WALL MOUNTED TYPE ROOM AIR-CONDITIONER
( Split system, air to air heat pump type )
SRK50HE-S1, SRK56HE-S1
SRK63HE-S1, SRK71HE-S1
Manual No. '06 . SRK-T . 050
updated September 29, 2009
