual Figure 3-2 Timeline ● Position the cursor on the timeline, drag the timeline to position to a certain time. ● Period marked with blue bar contains video. Red bar indicates the video in the period is event video.
  • Page 22 Digital Video Recorder User Manual motion detection, line crossing detection, or intrusion detection information. Before You Start Configure motion detection, line crossing detection, and intrusion detection rules and detection areas. Steps 1. Go to Playback. 2. Click Smart. 3. Select a camera. Figure 3-4 Smart Playback Interface 4.
  • Page 23 Digital Video Recorder User Manual Button Detection Button Detection for intrusion for line crossing detection. detection. Clear detection area. 5. Position the cursor on to set detection areas for smart event. Line Crossing Click , and draw the detection line. Detection Intrusion Detection Click...

  • Page 24: Sub-Periods Playback

    Digital Video Recorder User Manual 3.4 Sub-Periods Playback The videos can be played in multiple sub-periods simultaneously. Steps 1. Go to Playback. 2. Click Sub-periods. 3. Select a camera. 4. Set start and end time. 5. Optional: Select window division mode as 4-Period, 9-Period, or 16-Period. Videos will be divided into 4/6/9 equal segments.

  • Page 25: Chapter 4 File Search

    Digital Video Recorder User Manual Chapter 4 File Search 4.1 Search File Steps 1. Go to Search. 2. Set search conditions. 3. Click Search. – Click to play the video. – Click to lock the file. Locked file will not be overwritten. –...

  • Page 26: Chapter 5 Configuration (Easy Mode)

    Digital Video Recorder User Manual Chapter 5 Configuration (Easy Mode) Easy mode contains basic configurations. Go to Configuration, and click Easy Mode. 5.1 System Configuration 5.1.1 General You can configure the output resolution, system time, mouse pointer speed, etc. Steps 1.

  • Page 27: User

    Digital Video Recorder User Manual NTP Server IP address of the NTP server. NTP Port Port of the NTP server. 3. Click Apply. 5.1.2 User Add User There is a default account: Administrator. The administrator user name is admin. Administrator has the permission to add, delete, and edit user.

  • Page 28: Exception

    Digital Video Recorder User Manual Warning We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.

  • Page 29: Network Configuration

    Digital Video Recorder User Manual Figure 5-3 Exceptions 5. Click Apply. 5.2 Network Configuration 5.2.1 General You shall properly configure the network settings before operating the device over network. Steps 1. Go to Configuration → Network → General. Figure 5-4 Network 2.

  • Page 30: Guarding Vision

    Digital Video Recorder User Manual If DHCP is checked. You can check Obtain DNS Automatically to automatically obtain Preferred DNS Server and Alternate DNS Server. 3. Click Apply. 5.2.2 Guarding Vision Guarding Vision provides mobile phone application and platform service to access and manage your connected devices, which enables you to get a convenient remote access to the surveillance system.
  • Page 31 Digital Video Recorder User Manual Figure 5-5 Email 2. Set email parameters Server Authentication (Optional), check it to enable the server authentication feature. User Name The user account of email sender for SMTP server authentication. Password The password of email sender for SMTP server authentication. SSL/TLS (Optional), check it to enable SSL/TLS if it required by the SMTP server.

  • Page 32: Camera Management

    Digital Video Recorder User Manual Note ● For network cameras, the event images are directly sent as the email attachment. One network camera only sends one picture. ● For analog cameras, 3 attached pictures will be sent for one analog camera when an event occurs.

  • Page 33: Network Camera

    Digital Video Recorder User Manual 5.3.2 Network Camera Activate Network Camera Only activated network cameras can be added. Before You Start Ensure your network camera is on the same network segment with your video recorder. Steps 1. Go to Configuration → Camera → IP Camera. Security column indicates whether the network camera is activated.
  • Page 34 Digital Video Recorder User Manual Add Network Camera by Device Password Add network cameras which the password is the same as your video recorder. Before You Start ● Ensure your network camera is on the same network segment with your video recorder. ●...

  • Page 35: Osd Settings

    Digital Video Recorder User Manual Figure 5-9 Add Network Camera Edit Connected Network Camera You can edit the IP address, protocol and other parameters of the added network cameras. Steps 1. Go to Configuration → Camera → IP Camera. 2. Click to edit the selected camera.

