35W COB LED Work Light w/Telescopic Stand
Features:
Super bright 35 Wa COB LED
Heavy-duty industrial design with diecast aluminum housing
16 . water-resistant power cord remains exible in cold weather
Quick fastening light head for easier adjustment
160 degree horizontal rota on on base
Rota ng telescopic stand easily folds for storage and extends from 25" to 72"
IP67 rated for dust and water resistance
CSA outdoor cer
cate
Long beam distance
Power Cord: 18/3 SJTW
Lumens: 4200
Lux: 1300
ATD-80335
Instruction Manual
Advertisement
Table of Contents
Related Manuals for ATD Tools SABER ATD-80335
Summary of Contents for ATD Tools SABER ATD-80335
- Page 1 ATD-80335 35W COB LED Work Light w/Telescopic Stand Instruction Manual Features: Super bright 35 Wa COB LED Heavy-duty industrial design with diecast aluminum housing 16 . water-resistant power cord remains exible in cold weather Quick fastening light head for easier adjustment 160 degree horizontal rota on on base Rota ng telescopic stand easily folds for storage and extends from 25”...
- Page 2 General Safety Warnings: WARNING: and warnings contained in this manual should be read and understood before using this light. Do not allow anyone to use or operate this light un l they have read this manual and have developed a thorough understanding of how this light works. Failure to observe any of the following instru ons could result in severe personal injury to light user and bystanders, or cause damage to the light and property.
- Page 3 WARNING: Before a light to a power supply, always check to ensure the power supply corresponds to the voltage on the nameplate of the light. A power supply with a voltage greater than that sp ed for the light can result in serious injury to the user, as well as damage to the light.
- Page 4 the motor of your tool. If in doubt, always use a larger gauge cord. Be sure to check the voltage requirements of the light to your incoming power source. NOTE : The table below shows the correct size to use according to cord length and the amperage draw of the light ed on the nameplate).
- Page 5 ATD 80335 Assembly Instruc on A: Ref# Light head Bolt 1/4" Flat washer Spring washer Bracket Light head bracket 1) Insert bolt (02) through the light head bracket (06) slide spring washer (04) and t washer (03) to the bolt (02) and then thread bolt (02) to the tripod stand as shown illustra above.
- Page 6 ATD-80335 CREW PRT80335-14 O RING...
- Page 7 ATD-80335 STAND PARTS ITEM# ORDERING PART# PART DESCRIPTION PRT80422-30-1 UPPER TELESCOPING NUT ASSY (SMALL) PRT80422-30-2 LOWER TELESCOPING NUT ASSY (LARGE) PRT80422-30-3 CASTER FOR ROLL AROUND STAND PRT80420-30-1 HINGE BASE, 3 HINGES, UPPER HINGE SLIDE Learn more about hand lamps on our website.
