- Page 1 Tumble dryer WT47XM00EU User manual and installation instructions Register your product on My Siemens and discover exclusive services and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
-
Page 2: Table Of Contents
Futher information and explanations are available online: Table of contents 1 Safety .......... 4 9 Programmes ....... 24 1.1 General information.... 4 9.1 Automatic programmes.... 24 1.2 Intended use....... 4 9.2 Timed programmes .... 25 1.3 Restriction on user group... 4 10 Accessories...... 26 1.4 Safe installation ...... 5 1.5 Safe use ........ 7 11 Laundry........ - Page 3 15.2 Preparing the condensation container for the appliance care programme..... 34 15.3 Starting the appliance care programme...... 34 15.4 Running the basic appli- ance care programme on the appliance...... 35 15.5 Preparing the appliance for the intensive appliance care programme..... 36 15.6 Running the intensive appli- ance care programme ... 37 15.7 Ending the intensive appli- ance care programme ... 38...
-
Page 4: Safety
en Safety 1 Safety Observe the following safety instructions. 1.1 General information ¡ Read this instruction manual carefully. ¡ Keep the instruction manual and the product information safe for future reference or for the next owner. ¡ Do not connect the appliance if it has been damaged in transit. 1.2 Intended use Only use this appliance: ¡... -
Page 5: Safe Installation
Safety en 1.4 Safe installation Take note of the safety instructions when installing the appliance. WARNING ‒ Risk of electric shock! Incorrect installation is dangerous. ▶ Connect and operate the appliance only in accordance with the specifications on the rating plate. ▶ Connect the appliance to a power supply with alternating cur- rent only via a properly installed socket with earthing. - Page 6 en Safety ▶ If the power cord is too short and a longer one is not available, please contact an electrician to have the domestic installation adapted. WARNING ‒ Risk of injury! The high weight of the appliance may result in injury when lifted. ▶...
-
Page 7: Safe Use
Safety en CAUTION ‒ Risk of cutting! Touching sharp edges on the appliance may lead to cuts. ▶ Do not touch the sharp edges on the appliance. ▶ Wear protective gloves when installing and transporting the ap- pliance. 1.5 Safe use WARNING ‒ Risk of electric shock! If the appliance or the power cord is damaged, this is dangerous. - Page 8 en Safety WARNING ‒ Risk of explosion! If there is coal dust or flour in the air around the appliance, this may cause an explosion. ▶ Keep the area around the appliance clean during operation. WARNING ‒ Risk of poisoning! Condensation water from this appliance is not suitable for drinking and may be contaminated with fluff.
-
Page 9: Safe Cleaning And Maintenance
Safety en WARNING ‒ Risk of fire! If drying is interrupted early, the laundry is not cooled sufficiently and may ignite. ▶ Do not interrupt the drying programme early. ▶ If drying is interrupted early, remove the laundry immediately and spread it out. CAUTION ‒ Risk of injury! The covering plate may break if you stand on or climb onto the appliance. - Page 10 en Safety WARNING ‒ Risk of injury! The use of non-original spare parts and non-original accessories is dangerous. ▶ Only use the manufacturer's original spare parts and original ac- cessories. WARNING ‒ Risk of poisoning! Poisonous fumes may be given off if you use cleaning agents that contain solvents.
-
Page 11: Preventing Material Damage
Preventing material damage en Do not use hard scouring pads or ▶ 2 Preventing material cleaning sponges. Clean the appliance with nothing damage ▶ but water and a soft, damp cloth. Remove all detergent residue, Follow these instructions to avoid ma- ▶ spray residue or other residues im- terial damage and damage to the ap- mediately if they come into contact... -
Page 12: Energy Saving Mode
en Installation and connection Remove any packaging and pro- Observe the programme's maximum tective covers completely from the load capacity. appliance. → "Programmes", Page 24 → "Disposing of packaging", a If the maximum load is exceeded, Page 11 this extends the programme dura- tion and increases energy con- Check the appliance for visible sumption. -
Page 13: Requirements For The Install- Ation Location
Installation and connection en Included with Description Installation loca- Requirements the appliance tion Water drain hose In a washer-dryer Only use the ori- with connection stack ginal connection adapter, fixing set from the material and el- dryer manufac- bow. turer when set- → "Water drain ting up this appli- ance in a... - Page 14 en Installation and connection hose to drain away excess condens- Pull out the condensation hose ation directly into the waste water from the connecting piece. system. Notes ¡ Operate this appliance using the water drain hose provided. If you connect the water drain hose → Page 14, you do not have to regularly empty the condensation container → Page 30.
