ETNA EWM247DWIT/E01 Instructions For Use Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Instructions for Use
Washing machine

Advertisement

loading
Need help?

Need help?

Do you have a question about the EWM247DWIT/E01 and is the answer not in the manual?

Questions and answers

Related Manuals for ETNA EWM247DWIT/E01

Summary of Contents for ETNA EWM247DWIT/E01

  • Page 1 Instructions for Use Washing machine...

  • Page 2: Table Of Contents

    Thank you for your confi dence in purchasing our washing machine, and congratulations on the excellent choice. Your new washing machine meets the requirements of modern treatment of laundry. It is rational in the consumption of energy, water and washing agents. Our appliances are friendly to the environment.

  • Page 3: Description Of Washing Machine

    Description of washing machine 1. Front panel 5. Adjustable legs 2. Detergent dispenser 6. Water outlet hose 3. Door 7. Water inlet hose 4. Filter lid 8. Mains power cable Technical information (depending on model) • Max. load: 7 kg /6 kg / 5,5 kg •...

  • Page 4: Cautions

    Cautions • Be sure to remove transport brackets prior fi rst use of the appliance. Attempted operation of the blocked machine may result in irreparable damage which is not covered by the manufacturer’s warranty! • When connecting your washing machine to water supply, be sure to use brand new water inlet hose and appropriate sealing gaskets (attached).

  • Page 5: Installation And Connection

    Installation and connection Package removal In removing the wrapping be careful not to damage the appliance with a sharp object. Before connecting the appliance, let it warm up to room temperature (wait for two hours). • Our appliances are packed in environmentally friendly materials which may be recycled, deposited or decomposed without any threat to the environment.
  • Page 6 • If you have a tumble dryer of the same dimensions, you can place it on top of the washing machine. Water inlet connection To ensure correct operation of the appliance, water pressure inlet must be between 0,05 and 0,8 MPa. Minimum water pressure can be established by measuring the quantity of poured out water.
  • Page 7 Water outlet connection • Fix the outlet hose to run into the sink or the bathtub, or connect it directly to the wall drain outlet (diameter min. 4 cm). • Wall drain must be installed properly and must enable occasional cleaning. •...

  • Page 8: Operation

    Operation A - program selector knob Signal LED’s: B - key - selection of spinning speed (rpm) - washing program stages / stop pump • wash + pre-wash C - short program (Quick wash) • rinse D - higher water level (Water plus) •...
  • Page 9 - Open the door of the machine. Door is opened by pulling the handle (lever) on the right hand side of the door towards you. - Sort the laundry by the type of fabrics. Do the buttons and zippers, tie the strings and pull out the pockets.
  • Page 10 The Cotton 15° program is intended for washing less soiled laundry, using detergents (washing gels) specially designed for washing at such temperatures. Using this program will save you both time and power as water heater will only be engaged if the water inlet temperature is lower than 15°C.
  • Page 11 The display will turn on again when you rotate the program selector dial or press any button. If no action is taken after the end of the program, the display will also turn off after fi ve minutes. Washing stage signal lamps and the START/PAUSE key fl ash intermittently.
  • Page 12 Short program (Quick wash) (selection with a button (C)) • energy-saving program • appropriate for washing lightly soiled laundry or smaller quantities of clothes • reduces washing and rinsing time • reduces water consumption (with some programs) • by pressing the key quick program on the program Cotton 30°C, activate the program Cotton 30°C-quick Higher water level (Water plus) (selection with a button (D))
  • Page 13 - Adding washing and softening agents (see Tips for washing and energy saving) • pre-wash compartment • main wash compartment • softener compartment If you do not apply the program which includes the pre-wash feature, you may add washing detergent directly into the drum, using the measuring vessel.
  • Page 14 • After the end of washing program, power supply should be turned off by pulling the mains cord plug out of the outlet. Interruptions • By the user Selecting PUMP STOP function If the setting pump stop was selected, the program stops at the last rinsing cycle and the symbol for pump stop is indicated on the display.

  • Page 15: Tips For Washing And Energy Saving

    Tips for washing and energy saving • Before washing sort out the laundry according to the type, degree of dirtiness and color resistance. • Prior selecting the washing program consult the sewn tab with information on a particular piece of laundry (see Maintenance Chart on the last page).

  • Page 16: Cleaning And Maintenance

    • High spin RPM leave less moisture in laundry which dries out much quicker in the tumble dryer, thereby saving energy. Do not put clods of detergent into the soap dispenser as the tube in the washing machine may clog. Cleaning and maintenance Disconnect the washing machine from the mains before cleaning!
  • Page 17 • Wash it under running water using a brush, and dry it. Remove any leftover dried detergent from the bottom of the casing. • Clean the entire rinsing area of the washing machine with a brush, especially the nozzles on the upper side of the rinsing chamber.

