Summary of Contents for Jysk VAIL 727-23-1004

  • Page 1 VAIL Family 727-23-1004 Bunk Bed 04.04.2023 1/19...
  • Page 2 1900mm 1074mm 2016mm 1454mm 2/19...
  • Page 3 This bunk bed model has been tested by an independent laboratory and is in compliance with ASTM F- 1427 standard Consumer of upper bunk and lower bunk the upper bunk the lower bunk Safety Warnings STRANGULATION HAZARD - your local JYSK Linen'N Furniture store Essai de sûreté standard du consommateur matelas ou RISQUE D'ÉTRANGLEMENT 3/19...
  • Page 4 WARNING To help prevent serious or fatal injuries from entrapment or falls : Never allow a child under 6 years on upper bunk. ● Use only mattress which is 74" - 75" long and 37 1/2" - 38 1/2" wide on upper bunk. ●...
  • Page 5 5/19...
  • Page 6: Oluline Teave

    IMPORTANT INFORMATION! Please read the entire manual carefully before starting to assemble and/or using this product. Follow the manual thoroughly and keep it for further reference. INFORMATIONS IMPORTANTES Veuillez lire attentivement l'ensemble du manuel avant de commencer à monter et/ou utiliser ce produit.
  • Page 7 WARNING TO AVOID SCRATCHES! In order to avoid scratching this furniture should be assembled on a soft layer - could be a rug. AVERTISSEMENT POUR ÉVITER LES RAYURES Afin d'éviter les rayures, ce meuble doit être monté sur une surface souple (un tapis, par exemple). BR DIN UMS PAR SKR UMIEM!
  • Page 8 IMPORTANT! It is important that any product which is assembled using any kind of screw is re-tightened 2 weeks after assembly, and once every 3 months - in order to assure stability through-out the lifespan of the product. IMPORTANT Il est important que tout produit monté à l'aide de vis soit resserré 2 semaines après son montage, puis tous les 3 mois, afin de garantir sa stabilité...
  • Page 9 GENERAL INSTRUCTION FOR FURNITURE MADE OF WOOD OR WOOD COMPOSITES SUCH AS MELAMINE, LAMINATE OR VENEER SURFACES! Wipe clean with a damp cloth. Use only water or a gentle detergent. Wipe dry with a clean cloth. INSTRUCTIONS GÉNÉRALES POUR LE MOBILIER CONSTITUÉ DE BOIS OU DE COMPOSITES DE BOIS (COMME LES SURFACES EN MELAMINÉ, STRATIFIÉ...
  • Page 10 ANTI-TOPPLE WARNING! This product has to be permanently fixed to the wall with the bracket(s) included, to avoid fatal injury in case it topples over. The pack only contains screws for fastening the anti-topple bracket(s) itself to the product. Please contact your DIY or hardware store for advice on the correct type of screws/raw plugs for your type of wall.
  • Page 11 1 x22 2 x24 3 x1 4 x22 M6x100mm M6x35mm M6x13mm 5 x28 6 x4 7 x6 8 x14 M8x30mm M10x125mm M3.5x16mm M6x40mm 9 x2 10 x2 11 x4 12 x2 M6x20mm 25 X 280mm M4x16mm 13 x2 14 x2 M4x30mm 32mm 11/19...
  • Page 12 12/19...
  • Page 13 BOX 1/3 20x90x1530 D (x2) 20x90x1900 E (x2) 20x90x420 F (x4) 20x90x1900 G1 (x1) 20x90x1900 G2 (x1) 20x90x1900 H1 (x1) 20x90x1900 H2 (x1) 20x65x1935 I (x1) 32x32x205 J (x2) 24x55x1027 K (x2) 25x45x282 L (x3) 25x35x282 M (x1) 13/19...
  • Page 14 BOX 2/3 90x860x1450 C (x2) BOX 3/3 90x860x1070 A (x1) 90x860x1070 B (x1) 14/19...
  • Page 15 5 x28 M8x30mm 1 x8 3 x1 4 x8 M6x100mm M6x13mm 15/19...
  • Page 16 1 x14 3 x1 4 x14 M6x100mm M6x13mm 2 x24 3 x1 M6x35mm 16/19...
  • Page 17 6 x4 M10x125mm 3 x1 8 x8 M6x40mm 17/19...
  • Page 18 3 x1 7 x2 8 x4 M3.5x16mm M6x40mm 3 x1 7 x4 8 x2 9 x2 M3.5x16mm M6x40mm M6x20mm 18/19...
  • Page 19 10 x2 11 x4 12 x2 13 x2 14 x2 M4x16mm M4x30mm 25 X 280mm 32mm 19/19...