- Page 15 Installation and connection en Push the water drain hose as far Insert the stopper into the recess as it will go into the connecting in the top. piece. Insert the condensation container Empty the condensation container → Page 31. → Page 30. Connect the appliance to the water outlet.
-
Page 16: Aligning The Appliance
en Installation and connection 4.5 Aligning the appliance Note: You can use the Y-distrib- In order to reduce vibrations and utor → Page 26 noises, align the appliance correctly. to connect the To align the appliance, turn the ap- ▶ water drain hose pliance feet. Check that the appli- of an additional ance is level using a spirit level. -
Page 17: Familiarising Yourself With Your Appliance
Familiarising yourself with your appliance en 5 Familiarising yourself with your appliance 5.1 Appliance You can find an overview of the parts of your appliance here. On certain models, specific details such as the colour and shape may differ from those pictured. Ventilation opening Door Maintenance flap on the base Condensation container... -
Page 18: Control Panel
en Familiarising yourself with your appliance 5.2 Control panel You can use the control panel to configure all functions of your appliance and to obtain information about the operating status. Programmes → Page 24 Programme selector → Page 27 Buttons → Page 21 Display → Page 19... -
Page 19: Display
Display en 6 Display The display shows the current settings, options or relevant information. Display Designation Description 0:40 Programme dura- Expected programme duration or pro- tion/programme gramme time remaining in hours and time remaining minutes. 1:25 Timed programme The timed programme is set. → "Timed programmes", Page 25 "Ready in"... - Page 20 en Display Display Designation Description Filter system on Clean the filter system on the base unit the base unit → Page 28. Basic appliance Run the basic appliance care programme. care programme → "Running the basic appliance care pro- gramme on the appliance", Page 35 Cooling process The laundry is cooled while the drum is rotating, in order to avoid damage to the...
- Page 21 Buttons en 7 Buttons Below is an overview of the buttons and their setting options. Button Selection Description StartIReload ¡ Start Start, cancel or pause the programme. ¡ Cancel ¡ Pause (mains switch) ¡ Switch on Switch the appliance on or off. ¡...
- Page 22 en Buttons Button Selection Description Easy Ironing 120' ¡ Activate Activate or deactivate the crease-reduction func- ¡ Deactivate tion. Once the programme has ended, the drum moves the laundry at regular intervals for 120 minutes to prevent creasing. Gentle Dry ¡ Activate Activate or deactivate gentle drying.
-
Page 23: Changing The Dryness Level
Dryness level en 8 Dryness level Each automatic programme has a specified dryness level. The dryness level defines how dry or damp your laundry is after the programme ends. Dryness level Laundry Drying result Multi-layered, thick laundry The laundry is dry. that does not dry readily. Normal, single-layered The laundry is dry. -
Page 24: Programmes
en Programmes 9 Programmes You can dry your fabrics using either an automatic programme or a timed pro- gramme. 9.1 Automatic programmes Automatic programmes are pro- Tips grammes in which humidity sensors ¡ Select the dryness level according measure the residual moisture in the to the type of fabric or the desired laundry during the drying cycle. -
Page 25: Timed Programmes
Programmes en Programme Description Max. load (kg) Shirts/Business Suitable for shirts and blouses made of cotton, linen, synthetics or blended fab- rics. Note: For optimal drying results, dry a maximum of 5 shirts or 5 blouses at the same time. Once the laundry is dry, iron it or hang it up. - Page 26 en Accessories 10 Accessories Use original accessories. These have been made especially for your appli- ance. Note: Some accessories are avail- able in other colours. Contact → "Customer Service", Page 50. Order number Connection kit To save space, stack the WZ27410 appliance on a suitable washing machine of the same width and depth and that is from the...
