Grand Canyon Gas Logs GLOWFIRE LAVA BURNER FRONT VIEW Installation And Operation Manual

Advertisement

LAVA BURNER FRONT VIEW
INSTALLATION AND OPERATION MANUAL
WARNING: If the information in this manual
is not followed exactly, a fire or explosion
may result causing property damage,
personal injury, or loss of life.
FOR YOUR SAFETY: Do not store or use
gasoline or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
INSTALLER: Leave this manual with appliance. CONSUMER: Retain this manual for future reference.
Certified to the Canadian and American National Standards: ANSI Z21.60-2017 / CSA 2.26-2017 for decorative gas appliances for installation in solid-Fuel burning fireplaces.
3515 East Atlanta Avenue, Phoenix, Arizona 85040 | 602-344-4217 | grandcanyongaslogs.com
WITH GLOWFIRE LOGS
WARNING
Report # F23-187
FOR INDOOR OR OUTDOOR PATIO USE
Grand Canyon Gas Logs
SHOWN: 36" GLOWFIRE™ LAVA BURNER FRONT VIEW
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
– Installation and service must be performed by a
qualified installer, service agency, or the gas suppli
WITH ALL WEATHERED OAK CHARRED LOGS
07-00071 082023_V1
er.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLOWFIRE LAVA BURNER FRONT VIEW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Grand Canyon Gas Logs GLOWFIRE LAVA BURNER FRONT VIEW

  • Page 1 FOR INDOOR OR OUTDOOR PATIO USE Certified to the Canadian and American National Standards: ANSI Z21.60-2017 / CSA 2.26-2017 for decorative gas appliances for installation in solid-Fuel burning fireplaces. Grand Canyon Gas Logs 3515 East Atlanta Avenue, Phoenix, Arizona 85040 | 602-344-4217 | grandcanyongaslogs.com...
  • Page 2 LAVA BURNER FRONT VIEW WITH GLOWFIRE™ LOGS INSTALLATION & OPERATION MANUAL GRANDCANYONGASLOGS.COM - 08_2023...
  • Page 3 SAFETY INFORMATION p WARNING • Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fire or injury. • This appliance is hot when operated and can cause severe burns HOT GLASS WILL if contacted.
  • Page 4 SAFETY INFORMATION p WARNING • Do not use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water. •...
  • Page 5: Table Of Contents

    TABLE OF CONTENTS General Instructions and Information ........4-7 Parts List ..................8-11 Wiring Diagram, Pre-Installation ..........12-14 Pre-Installation Steps ...............15-17 Installation Steps ..............18-19 Log Placement ................. 20-24 Outdoor Installation Requirements ......... 25-26 Multifunction Remote Operating Instructions ......27-30 Remote Control Instructions ........... 31-35 Intermittent Pilot Instructions ............
  • Page 6: General Instructions And Information

    GENERAL INSTRUCTIONS DO NOT REMOVE THIS LABEL TESTED & BATTERY-DEXEN See installation & operating instructions for this model. LISTED BY: ANSI-Z21 60-2017 Contact local building officials about restrictions and CSA 2.26-2017 installation specifications in your area. Decorative gas appliances for installation in solid-fuel burning fireplaces.
  • Page 7 GENERAL INSTRUCTIONS Damper Stop Installation The damper must be permanently locked in position to prevent full closure and to provide a minimum flue opening. Various methods for locking the damper may be used but may be restricted from region to region and it is important to know the specifics that apply to your area.
  • Page 8 GENERAL INSTRUCTIONS MIN. FIRE BOX SIZE NG/LP Front Rear Depth Height LAFV-18- (EN, VEN, EP, VEP) 28" 18" 16" 22" LAFV-24- (EN, VEN, EP, VEP) 34" 24" 16" 22" LAFV-30- (EN, VEN, EP, VEP) 40" 30" 18" 26" LAFV-36- (EN, VEN, EP, VEP) 46"...
  • Page 9 GENERAL INSTRUCTIONS BURNER SPECIFICATIONS NATURAL GAS MODELS Rated Rated Rated Rated Rated Manifold Inlet Inlet NG Models High Pressure LAFV-18-EN 45,000 5" 10.5" LAFV-24-EN 56,000 5" 10.5" LAFV-30-EN 75,000 5" 10.5" LAFV-36-EN 86,000 5" 10.5"" Rated Rated Rated Rated Rated Manifold Inlet Inlet...
  • Page 10: Parts List

