- Page 1 OWNER’S MANUAL DVD Home Cinema System Please read this manual carefully before operating your set and retain it for future reference. HT1100BB (HT1100BB, SH96TA-S/ W, SH96SB-C) HT906TA-N0_BTURLLK_ENG_6156.indd 1 2011-12-13 5:17:01...
- Page 2 Getting Started Safety Information CAUTION CAUTION: This product employs a Laser System. RISK OF ELECTRIC SHOCK To ensure proper use of this product, please read DO NOT OPEN this owner’s manual carefully and retain it for future CAUTION: TO REDUCE THE RISK OF ELECTRIC reference. Shall the unit require maintenance, SHOCK DO NOT REMOVE COVER (OR BACK) NO contact an authorized service center. USER-SERVICEABLE PARTS INSIDE REFER SERVICING Use of controls, adjustments or the performance of TO QUALIFIED SERVICE PERSONNEL. procedures other than those specified herein may result in hazardous radiation exposure. This lightning flash with To prevent direct exposure to laser beam, do not try arrowhead symbol within an to open the enclosure. Visible laser radiation when equilateral triangle is intended to open. DO NOT STARE INTO BEAM. alert the user to the presence of uninsulated dangerous voltage CAUTION concerning the Power Cord within the product’s enclosure that Most appliances recommend they be placed upon may be of sufficient magnitude to a dedicated circuit;...
- Page 3 Getting Started This device is equipped with a portable battery or You have to set the disc format option to [Mastered] accumulator. in order to make the discs compatible with the LG players when formatting rewritable discs. When Safety way to remove the battery or the setting the option to Live File System, you cannot battery from the equipment: Remove the use it on LG players. old battery or battery pack, follow the steps in reverse order than the assembly. To prevent (Mastered/ Live File System : Disc format system for contamination of the environment and bring on Windows Vista) possible threat to human and animal health, the Disposal of your old appliance old battery or the battery put it in the appropriate container at designated collection points. Do not dispose of batteries or battery together with 1. W hen this crossed-out wheeled bin other waste. It is recommended that you use...
-
Page 4: Table Of Contents
Table of Contents Table of Contents System Setting Adjust the setup settings – OSD Initial language settings - Optional Getting Started – To display and exit the Setup menu – Language Safety Information – Display Unique Features – Audio – Portable In –... - Page 5 Table of Contents Troubleshooting Troubleshooting Appendix Maintenance – Handling the Unit – Notes on Discs Area Code List Language code List Trademarks and Licenses Specifications HT906TA-N0_BTURLLK_ENG_6156.indd 5 2011-12-13 5:17:02...
-
Page 6: Getting Started
Getting Started Unique Features Accessories Please check and identify the supplied accessories. Portable In Listen to music from your portable device. (MP3, Notebook, etc) USB Direct Recording Remote control (1) Battery (1) Records music from CD to your USB device. Full HD up-scaling Views Full HD picture quality with simple setup. Home Theater Speaker ez Setup Video cable (1) Speaker cables (6) Listen to sounds from TV, DVD and Digital device with vivid 5.1 (2.1 or 2.0) ch mode. HDMI cable (1) Portable cable (1) HT906TA-N0_BTURLLK_ENG_6156.indd 6 2011-12-13 5:17:02... -
Page 7: Introduction
