Dishwasher / User Manual
DF451

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DF451 and is the answer not in the manual?

Questions and answers

Related Manuals for Nordmende DF451

Summary of Contents for Nordmende DF451

  • Page 1 Dishwasher / User Manual DF451...
  • Page 2 Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.

  • Page 3: Table Of Contents

    CONTENTS 1.SAFETY INSTRUCTIONS ....................1 1.1. General Safety Warnings ....................1 1.2. Installation Warnings .....................1 1.3. During Use........................2 2.INSTALLATION ......................... 6 2.1. Machine Positioning .....................6 2.2. Water Connection ......................6 2.3. Water Inlet Hose ......................6 2.4. Drain Hose........................6 2.5. Electrical Connection ....................7 3.TECHNICAL SPECIFICATIONS ..................
  • Page 4 8.CLEANING AND MAINTENANCE ................. 16 8.1. Cleaning the Machine and Filters ................16 8.2. Spray Arms ........................16 9.TROUBLESHOOTING ....................17 10.PRACTICAL INFORMATION ..................19 11.THE PRODUCT FICHE ....................20...

  • Page 5: Safety Instructions

    1. SAFETY INSTRUCTIONS 1.1. General Safety Warnings • Carefully read all instructions before using your appliance and keep this manual for future reference. Check the machine and its packaging for any damage. Never start using a damaged machine, contact an authorised service immediately. •...

  • Page 6: During Use

    • Follow the instructions on installing and connecting the machine. • Only original spare parts should be used with the machine. Unplug the machine before installation. Machine should be installed by authorised service only. Check whether the indoor electrical fuse system is connected according to regulations.
  • Page 7 • guarantee. Do not stand, sit or place loads on the open door of the dishwasher. Only use detergents and rinse aids produced specifically for dishwashers. Our company is not responsible for any damage that may occur due to misuse. Do not drink water from the machine.
  • Page 8 keep the door open for 30 minutes after a programme is complete. Do not stand in front of the door after the auto-open signal sounds. In the case of a malfunction, repair should only be performed by authorised service personnel. Otherwise, the warranty will be void.
  • Page 9 CE Declaration of Conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. Disposal of your old machine The symbol on the product or on its packaging indicates that this product may not be treated as household waste.

  • Page 10: Installation

    2. INSTALLATION new hose before connecting. 2.1. Machine positioning WARNING: Connect the hose directly to the water inlet tap. The pressure When positioning the machine, place it in supplied by the tap should be a minimum an area where dishes can be easily loaded of 0.03 MPa and a maximum of 1 MPa.

  • Page 11: Electrical Connection

    2.5. Electrical connection WARNING: Your machine is set operates at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. The earthed plug of the machine must be connected to an earthed outlet supplied by suitable voltage and current.

  • Page 12: Technical Specifications

    3. TECHNICAL SPECIFICATIONS 3.2. Technical specifications 10 place Capacity settings Dimensions Height 820-870(mm) Width 450(mm) Depth 570(mm Net weight 32 kg Operating 220-240V 50 voltage / frequency Total 10(A) current (A) Total power 1900(W) 3.1. General appearance 1. Upper basket with racks Maximum: 2.

  • Page 13: Before Using The Appliance

    4. BEFORE USING a short washing program to protect your machine against corrosion. THE APPLIANCE 4.1. Preparing your Dishwasher for first use • Check whether the electricity and supply water specifications match the values indicated in the installation instructions for the machine. •...

  • Page 14: Test Strip

    4.3. Test Strip Run water Keep the Shake the Wait Set the hardness level of through tap strip in strip. (1min.) your machine. (1min.) water (1sec) NOTE: Level is set 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices.

  • Page 15: Filling The Detergent

    4.8. Filling the detergent The factory setting is “3”. Push the latch to open the dispenser and If the dishes are not drying properly or are pour in the detergent. spotted, increase the level. If blue stains form on your dishes, decrease level. To do Close the lid and press it until it locks in this, remove the cap and rotate the indicator place.

  • Page 16: Loading Your Dishwasher

    5. LOADING YOUR DISHWASHER For best results, follow these loading guidelines. We recommend that you place large items (pots, pans, lids, plates and bowls) which are heavily soiled in the lower basket. The upper basket is designed for delicate and lighter dishware such as glasses, coffee and tea cups and saucers.

  • Page 17: Alternative Basket Loads

    5.3. Alternative basket loads • Forks, spoons and knives with wooden, bone, ivory or nacrecoated handles; Lower basket glued items, items soiled with abrasive, acidic or base chemicals. • Temperature-sensitive plastics, copper or tincoated containers. • Aluminium and silver objects. •...

  • Page 18: Programme Table

    6. PROGRAMME TABLE Detergent A: 5cm³ Duration Programme Description B1: 15cm³ (min) B2: 25cm³ Intensive A+B2 For heavily soiled dishes. A+B2 Standard programme for normally soiled, daily-used/ dishes. (Reference) Prewash To rinse dishes that you plan to wash later. NOTE: THE PROGRAMME DURATION MAY CHANGE ACCORDING TO THE AMOUNT OF DISHES, THE WATER TEMPERATURE, THE AMBIENT TEMPERATURE AND SELECTED ADDITIONAL FUNCTIONS.

  • Page 19: The Control Panel

    7.2. Cancelling a Programme 7. THE CONTROL PANEL If you would like to cancel a programme while in operation. Open the door of your machine. The light corresponding to the selected program will illuminate. Press the Power On/Off button (1). The End Of Programme Indicator (3) will illuminate.

  • Page 20: Cleaning And Maintenance

    8. CLEANING AND the filters. Replace the filter insert, and MAINTENANCE rotate it clockwise (4). • Never use your Dishwasher without a Cleaning your Dishwasher is important filter. to maintain the machine’s service life. • Incorrect fitting of the filter will reduce Oil and lime may build up in your the washing effectiveness.

  • Page 21: Troubleshooting

    9. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start.
  • Page 22 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.

  • Page 23: Practical Information

    AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE CODE POSSIBLE FAULT WHAT TO DO Make sure the water inlet tap is open and water is flowing. Insufficient water Separate the inlet hose from the tap and clean the filter of the hose. Contact for service if the error continues.

  • Page 24: The Product Fiche

    11. THE PRODUCT FICHE Supplier's trade mark NORDMENDE Supplier's model DF451 Capacity of dishwasher The energy efficiency class Annual energy consumption in kWh per year (AEc) ( 280 Cycle )* Energy consumption (Et) (kWh per cycle) 0,73 Off-mode power consumption (W) (Po) 0,50 Left-on mode power consumption (W) (Pı)
  • Page 25 ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 26 52198221 R24...