    PARTS LIST VEN & VEP MODELS LAVA BURNER FRONT VIEW WITH GLOWFIRE™ LOGS INSTALLATION & OPERATION MANUAL GRANDCANYONGASLOGS.COM - 08_2023...
  • Page 11 PARTS LIST VEN & VEP MODELS LAFV-XX-VEN | LAFV-XX-VEP ITEM PART NO. DESCRIPTION QTY: 02-00721-XX LAVA BURNER FRONT VIEW COMPLETE ASSEMBLY 02-00730 SHEET METAL, BRACKET, CLEARANCE VALVE STAND 02-00731-XX SHEET METAL, PLATE MEDIA DECK, LOG INDEX 02-00726-XX SHEET METAL, RECESSED DROP IN TRAY, REMOVABLE HOUSING 02-00752 SHEET METAL, HOLDER, BRACKET 02-00753...
  • Page 12 PARTS LIST EN & EP MODELS LAVA BURNER FRONT VIEW WITH GLOWFIRE™ LOGS INSTALLATION & OPERATION MANUAL GRANDCANYONGASLOGS.COM - 08_2023...
  • Page 13 PARTS LIST EN & EP MODELS LAFV-XX-EN | LAFV-XX-EP ITEM PART NO. DESCRIPTION QTY: 02-00721-XX LAVA BURNER FRONT VIEW COMPLETE ASSEMBLY 02-00730 SHEET METAL, BRACKET, CLEARANCE VALVE STAND 02-00731-XX SHEET METAL, PLATE MEDIA DECK, LOG INDEX 02-00726-XX SHEET METAL, RECESSED DROP IN TRAY, REMOVABLE HOUSING 02-00752 SHEET METAL, HOLDER, BRACKET 02-00753...
  • Page 14 WIRING DIAGRAM PRE-INSTALLATION Before you begin Thank you for purchasing Grand Canyon Gas Log’s Lava Burner Front View with Glowfire™ Logs. This product has been designed to provide you with safe, trouble-free operation. Please read this manual throughly before beginning the installation. It has information which is important for safe installation and operation.
  • Page 15: Wiring Diagram, Pre-Installation

    WIRING DIAGRAM WIRING DIAGRAM INSTALLATION Dexen 6003V (EN/EP) Control System LAVA BURNER FRONT VIEW WITH GLOWFIRE™ LOGS INSTALLATION & OPERATION MANUAL GRANDCANYONGASLOGS.COM - 08_2023...
  • Page 16 WIRING DIAGRAM SIT Proflame 1 (VEN/VEP) Control System LAVA BURNER FRONT VIEW WITH GLOWFIRE™ LOGS INSTALLATION & OPERATION MANUAL GRANDCANYONGASLOGS.COM - 08_2023...
  • Page 17: Pre-Installation Steps

    PRE-INSTALLATION Installation Items Needed Installation must include an equipment shutoff valve, union and plugged 1/8" NPT tap. Locate NPT tap within reach Before installing appliance, make sure you have the items for test gauge hook up. NPT tap must be upstream from listed below.
  • Page 18 PRE-INSTALLATION We recommend that you install a sediment trap in supply CAUTION: Make sure external regulator has been installed line as shown in Figure C. Locate sediment trap where it is between propane/LP supply and appliance. within reach for cleaning. See guidelines under Connecting to Gas Supply, Page ?.
  • Page 19 PRE-INSTALLATION PRESSURE TESTING APPLIANCE For Massachusetts Residents Only: Installation of this gas log set as a vented indoor appliance in the Commonwealth GAS CONNECTIONS of Massachusetts requires the damper be permanently 1. Open equipment shutoff valve. removed or welded in the fully open position. 2. Open main gas valve located on or near gas meter for You must install the damper clamp accessory.
  • Page 20: Installation Steps