Getting Started Introduction Symbols Used in this Manual DVD-Video, DVD±R/RW in Video mode or VR mode and finalized Playable Discs Audio CDs This unit plays DVD±R/RW and CD-R/RW that contains audio titles, DivX, MP3, WMA and/or Video files contained in the JPEG files. Some DVD±RW/DVD±R or CD-RW/ USB/Disc CD-R cannot be played on this unit due to the recording quality or physical condition of the disc, Audio files contained in the or the characteristics of the recording device and USB/Disc authoring software. Photo files DVD-VIDEO (8 cm / 12 cm disc) Discs such as movies that can be Note purchased or rented. Indicates special notes and operating features. DVD±R (8 cm / 12 cm disc) Video mode and finalized only. Indicates tip and hints for making the task easier. DVD-RW (8 cm / 12 cm disc) > Caution Video mode and finalized only. DVD+R: Video mode only Indicates cautions for preventing possible damages from abuse. Supports the double layer disc also. -
Page 8: Playable File Requirement
Getting Started Playable file DivX file requirement DivX file compatibility with this unit is limited as Requirement follows: y Available resolution: within 720 x 576 (W x H) pixels. MP3/ WMA music file requirement y The file name of the DivX subtitle should be entered within 45 characters. MP3/ WMA file compatibility with this unit is limited as follows : y If there is impossible code to express in the DivX file, it may be displayed as “ _ “ mark on the y Sampling frequency : within 32 to 48 kHz (MP3), display. within 32 to 48 kHz (WMA) y Frame rate : less than 30 fps. y Bit rate : within 32 to 320 kbps (MP3), 40 to 192 kbps (WMA) y If the video and audio structure of recorded files is not interleaved, either video or audio is y Support Version : v2, v7, v8, v9 outputted. -
Page 9: Remote Control
• • • • • • f • • • • • TITLE: If the current DVD title has TV Control buttons: Controls the a menu, the title menu appears TV. (LG TV only) on the screen. Otherwise, the disc - You can control the sound menu may not appear. level, input source, and power switching of LG TVs as well. • • • • • • c • • • • •... -
Page 10: Front Panel
Getting Started Front panel a k j i h g f e a 1/! (POWER) g Z (STOP) Switches the unit ON or OFF. Stops playback. b Disc Tray h z/M (PLAY/PAUSE) Starts playback. c Display window Pauses playback temporarily, press again to exit Shows the current status of the unit. pause mode. d VOLUME i B (OPEN/CLOSE) Adjusts speaker volume. Opens or closes the disc tray. e F (FUNCTION) j USB Port Changes the input source or function. Connects a USB device. f C/V,(SKIP) k PORT. IN Go to next or previous file/track/chapter. -
Page 11: Rear Panel
Getting Started Rear panel h g f a Power cord e HDMI OUT Connects to TV with HDMI inputs. b Speakers connectors (Interface for digital audio and video) Connects the speaker cables. f OPTICAL IN c Cooling Fan Connects to optical audio equipment. d VIDEO OUT g COMPONENT VIDEO (Y P )OUTPUT Connects to a TV with video inputs. (PROGRESSIVE SCAN) Connects to a TV with Y P inputs. h AUX (L/R) INPUT Connects to an external source with 2 channel audio outputs. HT906TA-N0_BTURLLK_ENG_6156.indd 11 2011-12-13 5:17:03... -
Page 12: Connecting
Connecting Assembling the 2. Secure the connection with a supplied screw, then insert a speaker wire from the bottom of speaker the base. Before connecting the speakers, assemble the speakers. Please check the items for assembling the speakers. Preparation (Big screw) Pole 3. Attach the speakers to the speaker stands by rotating the screws. Base Screw (Small screw) Cable Speaker 1. Attach the pole to the base, then secure the connection with a supplied screw. (Small screw) HT906TA-N0_BTURLLK_ENG_6156.indd 12 2011-12-13 5:17:04... - Page 13 Connecting > Caution 4. Connect the speaker wire to the terminal on the speaker. Be careful that the speaker does not fall down. Make sure the wire marked black goes in to the Otherwise it may result in terminal marked “–” (minus) and the other wire the speaker malfunctioning goes in to the terminal marked and causing personal injury “+” (plus). and/ or property damage. HT906TA-N0_BTURLLK_ENG_6156.indd 13 2011-12-13 5:17:04...
