Toshiba Tecra M1 Specifications

TOSHIBA
Product Name: Tecra M1
Featured Model(s)*:
1.6GHz, 14.1"XGA, 512MB, 60GB, DVD-CDRW, Intel 802.11b, 9 cell, Windows XP Pro
1.4GHz, 14.1"XGA, 256MB, 40GB, DVD, Intel 802.11b, 9 cell, Windows XP Pro
* Other configurations available
Custom Configuration options
and optional items listed below are highlighted

Product Highlights

•
Stability: Toshiba's award-winning Tecra
customers a stable platform, consistent image and long product
lifecycles (12+ months) to reduce total cost of ownership.
•
Connectivity – Your Way: The Tecra M1 includes integrated Wi-Fi
(IEEE 802.11b or a/b dual band support) wireless communication, so
users can get connected while on the road without the hassle of cords
or cables and enjoy faster data rates. Bluetooth wireless technology,
fast infrared, built-in V.92 modem, 10/100/1000 Ethernet and PC Card
support for a 3G connectivity round out the notebook's unlimited
connectivity options. In addition, the Tecra M1 provides Gigabit
Ethernet for faster connections and hi-speed data transfer.
•
Productivity & Power for the Mobile Professional: Incorporating the
®
Intel Centrino™ mobile technology, Tecra M1 users experience a
breakthrough level of mobile performance, extended battery life (up to
5+ hours/10+ with optional Select Bay
wireless connectivity for improved productivity whether traveling or in
the office. Offering multiple ports and the first corporate platform to
provide DVD-RAM/RW capabilities as well as 2GB of memory for
those power-hungry projects, customers need look no further than the
Tecra M1 for the notebook that has it all.
•
Enhanced Usability: Toshiba understands the business professional
requires more than just computing power in their notebook PC.
Therefore, the Tecra M1 provides enhanced features such as a
brightness sensor to control the display in different environmental
settings and a one-touch presentation button so the user can easily
connect to a projector. In addition, the unit also offers dual mouse
control (pointing device and touchpad) functionality and Toshiba's own
Config-Free software for easy troubleshooting to ensure fast Wi-Fi
connections.
•
Common Accessories and Docking: Adding convenience while
saving time and money, the Tecra M1 shares common docking and
®
Slim Select Bay accessories with Toshiba's award-winning Portégé
®
4000 Series, Satellite Pro
Series and Tecra S1 notebooks which is a welcome addition to any
business looking to reduce overall costs. Additionally, for hi-speed
connection to a variety of peripherals, the Tecra M1 includes a new
Advanced Port Rep with USB 2.0 support.
System Characteristics
Processor (See CPU Performance Disclaimer)****
•
Intel® Pentium M processor at 1.70, 1.60 or 1.40 GHz
•
Intel 855PM system chipset
•
400MHz processor side bus clock speed
•
1MB Level 2 Cache integrated on die
Memory
•
256-2048MB SODIMM memory
•
256MB, 512MB, 1024MB PC2100 DDR SDRAM, 2.5V
Mass Storage
•
60, 40, 30GB* Enhanced IDE (ATA-5) hard disk drive; 9.5mm
height; 60 & 40GB: 5400rpm; user removable
•
Slim SelectBay CD-ROM, 5.25" EIDE, 12.7mm height, 24X CD-
ROM speed. Compatibility: CD-ROM, CD-R (read only), CD-RW
(read only).
•
Slim SelectBay DVD-ROM, 5.25" EIDE, 12.7mm height.
Compatibility: CD-ROM, CD-R, CD-RW, DVD-ROM, DVD-R,
DVD-RAM (all read only).
•
Slim SelectBay DVD-ROM/CD-RW, 5.25" EIDE, 12.7mm height.
Compatibility: CD-ROM, CD-R (read/write), CD-RW
(read/rewrite), DVD-ROM, DVD-R (read only), DVD-RW (read
only), DVD-RAM (read only).
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without
notice. Copyright 2003 TAIS tecra_M1.doc Created on 6/2/2003 11:17 AM
®
family offers corporate
™
battery) and enhanced
6000 Series, Satellite Pro M10, Tecra 9000
Part Numbers
PT930U-03YCV7
PT930U-03NE37
•
Slim SelectBay DVD Multi Drive, 5.25" EIDE, 12.7mm height.
Compatibility: CD-ROM, CD-R (read/write), CD-RW (read/write),
DVD-ROM, DVD-R (read/write), DVD-RW (read/write), DVD-RAM
(read/write).
•
Slim SelectBay Battery, Lithium Ion (10.8V, 3600mAh)
•
Slim SelectBay Hard Disk Drive: 30, 40 and 60GB (Adapter
required)
•
USB Floppy Drive, 3.5", 1.44MB
Display
•
14.1" TFT active-matrix LCD; internal display supports up to 16M
colors at 1024 x 768 (XGA) or 1400 x 1050 (SXGA+)
•
Automatic brightness control
Graphics
•
Trident XP4m32 graphics controller; 32MB DDR video memory
•
External Color Support:
1280x1024, 1024x768, 800x600; 100Hz Non-Interlaced @ 16M
1600x1200; 85Hz Non-Interlaced @ 16M
2048x1536, 1920x1440; 60Hz Non-Interlaced @ 16M
Input Devices
•
Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key
stroke, 6mm height; Dedicated Windows® & Application keys
support; HotKey function
•
Mouse: Toshiba Dual Pointing Device
•
Toshiba Console Button
•
Presentation Button
Expandability
•
2 Expansion memory slots (including Main Memory)
•
2 PC Card slots support 2 Type II or 1 Type III PC Cards,
PCMCIA R2.01, PC Card16, CardBus
•
SD slot
Communications
•
Integrated V.92 modem
Due to FCC limitations, speeds of 53kbps are the maximum permissible
transmission rates during download. Actual data transmission speeds will
vary depending on line conditions.
•
Integrated 10/100/1000Base-TX Ethernet**
•
Integrated i.LINK (400Mpbs)
•
Integrated Fast Infrared (4Mbps)
®
•
Integrated Wi-Fi compliant wireless LAN – 802.11b: Intel or Cisco.
802.11a/b: Atheros
•
Optional integrated Bluetooth (v1.1)
Ports
•
Parallel port
•
Serial Port
•
RGB (monitor) port
•
3 Universal Serial Bus (USB) port (v2.0)
•
i.LINK (IEEE 1394)
•
Infrared port
•
S-Video
•
240 pin docking connector
•
DVI connector (via Advanced Port Replicator)
•
Microphone in
•
Headphone out
•
RJ-45 LAN port
•
RJ-11 modem port
Physical Description
•
Dimensions (WxDxH): 12.0" x 10.6" x 1.4/1.5" Weight: 5.7lbs
(with 6 cell)
•
LED Indicators: DC-In, Power, Primary Battery, Hard Drive, Slim
SelectBay, Wireless indicator, SD indicator, Caps Lock, Arrow
Lock, Numeric Lock
•
Magnesium Alloy case
Sound
•
AD1981A software sound
•
16-bit stereo; Built-in stereo speakers, Built-in microphone
Rev. 1.5 Page 1 of 3