    INSTALLATION STEPS The Grand Canyon Gas Logs burner system must be installed by a qualified professional service technician. Instructions must be followed carefully to ensure proper performance and full benefit from the burner system. Check to be sure the burner system is designed and labeled for the type of gas (natural or propane gas) supplied to the fireplace.
  • Page 21 INSTALLATION STEPS DECORATIVE MEDIA INSTALLATION (BLACK EMBERS/LAVA ROCK) 1. Place the black glowing embers (supplied with burner) heavily and evenly in the areas shown (Figure 5). Break up black embers to be no larger than the size of a dime. Store any excess embers if applicable.
  • Page 22: Log Placement

    LOG PLACEMENT Firelog Installation Warnings 1. Firelogs are fragile. Handle them gently to prevent damage to their paint or the fireplace. 2. Arrange firelogs as shown the log section. Do not arrange them in any other way. If firelogs are not installed per installation instructions, flame impingement and improper combustion may occur and result in soot and/or excessive production of carbon monoxide (CO).
  • Page 23 LOG PLACEMENT 18" GLOWFIRE™ ARIZONA WEATHERED OAK CHARRED LOGS PLACEMENT GUIDE Part # Description GFWOC18 18" Glowfire™ Arizona Weathered Oak Charred Log Set 05-00129 18" Left Front Log 05-00130 18" Right Front Log 05-00131 18" Back Log 05-00151 Static Log #2 05-00152 Static Log #1 05-00153...
  • Page 24 LOG PLACEMENT 24" GLOWFIRE™ ARIZONA WEATHERED OAK CHARRED LOGS PLACEMENT GUIDE Part # Description GFWOC24 24" Glowfire™ Arizona Weathered Oak Charred Log Set 05-00131 24" Back Log 05-00132 24" Left Front Log 05-00133 24" Right Front Log 05-00153 24" Static Log #1 05-00154 24"...
  • Page 25 LOG PLACEMENT 30" GLOWFIRE™ ARIZONA WEATHERED OAK CHARRED LOGS PLACEMENT GUIDE Part # Description GFWOC30 30" Glowfire™ Arizona Weathered Oak Charred Log Set 05-00135 30" Left Front Log 05-00136 30" Rigth Front Log 05-00137 30" Back Log 05-00150 30" Static Log #6 05-00153 30"...
  • Page 26 LOG PLACEMENT 36" GLOWFIRE™ ARIZONA WEATHERED OAK CHARRED LOGS PLACEMENT GUIDE Part # Description GFWOC36 36" Glowfire™ Arizona Weathered Oak Charred Log Set 05-00138 36" Left Front Log 05-00139 36" Right Front Log 05-00140 36" Back Log 05-00150 36" Static Log #6 05-00153 36"...
  • Page 27: Outdoor Installation Requirements

    Lava Burner Front View with Glowfire™ Logs from Grand Canyon Gas Logs have been tested and approved for installation outdoors under a patio cover and away from direct water contact or direct sun light. Grand Canyon Gas Logs standard warranty applies if installed per instructions. All electrical wiring shall be to local building codes. Consult professional installers before installation.
  • Page 28 OUTDOOR INSTALLATION REQUIREMENTS Side Protection: Side distance (SD) must be 50% (or more) of the height (H). If: H=6’ Then: SD=3’ minimum (6’ x 50%=3’) Note: H taken from bottom of fireplace. OVERHANG HEIGHT (H) SIDE DISTANCE SIDE DISTANCE FIREPLACE (SD) (SD) LAVA BURNER FRONT VIEW WITH GLOWFIRE™...
  • Page 29: Multifunction Remote Operating Instructions

    MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS TECHNICAL DATA Remote Control 4.5 V (three 1.5 V AAA Supply voltage batteries) Ambient temperature ratings 0-50˚C (32 - 122˚F) Radio frequency 315 MHz WARNING: The transmitter and receiver are radio frequency devices. Placing the receiver in or near metal may NOTICE: Not all features called out in the diagram above are severely reduce the signal range.
  • Page 30 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Initializing the System for the First time (Re-Sync/Synchronize) 1. Open the battery back-up holder. See Figure 7.1. Install the four AA batteries into the battery back-up holder then reinstall the cover. See Figure 7.2. 2. Install three AAA batteries into the battery bay located on the base of the transmitter.
  • Page 31 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Turn On the Fireplace With the system OFF, press the ON/OFF button on the transmitter. The transmitter display will show other active icons on the screen. At the same time the receiver will activate the fireplace. A single beep from the receiver will confirm reception of the command.
  • Page 32 MULTIFUNCTION REMOTE OPERATING INSTRUCTIONS Low Battery Power Detection - Transmitter During a prolonged outage, the fireplace can operate in continuous pilot mode. This reduces drain on the batteries The life span of the remote control batteries depends on various factors: used to ignite the burner and ensures the fireplace will continue to operate throughout the outage.
  • Page 33: Remote Control Instructions