-
Page 14: Attaching The Speakers To The Unit
Connecting Attaching the speakers Color Speaker Position to the unit Grey Rear Rear right Blue Rear Rear left 1. Connect the wires to the unit. Green Center Center Match each wire’s colored band to the same Orange Sub woofer Any front position colored connection terminal on the rear of the unit. To connect the cable to the unit, press Front Front right each plastic finger pad to open the connection terminal. Insert the wire and release the finger White Front Front left pad. To connect the cable to the speakers, press each plastic finger pad to open the connection terminals on the base of each speaker. Insert the wire and release the finger pad. > Caution y Be careful to make sure children do not put their hands or any objects into the *speaker... -
Page 15: Positioning The System
Connecting Positioning the system F ront left speaker (L)/ Front right speaker (R): Place the front speakers to the sides of the monitor or screen and as flush with the screen The following illustration shows an example of surface as possible. positioning the system. Note that the illustrations C enter speaker: Place the center speaker above in these instructions differ from the actual unit for or below the monitor or screen. explanation purposes. S urround left speaker (L)/ Surround right For the best possible surround sound, all the speaker (R): speakers other than the subwoofer should be Place these speakers behind your listening placed at the same distance from the listening position, facing slightly inwards. position ( ). S ubwoofer: The position of the subwoofer is not so critical, because low bass sounds are not highly directional. But it is better to place the subwoofer near the front speakers. Turn it slightly toward the center of the room to reduce the wall reflections. Unit HT906TA-N0_BTURLLK_ENG_6156.indd 15 2011-12-13 5:17:05... -
Page 16: Connections To Your Tv
Connecting Connections to Your Component Video Connection Connect the COMPONENT VIDEO OUTPUT (PROGRESSIVE SCAN) jacks on the unit to the corresponding input jacks on the TV using component cables. Make one of the following connections, depending on the capabilities of your existing equipment. You can hear the sound through the system’s Note speakers. y Depending on your TV and other equipment you wish to connect, there are various ways you could connect the player. Use only one of the connections described Unit in this manual. y Please refer to the manuals of your TV, Stereo System or other devices as necessary to make the best connections. > Caution y Make sure the unit is connected directly to the TV. Tune the TV to the correct video input channel. y Do not connect your player via your VCR. The image could be distorted by the copy protection system. Green Blue HT906TA-N0_BTURLLK_ENG_6156.indd 16 2011-12-13 5:17:05... -
Page 17: Hdmi Out Connection
Connecting Note HDMI Out Connection y If a connected HDMI device does not accept If you have a HDMI TV or monitor, you can connect the audio output of the unit, the HDMI it to this unit using a HDMI cable (Type A, High device’s audio sound may be distorted or Speed HDMI™ Cable). may not output. Connect the HDMI OUT jack on the unit to the y When you connect a HDMI or DVI HDMI IN jack on a HDMI compatible TV or monitor. compatible device make sure of the Set the TV’s source to HDMI (refer to TV’s Owner’s following: manual). - T ry switching off the HDMI/DVI device and this unit. Next, switch on the HDMI/ DVI device and leave it for around 30 seconds, then switch on this unit. Unit - T he connected device’s video input is set correctly for this unit. - T he connected device is compatible with 720 x 480i (or 576i), 720 x 480p (or 576p), 1 280 x 720p, 1920 x 1080i or 1920 x 1080p video input. y Not all HDCP-compatible HDMI or DVI devices will work with this unit. -
Page 18: Video Connection
Connecting Video Connection Connect the VIDEO OUT jack on the unit to the video in jack on the TV using a video cable. You can hear the sound through the system’s speakers. Unit Yellow HT906TA-N0_BTURLLK_ENG_6156.indd 18 2011-12-13 5:17:06... -
Page 19: Resolution Setting
