Summary of Contents for ETNA EWM246KWIT

  • Page 1 Instructions for Use Washing machine...

  • Page 2: Table Of Contents

    Thank you for your confi dence in purchasing our washing machine, and congratulations on the excellent choice. Your new washing machine meets the requirements of modern treatment of laundry. It is rational in the consumption of energy, water and washing agents. Our appliances are friendly to the environment.

  • Page 3: Description Of Washing Machine

    Description of washing machine 1. Front panel 5. Adjustable legs 2. Detergent dispenser 6. Water outlet hose 3. Door 7. Water inlet hose 4. Filter lid 8. Mains power cable Technical information (depending on model) • Max. load: 7 kg / 6 kg / 5,5 kg •...

  • Page 4: Cautions

    Cautions • Be sure to remove transport brackets prior fi rst use of the appliance. Attempted operation of the blocked machine may result in irreparable damage which is not covered by the manufacturer’s warranty! • When connecting your washing machine to water supply, be sure to use brand new water inlet hose and appropriate sealing gaskets (attached).

  • Page 5: Installation And Connection

    Installation and connection Package removal In removing the wrapping be careful not to damage the appliance with a sharp object. Before connecting the appliance, let it warm up to room temperature (wait for two hours). • Our appliances are packed in environmentally friendly materials which may be recycled, deposited or decomposed without any threat to the environment.
  • Page 6 • If you have a tumble dryer of the same dimensions, you can place it on top of the washing machine. Water inlet connection To ensure correct operation of the appliance, water pressure inlet must be between 0,05 and 0,8 MPa. Minimum water pressure can be established by measuring the quantity of poured out water.
  • Page 7 Do not immerse the Aqua-stop system inlet pipe into the water, because it contains the electric valve! Water outlet connection • Fix the outlet hose to run into the sink or the bathtub, or connect it directly to the wall drain outlet (diameter min. 4 cm). •...

  • Page 8: Operation

    Operation A - program selector Signal LED’s: B - decreasing the spinning rpm or turning - washing program stages the spinning cycle off • wash + pre-wash C - short program knob • rinse D - elevated water level knob •...
  • Page 9 Washing procedure • Open the door of the machine. • Load the laundry into the drum. • Close the door. • Open the water inlet faucet. • Push the ON/OFF button and select the program. • Add washing and treatment agents (detergent and softener). •...
  • Page 10 To wash heavily soiled laundry that will not discolor, use the program with a prewash For smaller loads (non-delicate cotton, linen, synthetic, and mixed fabric) and smaller quantities of soiled laundry (laundry refreshment, laundry wet with perspiration, etc.), we recommend the use of the quick program.
  • Page 11 Reduced spin RPM • Reduction of spin RPM depends on program selection and maximum RPM for particular type of machine. Basic programs Spin speed - RPM max. reduced Cotton 1400/1300 1200/1100 1000/900/800 Synthetics , Mix 1000/800 Delicate Wool Spin OFF (RPM max. 700 RPM). This knob switches off spin on all programs.
  • Page 12 Pumping the water out (Draining) Use it when the washing program was interrupted or if pump stop function was engaged, and you only wish to pump the water out of the drum, without spinning. Spinning Aggressive spinning for non-delicate laundry at high spin RMP. Spinning rpm can be decreased by pressing the ( ) key - selection of spinning speed (rpm).
  • Page 13 - End of operation Flashing LED’s for particular washing stages indicate that the program was completed. • Washing machine door can be opened. • Extract the laundry from the drum and remove any alien objects from the door gasket. • Leave the door ajar to allow the interior to dry. •...

  • Page 14: Tips For Washing And Energy Saving

    If no program is selected and started and no other action is taken within fi ve minutes after turning on the machine, the machine will be automatically turned off to save energy. If no action is taken after the end of the program (e.g. if the door is not opened, etc.), the machine will also turn off after fi...
  • Page 15 Hardness Degree of hardness scale °dH(°N) m mol/l °fH(°F) p.p.m. 1 - Soft < 8,4 < 1,5 < 15 < 150 2 - Medium 8,4 - 14 1,5 - 2,5 15 - 25 150 - 250 3 - Hard > 14 >...

  • Page 16: Cleaning And Maintenance

    Cleaning and maintenance Disconnect the washing machine from the mains before cleaning! • The casing should be cleaned with soft cloth and mild detergent. • The interior of the drum and the door gasket is cleaned by washing at 60°C without laundry and adding half quantity of detergent.
  • Page 17 • Clean the entire rinsing area of the washing machine with a brush, especially the nozzles on the upper side of the rinsing chamber. • Clean frequently the water inlet hose screen under running water. • After each wash wipe the door rubber gasket. This will prolong its useful life.