    REMOTE CONTROL INSTRUCTIONS GCRK Manual On/Off Remote Control with Timer for Dexen Valve Installation and Operating Instructions IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS. DO NOT ATTEMPT TO INSTALL OR OPERATE This manual on/off remote control with timer transmitter is designed to be used with millivolt valve gas appliances. It can be operated on/off from the transmitter or turned on and off manually from the receiver.
  • Page 34 REMOTE CONTROL INSTRUCTIONS Transmitter: Installing Batteries: 1. Press down the battery door and remove the battery door. 2. Install uses two (2) “AAA” batteries as indicated on transmitter. 3. Close the battery door by snapping in place. 4. The batteries should be replaced when the low battery indicator display in LCD. 5.
  • Page 35 REMOTE CONTROL INSTRUCTIONS OPERATIONS: The GCRK remote control has two (2) operating modes: Manual and Timer. (15 min. -180 min. in 15 minute increments). The max setting time is 180 min. The transmitter will operate the remote receiver from 1 foot to 30 feet. The distance is reduced when batteries are low or when the receiver is inside a metal enclosure.
  • Page 36 REMOTE CONTROL INSTRUCTIONS WARNING: Make sure that the wires do not contact the appliances any place other than at the terminals. Exposure to temperatures higher than 250˚ (105˚) may cause the receiver to malfunction or cause a fire hazard. RECEIVER: Begin by installing (4) AA-size batteries.
  • Page 37 REMOTE CONTROL INSTRUCTIONS Slide Switch: 1. ON position: The system will remain on until the slide switch is placed in the OFF or REMOTE position. 2. REMOTE position: The system will only operate if the remote receiver receives a signal from the transmitter. 3.
  • Page 38: Intermittent Pilot Instructions

    INTERMITTENT PILOT INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING p WARNING If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. BEFORE LIGHTING smell all around the appliance B.
  • Page 39: Battery Lighting Instructions

    BATTERY LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with an ignition device that automatically lights the pilot. DO NOT attempt to light the pilot by hand. B.
  • Page 40: Maintenance

    MAINTENANCE p WARNING • Turn off the gas and electrical power before servicing the appliance. • Appliance may be hot. Do not service until appliance has cooled. • Do not use abrasive cleaners on glass. • Do not paint the pilot assembly. This appliance and its venting system should be inspected before use and at least annually by a qualified service person.
  • Page 41: Troubleshooting

    TROUBLESHOOTING Symptom Problem Test Solution Pilot will not light and / Battery. – Check batteries. or makes noise with no Wiring. – Verify the wire for the sensor and the wire for the spark at pilot burner. igniter are connected to the correct terminals (not reversed) on the module.
  • Page 42 TROUBLESHOOTING Symptom Problem Test Solution Continues to spark and Short or loose connection in – Verify all connections. Verify the connections pilot lights, but main sensor rod. from the pilot assembly are tight; also verify these burner will not light. connection are not grounding out to any metal.
  • Page 43: Warranty

    WARRANTY Burner: GlowFire™ Logs: Grand Canyon Gas Logs burners carry a life time warranty GlowFire™ Logs are manufactured with ceramic fiber and against manufacture defects or breakage as long as the carry a 5 year warranty when installed indoors and a 2-year appliance is installed inside and by a professional installer.
  • Page 44 DO NOT RETURN TO STORE! STOP CALL US FIRST For immediate help with installation, product information or if your product arrives damaged, please call our toll free number at: 1-602-344-4217 (Monday - Friday, 8:00AM - 5:00PM, AZ Mountain Time) or email us at: customerservice@grandcanyongaslogs.com OUR STAFF IS READY TO PROVIDE ASSISTANCE Copyright 2023 All rights reserved U.S.A, and Foreign Patents Pending.