  • Page 36: Smart Event

    Digital Video Recorder User Manual Figure 5-10 OSD 3. Drag the text frames on the preview window to adjust the OSD position. 4. Click Apply. 5.3.4 Smart Event Motion Detection Motion detection enables the video recorder to detect the moving objects in the monitored area and trigger alarms.
  • Page 37 Digital Video Recorder User Manual 4. Set the motion detection area. Full screen Click Full Screen to set the motion detection area as full screen. Customized area Drag on the preview window to draw motion detection areas. Clear Click Clear to clear the current motion detection areas. 5.
  • Page 38 Digital Video Recorder User Manual A->B Only an object crossing the configured line from the A side to the B side can be detected. B->A Only an object crossing the configured line from the B side to the A side can be detected. 3) Set Sensitivity.
  • Page 39 Digital Video Recorder User Manual Configure Alarm Linkage Action Alarm linkage actions will be activated when an alarm or exception occurs. Steps 1. Click Linkage Action. Figure 5-13 Linkage Actions 2. Set normal linkage actions, trigger alarm output, trigger recording channel, etc. Full Screen Monitoring The local monitor will display the alarming channel image in full screen when an alarm is triggered.

  • Page 40: Recording Management

    Digital Video Recorder User Manual 5.4 Recording Management 5.4.1 Storage Device Initialize HDD A newly installed hard disk drive (HDD) must be initialized before it can be used to save videos and information. Before You Start Install at least an HDD to your video recorder. For detailed steps, refer to Quick Start Guide. Steps 1.

  • Page 41: Configure Recording Schedule

    Digital Video Recorder User Manual Figure 5-14 Add NetHDD 7. Select NAS disk from the list, or manually enter the directory in NetHDD Directory. 8. Click OK. The added NetHDD will be displayed in the storage device list. 5.4.2 Configure Recording Schedule Video recorder will automatically start/stop recording according to the configured schedule.
  • Page 42 Digital Video Recorder User Manual 3. Go to Configuration → Record → Parameter. 4. Set the continuous main stream/sub-stream recording parameters for the camera. Refer to Configure Recording Parameter for details. 5. Go to Configuration → Record → Schedule. 6. Select recording type as Event. Refer to Edit Schedule for details. Edit Schedule Steps 1.

  • Page 43: Configure Recording Parameter

    Digital Video Recorder User Manual Note Up to 8 periods can be configured for each day. And the time periods cannot be overlapped with each other. 5. Click OK to save the settings and go back to upper level menu. 6 Edit Schedule 1.
  • Page 44 Digital Video Recorder User Manual Sub-Stream Sub-stream is a second codec that runs alongside the mainstream. It allows you to reduce the outgoing internet bandwidth without sacrificing your direct recording quality. Sub-stream is often exclusively used by smartphone applications to view live video. Users with limited internet speeds may benefit most from this setting.

  • Page 45: Chapter 6 Configuration (Expert Mode)

    Digital Video Recorder User Manual Chapter 6 Configuration (Expert Mode) Go to Configuration, and click Expert Mode at the lower-left corner. 6.1 System Configuration 6.1.1 General You can configure the output resolution, system time, mouse pointer speed, etc. Steps 1. Go to Configuration → System → General. Figure 6-1 General Settings 2.

  • Page 46: Live View

    Digital Video Recorder User Manual Set timeout time for menu inactivity. Enable Wizard The wizard pops up after the device starts up. Enable Password You need to enter password for authentication if the device automatically logged out. Menu Output Mode Choose output to display local menu.
  • Page 47 Digital Video Recorder User Manual Live View Mode Select the live view window division. Dwell Time The time to dwell in a camera before switching to next camera when auto-switch in live view is enabled. Event Output Select the output to show event video. Full Screen Monitoring Dwell Time Set the time to show alarm event image.

  • Page 48: User

    Digital Video Recorder User Manual bandwidth requirement without affecting the image quality. Steps 1. Go to Configuration → System → Live View → General. 2. Set Video Output Interface as Channel-Zero. 3. Go to Configuration → System → Live View → Channel-Zero. Figure 6-3 Channel-Zero 4.

  • Page 49: Ddns

    Digital Video Recorder User Manual ● The two NIC cards use the same IP address, and you can select the Main NIC to LAN1 or LAN2. By this way, in case of one NIC card failure, the video recorder will automatically enable the other standby NIC card so as to ensure the normal running of the whole system.

  • Page 50: Nat

    Digital Video Recorder User Manual Figure 6-4 DDNS 2. Check Enable. 3. Select a DDNS type. 4. Enter parameters including service address, domain name, etc. 5. Click Apply. What to do next You can view DDNS status in Status. 6.2.3 NAT Two ways are provided for port mapping to realize the remote access via the cross-segment network, UPnP™...