Connecting Video Output Resolution Setting Resolution The unit provides several output resolutions for HDMI OUT and COMPONENT VIDEO OUT jacks. You can change the resolution using [Setup] menu. Displayed resolution in display window and 1. Press n HOME. outputted resolution may different according to 2. Use A/D to select the [Setup] and press b connection type. ENTER. The [Setup] menu appears. [HDMI OUT]: 1080p, 1080i, 720p and 480p (or 576p) and 480i (or 576i) [COMPONENT VIDEO OUT]: 480p (or 576p) and 480i (or 576i) [VIDEO OUT]: 480i (or 576i) 3. Use W/S to select [Display] option then press D to move to the second level. 4. Use W/S to select the [Resolution] option then press D to move to the third level. 5. Use W/S to select the desired resolution then press b ENTER to confirm your selection. Note If your TV does not accept the resolution you have set on the player, you can set resolution to 480p (or 576p) as follows: Press Z STOP for more than 5 seconds. HT906TA-N0_BTURLLK_ENG_6156.indd 19 2011-12-13 5:17:06... -
Page 20: Optional Equipment Connection
Connecting Optional Equipment AUDIO (PORT. IN) In Connection Connection Connect an output of portable device (MP3 or PMP etc) to the AUDIO (PORT. IN) input connector. AUX In Connection Connect an Output of auxiliary device to the AUX (L/R) INPUT Connector. MP3 player, etc... Unit Listening to music from your portable player or external device The unit can be used to play the music from many types of portable player or external devices. 1. Connect the portable player to the To the audio output jacks PORT. IN (PORTABLE IN) connector of the unit. of your component (TV, VCR, etc.) Connect the external device to the AUX connector of the unit. -
Page 21: Usb Connection
Connecting USB Connection Compatible USB Devices y MP3 Player : Flash type MP3 player. Connect the USB port of USB Memory (or MP3 player, etc.) to the USB port on the front of the unit. y USB Flash Drive : D evices that support USB2.0 or USB1.1. y The USB function of this unit does not support some USB devices. USB device requirement y Devices which require additional program installation connected to a computer, are not supported. y Do not extract the USB device while in operation. y For a large capacity USB, it may take longer than a few minute to be searched. Removing the USB Device from the unit y To prevent data loss, back up all data. 1. Choose a different function mode or press Z STOP twice in a row. y If you use a USB extension cable or USB hub, the 2. Remove the USB device from the unit. USB device is not recognized. -
Page 22: Optical In Connection
Connecting OPTICAL In connection Connect an optical output of Unit (or Digital Device etc) to the OPTICAL IN connector. To the digital optical output jack of your component Home theater speaker ez setup Listen to sound from TV, DVD and Digital Device with 5.1(2.1 or 2)ch mode. Even in power off mode, if you press OPTICAL, then power is on and automatically changed to AUX OPT mode. 1. Connect the unit’s OPTICAL IN jack to jack on optical out of your TV (or Digital Device etc.). 2. Select the AUX OPT by using the OPTICAL. To select the AUX OPT directly. 3. Listen sound with 5.1(2.1 or 2)ch speaker. 4. To escape from AUX OPT by using the OPTICAL. Function is retuned to previous one. HT906TA-N0_BTURLLK_ENG_6156.indd 22 2011-12-13 5:17:06... -
Page 23: System Setting
System Setting Adjust the setup To display and exit the Setup menu settings 1. Press n HOME. Displays the [Home Menu]. By using the Setup menu, you can make various adjustments to items such as picture and sound. You can also set a language for the subtitles and the Setup menu, among other things. For details on each Setup menu item, see pages 23 to 28. 2. Select an [Setup] by using AD. OSD Initial language settings 3. Press b ENTER. - Optional Displays the [Setup]. 4. Press n HOME or x RETURN to exit in the During the first use of this unit, the initial language [Setup] Menu. setup menu appears on your TV screen. You must About help menu for Setup complete initial language selection before using the unit. English will be selected as the initial Menu... -
Page 24: Language
