- Page 1 PN-HS501 Dismantle Instruction LCD MONITOR PN-HS501 MODEL Dismantle Instruction...
- Page 2 PN-HS501 Dismantle Instruction Table of contents 1. Scope........................3 2. Tools for dismantling ....................3 3. Dismantle Procedure ....................3 4. Back covers ......................4 5. Printed circuit boards ..................... 5 6. Battery ........................ 5 7. LCD Module ......................6 8.
- Page 3 PN-HS501 Dismantle Instruction 1. Scope This document describes dismantling instruction according to Annex VII of Directive 2012/19/EU. 2. Tools for dismantling Below tools are required to dismantle this product. Screw Driver Nipper 3. Dismantle Procedure This product can be dismantled by below steps.
- Page 4 PN-HS501 Dismantle Instruction 4. Back covers Back cover can be removed by screw driver.
- Page 5 PN-HS501 Dismantle Instruction 5. Printed circuit boards All PWBs can be removed by screw driver. Main I/F PWB (1pcs) Power PWB (1pcs) T-CON PWB (1pcs) 6. Battery This model uses only AAA battery for remote control. Battery can easily be removed.
- Page 6 PN-HS501 Dismantle Instruction 7. LCD Module LCD Dismantle procedure Remove Rear cover Remove PWBs Remove the Cables...
- Page 7 PN-HS501 Dismantle Instruction 8. Capacitors Electrolyte Capacitors which diameter/height is larger than 25mm is installed on Power PWB. These capacitors can be removed by using nipper to cut the leads. On Power PWB 9. Parts List Parts described in Annex VII of directive 2012/19/EU are as below.