  • Page 51: Ports (More Settings)

    Digital Video Recorder User Manual devices are configured for the UPnP™ settings under the same router, the value of the port No. for each device should be unique. 4. Set the virtual server of your router, including internal source port, external source port, etc. The virtual server parameters shall be corresponding with your device port.

  • Page 52: Guarding Vision

    Digital Video Recorder User Manual ● The default output bandwidth is the maximum limit. Figure 6-5 Port Settings 6.2.5 Guarding Vision Go to Configuration → Network → Platform Access. Refer to Guarding Vision for details. 6.2.6 Advanced Settings Steps 1. Go to Configuration → Network → Advanced Settings. 2.

  • Page 53: Camera Management

    Digital Video Recorder User Manual The admin user account can disable the HTTP service from the GUI or the web browser. After the HTTP is disabled, all the related services, including the ISAPI, Onvif and Gennetc, will terminate as well. HTTP Authentication If you need to enable the HTTP service, you can set the HTTP authentication to enhance the access security.

  • Page 54: Network Camera

    Digital Video Recorder User Manual If the option is checked, signal of1080p resolution is available for the analog channels. 4. Click Apply. You can view the maximum network camera accessible number in Max. IP Camera Number. 6.3.2 Network Camera Activate Network Camera Only activated network cameras can be added.
  • Page 55 Digital Video Recorder User Manual Figure 6-7 Activation 4. Choose one of the following methods to set camera password. – Use video recorder password: Check Use Channel Default Password to activate the camera using the set channel default password. – Customize password: Enter the same password in Password and Confirm. Warning Strong Password recommended-We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following...
  • Page 56 Digital Video Recorder User Manual 2. Click Online Device. The online cameras on the same network segment will be displayed in the list. Figure 6-8 Online Device 3. Select a network camera, and click Add to add it. Add Network Camera Manually Add the network cameras to your video recorder.
  • Page 57 Digital Video Recorder User Manual Figure 6-9 Add IP Camera 3. Enter information of the network camera to add. Use Channel Default Password If it is checked, the video recorder will add the camera by the set channel default password. 4.

  • Page 58: Display Settings

    Digital Video Recorder User Manual Example Enter an example that illustrates the current task (optional). What to do next Enter the tasks the user should do after finishing this task (optional). Import/Export IP Camera Configuration File The information of added network camera can be generated into an excel file and exported to the local device for backup, including the IP address, manage port, password of admin, etc.
  • Page 59 Digital Video Recorder User Manual settings, etc. Steps 1. Go to Configuration → Camera → Display. 2. Select Camera. 3. Configure parameters as your desire. OSD Settings Configure the OSD (On-screen Display) settings for the camera, including date/time, camera name, etc. Image Settings Customize the image parameters including the brightness, contrast, and saturation for the live view and recording effect.

  • Page 60: Privacy Mask

    Digital Video Recorder User Manual 6.3.4 Privacy Mask You are allowed to configure the privacy mask areas that cannot be viewed or recorded. Steps 1. Go to Configuration → Camera → Privacy Mask. 2. Select Camera. 3. Check Enable. Figure 6-11 Privacy Mask 4.

  • Page 61: Event Configuration

    Digital Video Recorder User Manual 6.4 Event Configuration 6.4.1 Normal Event Motion Detection Motion detection enables the video recorder to detect the moving objects in the monitored area and trigger alarms. Steps 1. Go to Configuration → Event → Normal Event → Motion Detection. Figure 6-12 Motion Detection 2.
  • Page 62 Digital Video Recorder User Manual Note The option is only available for PIR camera. 7. Set the arming schedule. 8. Set the linkage actions. 9. Click Apply. Video Tampering Trigger alarm when the lens is covered and take alarm response actions. Steps 1.
  • Page 63 Digital Video Recorder User Manual Video Loss Detect video loss of a camera and take alarm response actions. Steps 1. Go to Configuration → Event → Normal Event → Video Loss. 2. Select Camera. 3. Check Enable. 4. Set the arming schedule. 5.
  • Page 64 Digital Video Recorder User Manual Figure 6-15 Edit Alarm Input 3. Customize Alarm Name. 4. Select alarm Type as N.O (normally open) or N.C (normally closed). 5. Select Settings as Input to enable the function. 6. Set the arming schedule. 7.
  • Page 65 Digital Video Recorder User Manual Figure 6-16 Alarm Output 5. Select Settings as Input to enable the function. 6. Set the arming schedule. 7. Click Apply. Exception Exception events can be configured to take the event hint in the live view window and trigger alarm outputs and linkage actions.