System Setting Language [Panscan] Automatically displays the wide picture on the Menu Language entire screen and cuts off the portions that do not fit. (If the disc/file is not compatible with Select a language for the Setup menu and then on Pan Scan, the picture is displayed at Letterbox screen display. ratio.) Disc Audio / Disc Subtitle / Disc Resolution Menu Sets the output resolution of the Component and Select the language you prefer for the audio track HDMI video signal. Refer to “Resolution Setting” for (disc audio), subtitles, and the disc menu. details about the resolution (page 19). [Original] [Auto] Refers to the original language in which the If the HDMI OUT jack is connected to disc was recorded. TVs providing display information (EDID), [Other] automatically selects the resolution best suited to the connected TV. If the COMPONENT To select another language, press numeric VIDEO OUT is only connected, this changes the buttons and then b ENTER to enter the resolution to 480i (or 576i) as default resolution. corresponding 4-digit number according to the language code list on the page 39. If you [1080p]... -
Page 25: Audio
System Setting Audio [Speaker] Select a speaker that you want to adjust. 5.1 Speaker Setup Note Certain speaker settings are prohibited by the Make the following settings for the built-in 5.1 Dolby Digital licensing agreement. channel surround decoder. 1. Select [5.1 Speaker Setup] on the [Audio] menu. 2. Press b ENTER. [Size] The [5.1 SPEAKER] appears. Since the speaker settings are fixed, you cannot change the settings. [Volume] Press AD to adjust the output level of the selected speaker. Front L/R : 0 - -5 SubWoofer, Rear L/R, Center : 5 - -5 [Distance] 3. Use AD to select the desired speaker. After you connected speakers to your unit, 4. Adjust options using WSAD buttons. set the Distance between the speakers and your listening point if the distance of Center 5. Returns to the previous menu by pressing x or Rear speakers is bigger than the distance RETURN. of Front speakers. This allows the sound from each speaker to reach the listener at the same time. Press AD to adjust the Distance of the selected speaker. This distance is equivalent to a difference of the distance between Center or... -
Page 26: Lock (Parental Control)
System Setting Lock (Parental Control) DRC (Dynamic Range Control) Make the sound clear when the volume is turned down (Dolby Digital only). Set to [On] for this effect. Initial Setting the Area Code: When you use this unit for the first time, you have Vocal to set the Area Code. Select [On] to mix karaoke channels into normal 1. Select the [Lock] menu and then press D. stereo. 2. Press D. This function is effective for multi-channel karaoke To access the [Lock] options, you must input the DVDs only. password you have created. Input a password and press b ENTER. Enter it again and press b HD AV Sync ENTER to verify. If you make a mistake before pressing b ENTER, press CLEAR. Sometimes Digital TV encounters a delay between 3. Select the first character using WS buttons. picture and sound. If this happens you can compensate by setting a delay on the sound so 4. Press b ENTER and select the second character that it effectively ‘waits’... -
Page 27: Others
System Setting Others Password You can enter or change password. DivX VOD 1. Select [Password] on the [Lock] menu and then press D. We provide you with the DivX® VOD (Video On 2. Press b ENTER. Demand) registration code that allows you to rent and purchase videos using the DivX® VOD service. 3. Input a password and press b ENTER. For more information, visit www.divx.com/vod. To change the password, press b ENTER when the [Change] option is highlighted. Input a [Register] password and press b ENTER. Enter it again Displays the registration code of your player. and press b ENTER to verify. 4. Press n HOME to exit the menu. [Deregister] Note Deactivate your player and display the deactivation code. If you forget your password, you can clear it using the following steps: Note 1. Select the [Setup] menu on the [Home All the downloaded videos from DivX VOD can Menu]. only be played back on this unit. 2. Input the 6-digit number “210499” and press b ENTER. The password is cleared. -
Page 28: Operating