-
Page 27: Laundry
QR code in the table of scanning the QR code in the table of contents or on siemens-home.bsh- contents or on siemens-home.bsh- group.com . group.com . -
Page 28: Loading Laundry
en operation you want to avoid or cancel the 12.4 Loading laundry cooling process, open the door. Note: To prevent creasing, note the → "Display", Page 20 maximum load for the programmes. Open the door. → "Programmes", Page 24 Add or remove laundry. Requirements Close the door. ¡... - Page 29 operation en ¡ If you do not clean the appliance Pull the fluff collector out horizont- as described, the appliance's func- ally. tionality may be impaired. Requirement: The display shows the following during operation: Open the base unit → Page 40. Remove the fluff. The fluff collector may contain con- densation, which may drip out of it when you pull it out.
-
Page 30: Condensation Container
en operation Clean the filter thoroughly under Close the base unit → Page 40. running water and then dry it off. 12.11 Condensation con- tainer Condensation forms during drying, which your appliance uses for auto- matic cleaning. By default, the con- densation is collected in the appli- ance's condensation container. -
Page 31: Childproof Lock
Childproof lock en Empty the condensation container. 13 Childproof lock Secure your appliance against being operated unintentionally using the controls. 13.1 Activating the childproof lock Press and hold the two Child ▶ Lock 3 sec. buttons for approx. 3 seconds. a The controls are locked. Check the condensation container a The childproof lock remains active filter → Page 42 regularly and... -
Page 32: Basic Settings
en Basic settings 14 Basic settings You can configure the basic settings for your appliance to meet your needs. 14.1 Overview of basic settings Basic setting Programme posi- Value Description tion End signal 0 (off) Set the volume of 1 (quiet) the signal at the 2 (medium) end of the pro- 3 (loud) -
Page 33: Changing The Basic Set- Tings
Appliance care en Remove the laundry. 14.2 Changing the basic set- tings Set the programme selector to po- sition 1. Close the appliance door. Pull out the condensation con- tainer, keeping it level. Press Drying Aim and, at the same time, turn the programme selector to position 2. -
Page 34: Preparing The Condensation Container For The Appliance Care Programme
en Appliance care 15.2 Preparing the condensa- 15.3 Starting the appliance tion container for the ap- care programme pliance care programme Requirements ¡ The appliance is ready to run the Note: If the condensation is drained appliance care programme. using the drain hose, the condensa- → "Preparing the appliance for the tion container must be prepared be- appliance care programme ",... -
Page 35: Running The Basic Appli- Ance Care Programme On The Appliance
Appliance care en Insert the condensation container 15.4 Running the basic appli- so that it locks into place. ance care programme on the appliance To remove any light soiling, you can run a basic appliance care pro- gramme. Note: After a certain period of use, the appliance automatically recom- mends that you run the basic appli- ance care programme. -
Page 36: Preparing The Appliance For The Intensive Appliance Care Programme
en Appliance care Empty the condensation container 15.5 Preparing the appliance → Page 30. for the intensive appli- ance care programme If the appliance is not used for more than one month, stubborn dirt or odours may occur. To remove this, you can run an intensive appliance care programme. -
Page 37: Running The Intensive Appli- Ance Care Programme
Appliance care en Insert the condensation container 15.6 Running the intensive so that it locks into place. appliance care pro- gramme Pull out the condensation con- tainer horizontally and empty it. Press StartIReload . The ap- pliance care programme starts and an audible signal sounds. After around 3 hours, the appli- ance pauses the appliance care Pour a bottle of the original appli-... -
Page 38: Ending The Intensive Appli- Ance Care Programme
en Appliance care Add approx. 1 ½ litres of hot tap 15.7 Ending the intensive ap- water into the condensation con- pliance care programme tainer. Add approx. 1 ½ litres of hot tap water into the condensation con- tainer. Hold the full condensation con- tainer level so that no liquid spills out. -
Page 39: Cleaning And Servicing
Note: You can find further information in the digital instruction manual by scanning the QR code in the table of contents or on siemens-home.bsh- group.com . 16.1 Tips on cleaning and care Wipe down the... -