  • Page 66: Smart Event

    Digital Video Recorder User Manual Figure 6-17 Exceptions 4. Set the arming schedule. 5. Click Apply. 6.4.2 Smart Event Face Detection Face detection function detects the face appears in the surveillance scene, and some certain actions can be taken when the alarm is triggered. Steps 1.
  • Page 67 Digital Video Recorder User Manual Figure 6-18 Face Detection 2. Select Camera to configure. 3. Check Save VCA Picture to save the captured pictures of VCA detection. 4. Check Enable Face Detection. 5. Adjust Sensitivity. Sensitivity: Range [1-100]. The higher the value is, the more easily the defocus image can trigger the alarm.
  • Page 68 Digital Video Recorder User Manual 7. Set the linkage actions. 8. Click Apply. Line Crossing Detection Line crossing detection detects people, vehicles, and objects crossing a set virtual line. The detection direction can be set as bidirectional, from left to right or from right to left. Steps 1.
  • Page 69 Digital Video Recorder User Manual 7. Set the linkage actions. 8. Click Apply. Region Exiting Detection Region exiting detection function detects people, vehicle or other objects which exit from a pre- defined virtual region, and some certain actions can be taken when the alarm is triggered. Steps 1.
  • Page 70 Digital Video Recorder User Manual 7. Set the linkage actions. 8. Click Apply. People Gathering Detection People gathering detection alarm is triggered when people gather around in a pre-defined virtual region, and a series of actions can be taken when the alarm is triggered. Steps 1.
  • Page 71 Digital Video Recorder User Manual Parking Detection Parking detection function detects illegal parking in places such as highway, one-way street, etc., and a series of actions can be taken when the alarm is triggered. Steps 1. Go to Configuration → Event → Smart Event → Parking. 2.
  • Page 72 Digital Video Recorder User Manual 8. Click Apply. Object Removal Detection Object removal detection function detects the objects removed from the pre-defined region, such as the exhibits on display, and a series of actions can be taken when the alarm is triggered. Steps 1.
  • Page 73 Digital Video Recorder User Manual Defocus The image blur caused by defocus of the lens can be detected, and some certain actions can be taken when the alarm is triggered. Steps 1. Go to Configuration → Event → Smart Event → Defocus. Figure 6-19 Defocus Detection 2.

  • Page 74: Configure Arming Schedule

    Digital Video Recorder User Manual 3. Check Save VCA Picture to save the captured pictures of VCA detection. 4. Check Enable. 5. Adjust Sensitivity. The Sensitivity in the Rule Settings ranges from 1 to 100, and the higher the value is, the more easily the change of scene can trigger the alarm. Note For the analog cameras, the line crossing detection and intrusion detection conflict with sudden scene change detection.

  • Page 75: Configure Alarm Linkage Action

    Digital Video Recorder User Manual 6.4.4 Configure Alarm Linkage Action Configure Full Screen Monitoring When an alarm is triggered, the local monitor displays in full screen the video image from the alarming channel configured for full screen monitoring. And when the alarm is triggered simultaneously in several channels, you must configure the auto-switch dwell time.
  • Page 76 Digital Video Recorder User Manual iVMS-5200). Steps 1. Log into video recorder in web browser. 2. Go to Configuration → Network → Advanced Settings → Other. 3. Set Alarm Host IP and Alarm Host Port. 4. In local menu, go to Linkage Action interface of the alarm detection. 5.

  • Page 77: Recording Management

    Digital Video Recorder User Manual Figure 6-21 PTZ Linkage Note You can set one PTZ type only for the linkage action each time. 6.5 Recording Management 6.5.1 Configure Recording Schedule Video recorder will automatically start/stop recording according to the configured schedule. Configure Continuous Recording Steps 1.
  • Page 78 Digital Video Recorder User Manual Configure Event Recording You can configure the recording triggered by the normal event or smart event. Steps 1. Go to Configuration → Event. 2. Configure the event detection and select the cameras to trigger the recording when event occurs.

  • Page 79: Configure Recording Parameter

    Digital Video Recorder User Manual Note Up to 8 periods can be configured for each day. And the time periods cannot be overlapped with each other. 5) Click OK to save the settings and go back to upper level menu. Figure 6-23 Edit Schedule Note You can also Click to select schedule type as ContinuousorEvent.and On the table, drag the...

  • Page 80: Storage Device

    Digital Video Recorder User Manual may benefit most from this setting. Steps 1. Go to Configuration → Record → Parameter to configure camera main stream and sub-stream parameters. 2. Configure recording parameters. Frame Rate Frame rate refers to how many frames are captured each second. A higher frame rate is advantageous when there is movement in the video stream, as it maintains image quality throughout.

