Summary of Contents for Airopie DC50
- Page 1 Document Camera DC50 User Manual...
- Page 2 NOTICES:PLEASE READ CAREFULLY BEFORE USE ● Use the document camera under the rated electric conditions. ● Do not place the document camera on any unstable surface. It may fall and causeinjuries or damages. ● Do not place this device under direct sunlight or near heaters. ●...
-
Page 3: Specifications
1. Part Name And Functions ● Appearance ● Side Panel ● Control Panel 2. Remote Control 3. Pc Free Annotation And Control ● Annotation Functions 4. Specifications... -
Page 4: Part Name And Functions
Part Name And Functions: Appearance: Rear Panel: ①DC5V: power input ⑥HDMI IN: HDMI input ②VGA IN: VGA input ⑦HDMI OUT:HDMI output ③Audio IN: audio input for VGA input ⑧PC: USB connector, ④VGA OUT: VGA output used to connect with PC ⑤Audio OUT: audio output for VGA output ⑨USB: N/A... -
Page 5: Side Panel
Side Panel ZOOM KNOB KENSINTON ● ZOOM KNOB: Zoom in/zoom out knob ● KENSINTON: Kensington lock SD-CARD ● USB: USB connector, used to connect USB mouse. ● SD-CARD:SD card connector Control Panel... - Page 6 1. CAMERA: To switch back to camera image 2. HDMI IN: To switch to HDMI input 3. READ SD CARD：Long press to read SD card memory 4. SAVE: Capture and save the image to Memory stick, SD card, or built-in memory 5.
-
Page 7: Remote Control
Remote Control... - Page 8 1. POWER: Power on/off (Long press to turn off the power) 2. HOME: To switch back to camera image 3. USB: Switch to computer connection 4. DIRECTION: up/ down/ left/ right 5. BACK: Back to previous 6. AUTO:Adjust white balance and focus automatically 7.
- Page 9 PC Free Annotation And Control After clicking the device button or the button "MENU" on the remote control, the settings interface will appear on the screen, where you can set Language, Resolution, USB Mode, Image Setting, Format, Default Setting, and About. The USB mode defaults to camera, the annotation function needs to select "Annotate", and the mouse is connected to the USB interface on the side of the device.
- Page 10 Introduction To Annotation Interface Functions ZOOM OUT Pen, select the pen to annotate ZOOM IN Rectangle, draw rectangles of different sizes Red, color selection for annotations AUTO FOCUS BRIGHTNESS- Blue, color choice for annotations Thin lines, use thin lines for pens and rectangles BRIGHTNESS+ FREEZE Thick lines, use thick lines for pens and rectangles...
- Page 11 Specifications Total pixel 5.0 MP Zoom 12X optical, 20X digital Image Sensor 1/3" CMOS Lens ff=5.1~51mm FF=1.6~1.8 Frame rate 60fps(max) Shooting area Focus Auto/manual Output signal XGA, SXGA，720P, 1080P Resolution (Horizontal) ≥ 900 TV lines White balance Auto/manual Color adjustment Red+/-, Blue+/- Image capture Yes（to SD card)