Page 40: Base Unit
en Cleaning and servicing Pull out the heat exchanger cover 16.2 Base unit by the handle. The base unit is the accessible area at the bottom of the appliance in which you will find the heat ex- changer. Opening the base unit Requirements ¡... -
Page 41: Moisture Sensor
Cleaning and servicing en Insert the heat exchanger cover by ance changes the duration of the the handle. automatic programme depending on the residual moisture in the laundry. Cleaning the moisture sensor Over time, residue from limescale, detergents and care products can build up on the moisture sensor. -
Page 42: Condensation Container Filter
en Cleaning and servicing Slide in the filter as far as it will go. 16.4 Condensation container filter During drying, fluff from the laundry gets into the condensation. The filter in the condensation container pro- tects the appliance from fluff. Clean the filter for the condensation tank. -
Page 43: Troubleshooting
Troubleshooting en 17 Troubleshooting You can rectify minor faults on your appliance yourself. Read the troubleshoot- ing information before contacting after-sales service. This will avoid unneces- sary costs. WARNING Risk of electric shock! Incorrect repairs are dangerous. Repairs to the appliance should only be carried out by trained specialist ▶... - Page 44 en Troubleshooting Fault Cause and troubleshooting Appliance paused, but Cooling process active. the drum is rotating. Not a fault – no action required. ▶ Creasing. The load is too large. Observe the maximum load capacity of the ▶ → "Programmes", Page 24. The laundry lies in the drum for too long after drying. Remove the laundry from the drum as soon as the drying programme has finished.
- Page 45 Troubleshooting en Fault Cause and troubleshooting and programme → "Closing the base unit", Page 40. terminated. Dirt in the appliance. → "Preparing the appliance for the intensive appli- ▶ ance care programme", Page 36. Condensation in the The appliance uses condensation for the automatic condensation tank self-cleaning.
- Page 46 en Troubleshooting Fault Cause and troubleshooting The drying time is too Regularly dry a load weighing more than 3 kg of ▶ long. damp laundry until the programme ends. Insufficient condensation for the automatic self-clean- ing when permanently using the crease-removal func- tion.
- Page 47 Troubleshooting en Fault Cause and troubleshooting Automatic self-cleaning function rinses the appliance's heat exchanger. Not a fault. Do not pull out the condensation tank. Do not cancel the programme. Water is leaking from Appliance is not correctly aligned. the appliance. → "Aligning the appliance", Page 16 ▶...
- Page 48 en Troubleshooting Fault Cause and troubleshooting The laundry is too Set a timed programme for the subsequent drying. ▶ damp. → "Programmes", Page 24 Moisture sensor dirty. → "Cleaning the moisture sensor", Page 41. ▶ The drying process is interrupted and the condensa- tion tank has been filled. → "Emptying the condensation container", Page 30.
-
Page 49: Transportation, Storage And Disposal
Transportation, storage and disposal en Empty the condensation container 18 Transportation, stor- → Page 30. age and disposal Insert the condensation container → Page 31. Disconnect the appliance's mains 18.1 Preparing the appliance plug from the power supply. for transportation a The appliance is now ready to be transported. -
Page 50: Customer Service
en Customer Service Information about current disposal 19.1 Product number (E-Nr.) methods are available from your and production number specialist dealer or local authority. (FD) This appliance is la- You can find the product number (E- belled in accordance Nr.) and the production number (FD) with European Directive on the appliance's rating plate. -
Page 51: Consumption Values
Consumption values en 20 Consumption values The programme The actual values may deviate from + the indicated values depending on Cottons (denoted by the arrow symbol) is the type of fabric, composition of suitable for drying cotton laundry with laundry to be dried, residual moisture a normal dampness level, and is the in the fabric, set degree of dryness, most efficient programme for drying... -
Page 52: Technical Data
en Technical data Programme Final Load Spin Initial Pro- Energy mois- (kg) speed mois- gramm con- ture (rpm) ture e dura- sump- level level tion tion (h:min) (kWh/ cycle) Cottons + 12.0 1000 1:39 0.67 Cottons + 12.0 3:09 1.45 Cottons... - Page 56 Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001758696* 9001758696 (020803)