  • Page 81: Configure Storage Mode

    Digital Video Recorder User Manual 2. Select an HDD. 3. Click Init. Add Network Disk You can add the allocated NAS or IP SAN disk to the video recorder, and use it as a network HDD. Up to 8 network disks can be added. Steps 1.
  • Page 82 Digital Video Recorder User Manual 5. Click Apply. 6. Reboot the video recorder to activate the new storage mode settings. 7. After reboot, go to Configuration → Record → Storage. 8. Click of desired HDD to set the group. 9. Select Group number for the current HDD. 10.

  • Page 83: Advanced Settings

    Digital Video Recorder User Manual 6.5.5 Advanced Settings Steps 1. Go to Configuration → Record → Advanced Settings. 2. Configure the parameters as your desire. Overwrite ● Disable: When the HDD is full, video recorder will stop writing. ● Enable: When hard drive is full, video record will continue to write new files by deleting the oldest files.

  • Page 84: Rs-232 Settings

    Digital Video Recorder User Manual 4. Scan the QR code to log into the selected cloud to get the authentication code and enter Authentication Code. 5. Click Apply. 6. About 20 seconds later, cloud storage status will be Online. 7. Configure the event recording schedule. For detailed recording schedule, refer to Configure Recording Schedule.
  • Page 85 Digital Video Recorder User Manual 2. Configure RS-232 parameters, including baud rate, data bit, stop bit, parity, flow control and usage. Console Connect a computer to the video recorder through the computer serial port. Video recorder parameters can be configured by using software such as HyperTerminal. The serial port parameters must be the same as those of video recorder when connecting with the computer serial port.

  • Page 86: Chapter 7 Maintenance

    Digital Video Recorder User Manual Chapter 7 Maintenance 7.1 Restore Default Steps 1. Go to Maintenance. 2. Select the restoring type. Simple Restore Restore all parameters, except the network (including IP address, subnet mask, gateway, MTU, NIC working mode, default route, server port, etc.) and user account parameters, to the factory default settings.

  • Page 87: Local Upgrade

    Digital Video Recorder User Manual 7.3.1 Local Upgrade Before You Start Store the upgrade firmware to a backup device, and connect it to your device. Steps 1. Go to Maintenance. 2. Click near Firmware. 3. Select a backup device in Device Name. 4.

  • Page 88: Chapter 8 Alarm

    Digital Video Recorder User Manual Chapter 8 Alarm When events occur, you can view their details in alarm center. 8.1 Set Event Hint Select the events to hint in alarm center. Steps 1. Click in the upper-right corner of local menu to enter alarm center. 2.

  • Page 89: Chapter 9 Web Operation

    Digital Video Recorder User Manual Chapter 9 Web Operation 9.1 Introduction You can get access to the video recorder via web browser. You may use one of the following listed web browsers: Internet Explorer 6.0 to 11.0, Apple Safari, Mozilla Firefox, and Google Chrome. The supported resolutions include 1024×768 and above. 9.2 Login You shall acknowledge that the use of the product with Internet access might be under network security risks.

  • Page 90: Live View

    Digital Video Recorder User Manual Figure 9-1 Login 4. Follow the installation prompts to install the plug-in. Note You may have to close the web browser to finish the installation of the plug-in. 9.3 Live View After login, live view interface shows. Figure 9-2 Live View...

  • Page 91: Playback

    Digital Video Recorder User Manual 9.4 Playback Click Playback to enter playback interface. Figure 9-3 Playback 9.5 Configuration Click Configuration to enter configuration interface. Figure 9-4 Configuration...

  • Page 92: Log

    Digital Video Recorder User Manual 9.6 Log Steps 1. Go to Maintenance → System → Maintenance → Log. 2. Set the search conditions. 3. Click Search. Figure 9-5 Log...

  • Page 93: Chapter 10 Appendix

    Digital Video Recorder User Manual Chapter 10 Appendix 10.1 Glossary Dual-Stream Dual-stream is a technology used to record high resolution video locally while transmitting a lower resolution stream over the network. The two streams are generated by the DVR, with the main stream having a maximum resolution of 1080P and the sub-stream having a maximum resolution of CIF.
  • Page 94 Digital Video Recorder User Manual Acronym for Network Time Protocol. A protocol designed to synchronize the clocks of computers over a network. NTSC Acronym for National Television System Committee. NTSC is an analog television standard used in such countries as the United States and Japan. Each frame of an NTSC signal contains 525 scan lines at 60Hz.
  • Page 95 UD20437N...