Operating Using the Home Menu Basic Operations 1. Press n HOME. 1. Insert the disc by using the B OPEN/CLOSE or Displays the [Home Menu]. Connect the USB device to the USB port. 2. Press n HOME. Displays the [Home Menu]. 3. Select an option by using AD. If you select the [Movie], [Photo] or [Music] option when you connect up to two devices, 2. Select an option by using AD. it appears as belows. Select a media then press 3. Press b ENTER then selected option menu. b ENTER. [Music] – Displays [MUSIC] menu. [Movie] – S tart video media’s playback or displays the [MOVIE] menu. 4. Press b ENTER then selected option menu. [Photo] – Displays [PHOTO] menu. Note [Setup] – Displays the [Setup] menu. y For the most Audio CD and DVD-ROM discs, Note playback starts automatically. You can not select the [Music], [Movie] or y The unit plays only music file contained in [Photo] option when the USB device is not... -
Page 29: Other Operations
Operating Other Operations Do this Stop Press Z STOP. Displaying Disc Information Press d PLAY. Playback on-screen Pause Press M PAUSE/STEP. You can display various information about the disc Press M PAUSE/STEP Frame-by- loaded on-screen. repeatedly to play title Frame- Frame playback by-Frame. (DVD, DivX only) 1. Press m INFO/DISPLAY to show various playback information. During playback, press C/, The displayed items differ depending on the V SKIP to go to the next disc type or playing status. chapter/ track/ file or to Skipping to the 2. You can select an item by pressing WS,and return to the beginning of the next/ previous change or select the setting by pressing AD. -
Page 30: To Display The Dvd Menu
Operating To display the DVD Menu Starting play from selected time When you play a DVD which contains several menu, you can select the menu you want using the Menu. To start playing at any chosen time on the file or 1. Press DISC MENU. title. The disc’s menu appears. 1. Press m INFO/DISPLAY during playback. 2. Select the menu by using WSAD. 2. Press WS to select the time clock icon and 3. Press d PLAY to confirm. “--:--:--” appears. 3. Input the required start time in hours, minutes, To display the DVD title and seconds from left to right. If you enter the wrong numbers, press CLEAR to remove the numbers you entered. Then input the correct When you play a DVD which contains several title, numbers. you can select the title you want using the Menu. -
Page 31: Marked Playback
Operating Marked Playback To delete a Marker 1. Use to select the track that you wish to erase from the marked file. The mark function enables you to store your 2. Press MARKER. favourite files from any disc or USB device in the unit memory. To delete all Markers 1. Select [Music] on the [Home Menu]. Use WSAD to select [Deselect All] then press b Returning to the upper folder. ENTER in program edit mode. (MP3/ WMA only) Note File information will be displayed The markers are also cleared when the disc or according to the ID3TAG information USB device is removed, the unit is switched to on the appropriate music file. (MP3 power off or the function is switched to others. only) Selecting all tracks/ files. Deselecting all tracks/files. Moving to the previous or next file list. 2. Select a desired music on the [List] by using the then press MARKER to appears the mark on the list. -
Page 32: Viewing A Photo File
Operating Viewing a PHOTO file About help menu in the full screen Menu Buttons Operation This unit can play discs with photo files. Displaying the Option Menu INFO/ 1. Select [Photo] on the [Home Menu] and press menu. DISPLAY b ENTER. Moving to another file. Prev./ Next Moving to the previous or next file list. Returning to the RETURN Close [Photo] menu. Options while viewing a photo You can use various options during viewing a photo in full screen. 1. While viewing a photo in full screen, press m INFO/DISPLAY to display the option menu. -
Page 33: Sleep Timer Setting
