- Page 1 Document Camera DC80 User Manual...
- Page 2 NOTICES:PLEASE READ CAREFULLY BEFORE USE ● Use the document camera under the rated electric conditions. ● Do not place the document camera on any unstable surface. It may fall and causeinjuries or damages. ● Do not place this device under direct sunlight or near heaters. ●...
-
Page 3: Specifications
1. Part Name And Functions ● Appearance ● Side Panel ● Control Panel 2. Remote Control 3. Pc Free Annotation And Control ● Annotation Functions 4. Specifications... -
Page 4: Part Name And Functions
Part Name And Functions: Appearance: Rear Panel: ①DC5V: power input ⑥HDMI IN: HDMI input ②VGA IN: VGA input ⑦HDMI OUT:HDMI output ③Audio IN: audio input for VGA input ⑧PC: USB connector, ④VGA OUT: VGA output used to connect with PC ⑤Audio OUT: audio output for VGA output ⑨USB: USB connector, used to connect USB mouse. -
Page 5: Side Panel
Side Panel ZOOM KNOB KENSINTON ● ZOOM KNOB: Zoom in/zoom out knob ● KENSINTON: Kensington lock SD-CARD ● USB: USB connector, used to connect USB mouse. ● SD-CARD:SD card connector Control Panel... - Page 6 1. CAMERA: To switch back to camera image 2. HDMI IN: To switch to HDMI input 3. READ SD CARD：Switch to online mode，Long press to read SD card memory 4. SAVE: Capture and save the image to Memory stick, SD card, or built-in memory 5.
-
Page 7: Remote Control
Remote Control... - Page 8 1. POWER: Power on/off (Long press to turn off the power) 2. HOME: To switch back to camera image 3. USB: Switch to computer connection 4. DIRECTION: up/ down/ left/ right 5. BACK: Back to previous 6. AUTO:Adjust white balance and focus automatically 7.
- Page 9 Introduction To Offline Annotation Interface Pencil Color - Red Line width (thick) Pencil Color - Red Eraser, erase by frame Pencil Color - Black Eraser, erase all Square drawing ZOOM IN Line width (thin) ZOOM OUT Line width (medium) Auto focus...
- Page 10 Introduction to offline setting interface PARAMETER Adjustable items BRIGHTNESS Data adjustment Data adjustment BLUE Data adjustment SHARPNESS Data adjustment DENOISE Weak, Mid, Strong TEXT ENHANCE On, Off POSVNEGA Positive, Negative COLOR/BW Color, B&W MIRROR Normal, Flip, Mirror, Filp|Mirror FRAME RATE 15fps, 20fps, 25fps, 30fps OUTPUT XGA, SXGA, 720P, 1080P...
- Page 11 Specifications Total pixel 8.0 MP Zoom 12X optical, 4X mechanic, 12X digital Image Sensor 1/2.7“ CMOS Lens ff=5.1~51mm FF=1.6~1.8 Frame rate 30fps(max) Shooting area Focus Auto/manual Output signal XGA, SXGA，720P, 1080P Resolution (Horizontal) ≥ 1000 TV lines White balance Auto/manual Color adjustment Red+/-, Blue+/- Image capture...
