Toshiba Satellite M205-S4806 Specifications

Satellite M205 Detailed Product Specification
Model Name M205-S4806
:
C1 2
Operating System
• Genuine Windows Vista ®
Home Premium (32-bit version)
Processor and Chipset
® ®
Intel Centrino Processor Technology featuring:
• Intel
®
Core™ 2 Duo Processor T5450
o 1.66GHz, 2MB L2, 667MHz FSB
• Mobile Intel
®
GM965 Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
®
o Intel Wireless WiFi Link 4965AGN (802.11a/g/n)
5
Memory
• Configured with 2048MB PC5300 DDR2 SDRAM (both memory slots
may be occupied). Maximum capacity 4096MB
6
Hard Disk Drive
• 200GB (5400 RPM); Serial ATA hard disk drive
Fixed Optical Disk Drive
• DVD SuperMulti (+/-R double layer) with Labelflash™ drive supporting
11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (16x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-
RAM (5x)
o Supports Labelflash™ media to burn high quality labels directly
on the disk
8
Display
• 14.1" diagonal widescreen TruBrite™ TFT LCD display at 1280x800
native resolution (WXGA)
o Native support for 720p content
9
Graphics
• Mobile Intel® Graphics Media Accelerator X3100 with 128MB-358MB
dynamically allocated shared graphics memory
Sound
• Built-in stereo speakers
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• 86 key US keyboard
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Control Buttons:
o Internet button to launch default browser
o CD/DVD control buttons (Play/Pause, Stop, Prev Track, Next
Track)
Communications
• Webcam and microphone built into LCD bezel
• Modem
10
• 10/100 Base-TX Ethernet
• Integrated Wi-Fi
®
compliant wireless:
®
o Intel Wireless WiFi Link 4965AGN (802.11a/g/n)
Expandability
• 2 main memory slots. Both slots may be occupied.
• One PCMCIA – Type II/Type I Card Slot
• 5-in-1 Bridge Media Adapter
o Secure Digital, Memory Stick™, Memory Stick PRO™, Multi
Media Card, xD Picture Card [shared slots]
Ports
• Video
o RGB (monitor) output port
Part Number: PSMC3U-06H00W
3
4
7
11
4
© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite M205-S4806 BTS Rev. 1.00 2007-11-13 AP T20070905 CB1.30
This product specification is variable and subject to change prior to product launch.
1
o S-Video output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o USB v2.0 – 4 ports
Physical Description
• Dimensions (WxDxH Front/H Rear): 13.5" x 9.53" x 1.33" without feet
o Weight: Starting at 5.5lbs depending upon configuration
• LCD Cover Color: Onyx Blue Metallic
Power
• 75W (19V x 3.95A) 100-240V AC Adapter
o Dimensions (WxDxH): 5.04" x 1.20" x 2.01"
o Weight: starting at 0.77 lb
13
Battery
• 4000mAh Lithium Ion battery pack
C1
Software
• Toshiba Software and Utilities
TOSHIBA Value Added Package
o
Electronic User's Guide
o
TOSHIBA ConfigFree®
o
TOSHIBA Disc Creator
o
TOSHIBA DVD Player
o
TOSHIBA Extended Tiles for Windows Mobility Center
o
TOSHIBA Speech System
o
• Third-party Software
o TOSHIBA Games Console, designed by WildTangent
o Microsoft Works Version 9.0
®
o Sun Java™ 2 Runtime Environment
o Adobe
o Google™ Desktop
o Google™ Toolbar
o Google™ Picasa™
®
o Ulead
o Earthlink
o PeoplePC Internet Access Service
• Trial Software
o Microsoft Office Trial Home and Student 2007 Edition (60-day trial)
o McAfee
o memeo AutoSync and memeo AutoBackup
o Norton™ Confidential
• Special Offers
o Microsoft
o Shutterfly digital photo print provider
o Napster
o eMusic MP3 Music Download Subscription Service
o Computrace
o VONGO , Starz Entertainment Movie Download Service
o Skype™
o PhotoWorks
®
o Intuit
Environmental Specifications
15
Temperature
Thermal Gradient
Relative Humidity
(non-condensing)
Altitude
(relative to sea level)
Shock
Vibration
UPC: 883974026210
14
® ®
Acrobat Reader
DVD MovieFactory® 5 for TOSHIBA
®
Internet Access Service
®
Internet Security Suite (30-day trial)
®
Office Live
®
Music Download Subscription Service
® ®
LoJack for Laptops
®
digital photo print provider
®
Quickbooks Financial Center
Operating
5° to 35° C
(41° to 95° F)
18° C per hour (max)
20% to 80%
0 to 3,000 meters
10G
0.5G
12
®
Non-operating
-20° to 60° C
(-4° to 140° F)
18° C per hour (max)
10% to 90%
0 to 10,000 meters
60G
1.0G
