Toshiba Satellite M35X-S309 Specifications

TOSHIBA

Satellite M35X

Model Name Description
M35X-S309 Intel Pentium M Processor 710, 15.4" WXGA, 256MB, 60GB (4200 RPM), DVD/CD-RW, TV-
out, IEEE 1394, 5-in1, 802.11bg, Microsoft® Windows® XP Home, 1-year Limited Warranty
M35X-S3091 Intel Pentium M Processor 710, 15.4" WXGA, 256MB, 60GB (4200 RPM), DVD/CD-RW, TV-
out, IEEE 1394, 5-in1, 802.11bg, Microsoft® Windows® XP Professional, 1-year Limited
Warranty
M35X-S329 Intel Pentium M Processor 725, 15.4" WXGA, 512MB, 80GB (4200 RPM), DVD/CD-RW, TV-
out, IEEE 1394, 5-in1, 802.11bg, Microsoft® Windows® XP Home, 1-year Limited Warranty
M35X-S3291 Intel Pentium M Processor 725, 15.4" WXGA, 512MB, 80GB (4200 RPM), DVD/CD-RW, TV-
out, IEEE 1394, 5-in1, 802.11bg, Microsoft® Windows® XP Professional, 1-year Limited
Warranty
M35X-S349 Intel Pentium M Processor 735, 15.4" WXGA TruBrite™ CSV, 512MB, 80GB (4200 RPM),
DVD-SuperMulti, TV-out, IEEE 1394, 5-in1, 802.11bg, Microsoft® Windows® XP Home, 1-year
Limited Warranty
M35X-S3491 Intel Pentium M Processor 735, 15.4" WXGA TruBrite™ CSV , 512MB, 80GB (4200 RPM),
DVD-SuperMulti, TV-out, IEEE 1394, 5-in1, 802.11bg, Microsoft® Windows® XP Professional,
1-year Limited Warranty

System Characteristics

Operating System
• Microsoft® Windows® XP Home
• Microsoft® Windows® XP Professional
Processor and Chipset
Intel® Centrino™ Mobile Technology featuring:
• Choice of processors:
Intel Pentium® M processor 710 [2MB Level 2 cache,
o
Processor speed 1.40GHz 400MHz Front Side Bus ("FSB")],
Intel Pentium® M processor 725 [2MB Level 2 cache,
o
Processor speed 1.60GHz 400MHz Front Side Bus ("FSB")],
Intel Pentium® M processor 735 [2MB Level 2 cache,
o
Processor speed 1.70GHz 400MHz Front Side Bus ("FSB")],
• Intel 855GME system chipset
• Intel PRO/Wireless 2200BG
Memory
• 256MB, 512MB, or 1024MB PC2700 DDR333 SDRAM 2.5V
SODIMM Memory modules; expandable to 2048MB (both slots
may be occupied)
Mass Storage
2
Choice of Hard Disk Drives :
• 80GB (4200 RPM), 60GB (4200 RPM), Enhanced IDE (ATA-5)
hard disk drive; 9.5mm height; user removable
Choice of Optical Disk Drives:
• Fixed Bay DVD-ROM/CD-RW, 5.25" EIDE, 12.7mm height.
Compatibility: CD-ROM (read), CD-R (read), CD-RW
(read/write), DVD-ROM (read), DVD-R (read), DVD-RW
(read), DVD-RAM (read)
or,
• Fixed Bay DVD Super Multi Drive, 5.25" EIDE, 12.7mm height.
Capability: CD-ROM (read), CD-R (read/write), CD-RW
(read/write), DVD-ROM (read), DVD-R (read/write),
DVD-RW (read/write), DVD+R (read/write), DVD+RW
(read/write), DVD-RAM (read/write)
Optional Floppy Disk Drive
• External USB Floppy Drive, 3.5", 1.44MB
3
Display
• 15.4" diagonal WXGA TFT active-matrix LCD; internal display
supports up to 16M colors at 1280 x 800 (WXGA)
• Maximum Brightness 150 Cd/m
• Brightness Control
or,
• 15.4" WXGA TFT active-matrix TruBrite™ LCD; internal display
supports up to 16M colors at 1280 x 800 (WXGA)
• Maximum Brightness 200 Cd/m
• Brightness Control
Graphics
• Intel 855GME, 16MB-64MB (DVMA) shared video memory
1
2
2
Input Devices
• Keyboard: Full sized 85 keys with 12 function keys, 2.7mm key
stroke, 6mm height; Dedicated Windows® & Application keys
support; HotKey function
• Mouse: Touch Pad
Expandability
• 2 Expansion memory slots (including Main Memory)
• 1 PC Card slots support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
4
Communications
• Integrated V.92 modem
• Integrated 10/100Base-TX
• Integrated Wi-Fi compliant wireless LAN Intel PRO/Wireless
802.11bg
Ports
Standard
• RGB (monitor) port
• TV-out (S-Video)
• 3 Universal Serial Bus (USB) ports (v2.0)
• External Microphone jack
• Headphone jack
• RJ-45 LAN port
• RJ-11 modem port
• IEEE 1394
Configured (Only available on certain models)
• Parallel port
• Infrared port
• 5-in-1 Multimedia port (SD, Memory Stick, MMC, xD-picture card,
Memory Stick Pro)
Physical Description
• Dimensions (WxDxH Front/H Rear): 14.4" x 10.8" x 1.16"/1.48"
• Weight
5
: Starting at 6.6 lbs depending upon configuration
• LED Indicators: DC-In, Power, Primary Battery, Hard Drive,
CD/DVD-ROM, Multiple Digital Media, Wireless indicator, Caps
Lock, Arrow Lock, Numeric Lock, Main Battery Charging Status,
Sleep Suspend Mode.
Sound
• Realtek ALC250 Software Sound
• 16-bit stereo; Built-in stereo speakers, Built-in microphone
• Direct 3D Sound; DirectSound, 3D Sound , Direct Music, MIDI
(playback)
• Sound Volume Control Dial
Power Supply
• 65W (19V 3.42A) Auto-sensing external AC Adapter, 100-240V /
50-60Hz input.
6
Battery
•
8-cell (4300mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
• Battery Life (Normal Mode): Battery Life: Up to 4 hours (measured
by MobileMark™**
Security
• Slot for cable lock, HDD, memory (by screw only), User Power-on
password, Supervisor Password, Screen Blank (by Hotkey),
Screen Saver (by software).
Part Number UPC Code
PSA72U-01400U 032017275024
PSA72U-01400Y 032017272415
PSA72U-00V00U 032017269989
PSA72U-00V00Y 032017269996
PSA72U00W00X 032017270008
PSA72U00W00Z 032017270015