Operating Sleep Timer Setting Adjust the speaker level settings Press SLEEP one or more times to select delay time between 10 and 180 minutes, after the unit will You can adjust the sound level of each speaker. turn off. 1. Press SPEAKER LEVEL repeatedly to select a To check the remaining time, press SLEEP. desired speaker to set. To cancel the sleep function, press SLEEP 2. Press VOL -/+ to adjust the sound level of the repeatedly until “SLEEP 10” appears, and then press selected speaker while the level setting memu SLEEP once again while “SLEEP 10” is displayed. is displayed on the display window. Note 3. Repeat and adjust the sound level of the other You can check the remaining time before the speakers. Unit turns off. Press SLEEP The remaining time appears in the display window. Dimmer Press SLEEP once. The display window will be darken by half. To cancel it, press SLEEP repeatedly until dim off. Turn off the sound temporarily Press MUTE to mute your unit. -
Page 34: Sound Adjustment
Operating Sound adjustment On Display Description The GAME is Game Equalizer. You can enjoy more virtual GAME Setting the surround mode sound while playing video games. This system has a number of pre-set surround sound fields. You can select a desired sound mode The NIGHT is Night Mode. by using SOUND EFFECT. This may be useful when you NIGHT want to watch movies at low You can change the SOUND EFFECT using AD volume late at night. arrow key while the sound effect information is displayed on. The RETOUCH is MP3 Up- The displayed items for the equalizer maybe Scaling. When listening to different depending on sound sources and effects. MP3 files or other compressed RETOUCH music, you can enhance the On Display Description sound. This mode is available only to 2 channel sources. The NAT PLUS is Natural Plus sound effect. You can enjoy Improves the bass and treble... -
Page 35: Advanced Operations
Operating Note Advanced Operations y You can check the recording percentage rate for the USB record on the screen during the recording. (Audio CD or MP3/ WMA CD Recording to USB only) y During recording MP3/WMA, there is no You can record music or sound souce to USB device sound. by connecting in to the port on the unit. y When you stop recording during playback, 1. Connect the USB device to the unit. the file that has been recorded at that time 2. Select a mode in which you want to record. will be stored. (Audio CD only) Play back a sound source first. y Do not remove the USB device or turn 3. Start the recording by pressing X REC. off the unit during USB recording. If not, 4. To stop recording, press Z STOP. an incomplete file may be made and not deleted on PC. [All tracks/ files recording] y If USB recording does not work, the Record to USB in stop or play mode. -
Page 36: Troubleshooting
Troubleshooting Troubleshooting PROBLEM CORRECTION No power Plug the power cord into the wall outlet securely. Select the appropriate video input mode on the TV so the picture from the unit appears on the TV screen. No picture Connect the video cables securely to both the TV and unit. Select the correct input mode of the unit so you can hear the sound from the unit. There is little or no sound Connect the audio cables into the connection terminals correctly. Replace with a new audio cable. Clean the disc using a soft cloth with outward strokes. The DVD picture quality is poor Insert a disc. Insert a playable disc (check the disc type, colour system and regional code). A DVD/CD will not play Place the disc with the label or printed side facing upwards. Enter your password or change the rating level. Clean the disc using a soft cloth with outward strokes. Humming noise heard while a DVD or CD is playing Move unit and audio components further away from your TV. The remote is not pointed directly at the unit. Point the remote directly at the unit. The remote is too far from the unit. Use the remote within 23 feet (7m) of the unit. The remote control doesn’t work There is an obstacle in the path between the remote control and well / at all the unit. Remove the obstacle. The battery in the remote control are flat. Replace the battery with new ones. HT906TA-N0_BTURLLK_ENG_6156.indd 36 2011-12-13 5:17:08... -
Page 37: Appendix
