LINK

User guide

VERSION 1.5.0

SEPTEMBER 11, 2023

www.aodyo.com

Table of Contents

Need help?

Do you have a question about the Sylphyo Link and is the answer not in the manual?

Questions and answers

Summary of Contents for Aodyo Instruments Sylphyo Link

Page 1 LINK User guide VERSION 1.5.0 SEPTEMBER 11, 2023 www.aodyo.com...
Page 2 www.aodyo.com...
Page 3: Table Of Contents
Contents The Sylphyo Link at a glance ......5 Overview • What’s in the box? •...
Page 5: The Sylphyo Link At A Glance
A warm thank you from the Aodyo team for believing in us and supporting our work! We hope you will love using your Link as much as we do. Sylphyo Link is a compact sound bank for electronic wind instruments and other MIDI controllers. Aodyo Instruments constantly improves it and updates its sounds to offer musicians rich and expressive sonic worlds in a small and portable package.
Page 6: Overview
The Sylphyo Link at a glance as an in‐ear monitor on stage while the Link is connected to the control booth and to various expanders and synths at the same time. Overview Front panel Indicator light. Tells whether there is a wireless connection to a Sylphyo: A yellow light means the Link is looking to pair with any Sylphyo.
Page 7 Rear panel Headphone output port (6.35mm stereo jack). Play the Link synth with headphones. Line input port (6.35mm stereo jack). Mix any sound source to your own sound. Line output ports (left and right 6.35mm mono jacks). Play the Link synth on an amp, a mixer, or a hi‐fi system.
Page 8: What's In The Box
The Sylphyo Link at a glance What's in the box? VIDEO youtu.be/yZnmMfIc1EI  Unboxing Two accessories are included along with your Link: 5W charger Plug the 5W charger into a mains socket in order to power the Link using the USB cable.
Page 9 the Link. Then, turn on your Link using the power‐on switch, and turn on your Sylphyo as well. If the Link displays a green light , then they are already paired (i.e., they already know each other), and you can skip the rest of this subsection.
Page 10: Another Controller To The Link
The Sylphyo Link at a glance VIDEO youtu.be/LvsWkr39zLc  Pairing with the Link receiver Connecting another controller to the Link If you plan to use the Link with another MIDI controller, there are sev‐ eral options to connect it. If your controller has a 5‐pin MIDI DIN port, connect a MIDI DIN cable (not included) from the MIDI OUT port of your controller to the MIDI IN port of your Link.
Page 11: Playing With The Link
Playing with the Link In this section, you will learn how to use the Link with your controller, Syl‐ phyo or otherwise, to play its internal sounds as well as other sounds on your computer, phone, tablet, or synthesizer. Playing using the internal sounds Connect the Link to a power supply.
Page 12: Playing With An Ios Smartphone Or Tablet
Playing with the Link VIDEO youtu.be/Jov0iqmQ7Q0  Quick start with a PC/Mac computer Note that the Link shows up in your computer as three different MIDI input/output ports in the following order: − Sylphyo. This is the wireless MIDI input and output to your Syl‐ phyo.
Page 13 VIDEO youtu.be/MivOe32DNJ0  Quick start with an iOS smartphone or tablet Playing with a hardware synthesizer You can control any MIDI‐compatible hardware synthesizer with the Sylphyo +Link. However, you will need to get a MIDI cable to connect your synthesizer to the Link. First, connect the Link to a power supply.
Page 14: Midi Routing
Playing with the Link MIDI routing The following diagram explains the routing between the different MIDI inputs and outputs: Sylphyo WIRELESS USB-MIDI MIDI DIN POWER SUPPLY USB-MIDI Host USB-MIDI MIDI Internal sounds PHONES & LINE OUT HOST...
Page 15: Complementary Information
Complementary information Please take note of the following important information before you begin to use your Link. Technical features Size and weight 240 g (0.53 lbs). Maximum operating temperature 40 °C (104 °F). Repairing the Link Do not open the Link and do not attempt to service it yourself. Damage to you or your instrument could occur during teardown.
Page 16: Information
Complementary information Disposal and recycling Your Link must be disposed of properly according to local laws and regu‐ lations. Because it contains electronic components, it must be disposed of separately from household waste. Regulatory compliance information This device complies with part 15 of the FCC Rules. Operation is sub‐ ject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 17: Trademarks
− Reorient or relocate the receiving antenna. − Increase the separation between the equipment and receiver. − Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. − Consult the dealer or an experienced radio/TV technician for help. FCC ID: 2ASYT‐AODYOSLINK This device complies with Industry Canada licence‐exempt RSS stan‐...
Page 18: Disclaimer
Complementary information Disclaimer This documentation represents the current state of the product, how‐ ever it may evolve. We do everything we can to provide our users with high‐quality products and documentation. However, Aodyo does not guarantee that this documentation exactly reflects the state of the product.