  • Page 18: Failures

    • Insert the fi lter back as shown on the picture, and tighten by turning it in clockwise direction. To ensure good sealing the gasket surface (A) must be dirt free. Failures The washing machine automatically monitors the execution of particular functions during the operation, and reports any detected failures.
  • Page 19 Failure Possible cause Remedy The machine does not Machine is not powered. Check if: work (indicator LED’s are • power in the socket, not illuminated). • the fuse is OK, • plug is in the socket. FAILURE 2 Washing program does Door is not properly closed.
  • Page 20 Failure Possible cause Remedy Greasy wads appear on Too little detergent (laundry was Wash the laundry again. the laundry. very greasy). Add more detergent for such soiled laundry, or use liquid detergent. Laundry is stained after You used liquid detergent or Use the detergent containing washing.
  • Page 21 Failure Possible cause Remedy FAILURE 5 Motor operation Motor overload or motor failure. • Turn off the appliance and wait for interrupted; or motor does a few seconds; not operate (the machine • turn the appliance back on and reports a failure - the repeat the washing program.

  • Page 22: Tables

    Tables Program chart - 7 kg (A-30%)n Water Energy cons. cons. Basic programs [kWh] Cotton 59-44 2,10 Cotton* 7/3,5** 59-44 164/164** 49/40** 0,89/0,71** 1000- Cotton + prewash 59-44 1,40 1400 Cotton* 7/3,5** 59-44 151/151** 49/40** 0,68/0,59** Cotton 59-44 0,35 Cotton - quick 17’ 1000 0,17 Cotton - Tap water +...
  • Page 23 Tabella programmi - 6 kg (A-20%)n Water Energy cons. cons. Basic programs [kWh] Cotton 62-44 2,05 Cotton* 6/3** 62-44 164/164** 50/35** 0,89/0,71** 800- Cotton + prewash 62-44 1,34 1400 Cotton* 6/3** 62-44 151/151** 50/36** 0,66/0,59** Cotton 62-44 0,27 Cotton - quick 17’ 1000 0,17 Cotton - Tap water +...
  • Page 24 Program chart - 6 kg (A-10%)n Water Energy cons. cons. Basic programs [kWh] Cotton 62-44 2,05 Cotton* 6/3** 62-44 164/164** 0,98/0,95** 800- Cotton + prewash 62-44 1,34 1400 Cotton* 6/3** 62-44 151/151** 0,66/0,59** Cotton 62-44 0,27 Cotton - quick 17’ 1000 0,17 Cotton - Tap water +...
  • Page 25 Program chart - 5,5 kg (A-10%)n Water Energy cons. cons. Basic programs [kWh] Cotton 62-44 2,00 Cotton* 5,5/2,75** 62-44 164/164** 0,93/0,90** 800- Cotton + prewash 62-44 1,34 1400 Cotton* 5,5/2,75** 62-44 151/151** 0,56/0,49** Cotton 62-44 0,27 Cotton - quick 17’ 1000 0,17 Cotton - Tap water +...
  • Page 26 Program chart - 5 kg (A-20%)n (slim) Water Energy cons. cons. Basic programs [kWh] Cotton 62-50 1,95 Cotton* 5/2,5** 62-50 157/157** 42/39** 0,68/0,62** 800- Cotton + prewash 62-50 0,99 1400 Cotton* 5/2,5** 62-50 147/147** 42/38** 0,55/0,52** Cotton 62-50 0,15 Cotton - quick 17’ 1000 0,13 Cotton - Tap water +...
  • Page 27 Program chart - 5 kg / 4,5 kg (A-10%)n (slim) Water cons. Energy cons. [kWh] Basic programs 4,5kg 4,5kg 4,5kg Cotton 62-50 1,95 1,80 4,5 / 0,89 / 0,80 / Cotton* 62-50 157/157** 2,5** 2,25** 39** 0,71** 0,69** 800- Cotton + prewash 62-50 0,99 0,99...
  • Page 28 Program chart / Additional functions Program Basic programs Cotton    Cotton with prewash   Synthetics    Delicate    Wool       Partial programs Rinse  Softening  Pumping water Spinning ...
  • Page 29 Maintenance chart Normal wash Max. Max. Max. Max. washing washing washing washing temp. temp. temp. Washing temp. 95°C Manual 60°C 40°C 30°C Delicate wash washing allowed Whitening Whitening in cold water Whitening not allowed Ironing Hot iron max. Hot iron max. Hot iron max.
  • Page 32 PS PG0A ETN en (11-13)