Appendix Maintenance Notes on Discs Handling Discs Handling the Unit Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints do not get on the surface. Never stick paper or tape on the When shipping the unit disc. Please save the original shipping carton and packing materials. If you need to ship the unit, for Storing Discs maximum protection, re-pack the unit as it was After playing, store the disc in its case. Do not originally packed at the factory. expose the disc to direct sunlight or sources of heat Keeping the exterior surfaces clean and never leave it in a parked car exposed to direct y Do not use volatile liquids such as insecticide sunlight. spray near the unit. y Wiping with strong pressure may damage the Cleaning Discs surface. Fingerprints and dust on the disc can cause poor y Do not leave rubber or plastic products in picture quality and sound distortion. Before playing, contact with the unit for a long period of time. -
Page 38: Area Code List
Appendix Area Code List Choose an area code from this list. Area Code Area Code Area Code Area Code Afghanistan Fiji Monaco Singapore Argentina Finland Mongolia Slovak Republic Australia France Morocco Slovenia Austria Germany Nepal South Africa Belgium Great Britain Netherlands South Korea Bhutan Greece Antilles Spain Bolivia Greenland New Zealand Sri Lanka Brazil Hong Kong... -
Page 39: Language Code List
Appendix Language code List Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu]. Language Code Language Code Language Code Language Code Afar 6565 French 7082 Lithuanian 7684 Sindhi 8368 Afrikaans 6570 Frisian 7089 Macedonian 7775 Singhalese 8373 Albanian 8381 Galician 7176 Malagasy 7771 Slovak 8375 Ameharic 6577 Georgian 7565 Malay... -
Page 40: Trademarks And Licenses
Certified® device must be registered in order to play purchased DivX Video-on-Demand (VOD) HDMI, the HDMI logo and High-Definition movies. To obtain your registration code, locate Multimedia Interface are trademarks or registered the DivX VOD section in your device setup menu. trademarks of HDMI licensing LLC. Go to vod.divx.com for more information on how to complete your registration. “DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation. What is SIMPLINK? Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; Some functions of this unit are controlled by 6,487,535 & other U.S. and worldwide patents TV’s remote control when this unit and LG TV issued & pending. DTS and the Symbol are reg- with SIMPLINK are connected through HDMI istered trademarks & DTS Digital Surround and connection. Controllable functions by LG TV’s the DTS logos are trademarks of DTS, Inc. Product remote control; Play, Pause, Scan, Skip, Stop, includes software. © DTS, Inc. All Rights Reserved. Power Off, etc. y Refer to the TV owner’s manual for the details of SIMPLINK function. y LG TV with SIMPLINK function has the logo as shown above. y Use a higher version cable than High Speed HDMI™ Cable. HT906TA-N0_BTURLLK_ENG_6156.indd 40 2011-12-13 5:17:08... -
Page 41: Specifications
Appendix Specifications General Power requirements Refer to main label. Power consumption Refer to main label. Dimensions (W x H x D) 430 X 60 X 310 mm without foot Net Weight (Approx.) 4.0 kg Operating temperature 41 °F to 95 °F (5 °C to 35 °C) Operating humidity 5 % to 90 % Bus Power Supply (USB) DC 5 V 0 500 mA Inputs/ Outputs VIDEO OUT 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1 (Y) 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1 COMPONENT VIDEO OUT (Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2 HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector ) ANALOG AUDIO IN 2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1 DIGITAL IN (OPTICAL) 3 V (p-p), Optical jack x 1 PORT. IN 0.5Vrms (3.5 mm stereo jack) Amplifier Stereo mode 180 W + 180 W (4 Ω at 1kHz) Front 180 W + 180 W (4 Ω at 1 kHz) Center 180 W (4 Ω at 1 kHz) Surround mode Surround 180 W + 180 W (4 Ω at 1 kHz) Subwoofer... - Page 42 Appendix Front Speaker Type 2 Way 3 speaker Impedance Rated 4 Ω Input Power 180 W Max. Input Power 360 W Net Dimensions (W x H x D) 280 X 1 152 X 225 mm Net Weight 3.33 kg Rear Speaker Type 2 Way 3 speaker Impedance Rated 4 Ω Input Power 180 W Max. Input Power 360 W Net Dimensions (W x H x D) 280 X 1 152 X 225 mm Net Weight 3.33 kg Centre Speaker Type 2 Way 3 speaker Impedance Rated 4 Ω Input Power 180 W Max. Input Power 360 W Net Dimensions (W x H x D) 327 x 99 x 76 mm Net Weight 1.21 kg...
- Page 43 HT906TA-N0_BTURLLK_ENG_6156.indd 43 2011-12-13 5:17:08...