  • Page 18: Troubleshooting

    • Carefully turn the fi lter insert in anticlockwise direction and let the water slowly drain; then remove the fi lter and clean it under running water. • Insert the fi lter back as shown on the picture, and tighten by turning it in clockwise direction.
  • Page 19 Various interferences from the environment (e.g. electric devices) may also cause the machine to signal faults. In such case: - turn off the appliance and wait a few seconds; - turn on the appliance and repeat the washing program. If the fault reoccurs, call the service center. The warranty does not cover faults caused by interference from the environment (lightning strike, electric circuit, natural disasters, etc.).
  • Page 20 Failure Possible cause Remedy FAILURE 7 Water is poorly pumped Water outlet is clogged Check if: out or not at all (machine • the fi lter is clean, reports failure - the LEDs • outlet pipe is not jammed, periodically fl ash seven •...
  • Page 21 Failure Possible cause Remedy FAILURE 1 Program temperature not Temperature sensor disconnected • Turn off the appliance and wait for reached (the machine from the electronic circuit. a few seconds; reports a failure - the • turn the appliance back on and LEDs periodically fl...

  • Page 22: Tables

    Tables Program chart - 7 kg (A-30%)n Water Energy cons. cons. Basic programs [kWh] Cotton 59-44 2,10 Cotton* 7/3,5** 59-44 164/164** 49/40** 0,89/0,71** 1000- Cotton + prewash 59-44 1,40 1400 Cotton* 7/3,5** 59-44 151/151** 49/40** 0,68/0,59** Cotton 59-44 0,35 Cotton - quick 17’ 1000 0,17 Cotton - Tap water +...
  • Page 23 Program chart - 6 kg (A-20%)n Water Energy cons. cons. Basic programs [kWh] Cotton 62-44 2,05 Cotton* 6/3** 62-44 164/164** 50/35** 0,89/0,71** 800- Cotton + prewash 62-44 1,34 1400 Cotton* 6/3** 62-44 151/151** 50/36** 0,66/0,59** Cotton 62-44 0,27 Cotton - quick 17’ 1000 0,17 Cotton - Tap water +...
  • Page 24 Program chart - 6 kg (A-10%)n Water Energy cons. cons. Basic programs [kWh] Cotton 62-44 2,05 Cotton* 6/3** 62-44 164/164** 0,98/0,95** 800- Cotton + prewash 62-44 1,34 1400 Cotton* 6/3** 62-44 151/151** 0,66/0,59** Cotton 62-44 0,27 Cotton - quick 17’ 1000 0,17 Cotton - Tap water +...
  • Page 25 Program chart - 5,5 kg (A-10%)n Water Energy cons. cons. Basic programs [kWh] Cotton 62-44 2,00 Cotton* 5,5/2,75** 62-44 164/164** 0,93/0,90** 800- Cotton + prewash 62-44 1,34 1400 Cotton* 5,5/2,75** 62-44 151/151** 0,56/0,49** Cotton 62-44 0,27 Cotton - quick 17’ 1000 0,17 Cotton - Tap water +...
  • Page 26 Program chart - 5 kg (A-20%)n (slim) Water Energy cons. cons. Basic programs [kWh] Cotton 62-50 1,95 Cotton* 5/2,5** 62-50 157/157** 42/39** 0,68/0,62** 800- Cotton + prewash 62-50 0,99 1400 Cotton* 5/2,5** 62-50 147/147** 42/38** 0,55/0,52** Cotton 62-50 0,15 Cotton - quick 17’ 1000 0,13 Cotton - Tap water +...
  • Page 27 Program chart - 5 kg / 4,5 kg (slim) (A-10%) Water cons. Energy cons. [kWh] Basic programs 4,5kg 4,5kg 4,5kg Cotton 62-50 1,95 1,80 4,5 / 0,89 / 0,80 / Cotton* 62-50 157/157** 2,5** 2,25** 39** 0,71** 0,69** 800- Cotton + prewash 62-50 0,99 0,99...
  • Page 28 Program chart / Additional functions Program Basic programs Cotton /   Cotton with prewash /  Synthetics /   Delicate /   Wool /   /   Partial programs Softening (Conditioner)  Pumping water (Drain) Spinning ...
  • Page 29 Maintenance chart Normal wash Max. Max. Max. Max. washing washing washing washing temp. temp. temp. Washing temp. 95°C Manual 60°C 40°C 30°C Delicate wash washing allowed Whitening Whitening in cold water Whitening not allowed Ironing Hot iron max. Hot iron max. Hot iron max.
  • Page 32 PS PG0A LED ETN en (12-13)
