Summary of Contents for Inter-m ER-6116
- Page 1 Operation Manual Emergency Router ER-6116 * Rack mount products in the Western Hemisphere(North America, South America, and the Caribbean) do not have handles installed due to customer preference.
- Page 2 A personal welcome to you from the management and employees of Inter-M All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
-
Page 3: Table Of Contents
....................4 Front Panel ............................6 Rear Panel ............................7 Applications ............................9 Block Diagram ..........................10 Specifications ..........................11 Service ............................12 Procedures............................12 Schematic.............................12 Parts List ............................12 Warranty ............................12 "We, Inter-M to apply the appropriate set of E4 & Class A for Electromagnetic Environment Condition." ER-6116... -
Page 4: Unpacking
EMERGENCY ROUTER Unpacking Unpacking Although your ER-6116 is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. As with most electronic devices, we strongly recommend you to retain the original packaging. In the unlikely event the product must be returned for servicing, the original packaging (or reasonable equivalent) is required. -
Page 5: Features
Scenario data written to PC is saved in built-in memory; no problems will occur as a result of a PC failure. - 99 MESSAGES CAPACITY PV-6232 (VOICE FILE) enables use of 99 messages. - SYSTEM EXPANSION Through RS-485 communication, it can be expanded to maximum 10 systems. ER-6116... -
Page 6: Equipment Setting And Checking
A) 1~99 track can be used as the scenario sound source among sound sources saved in PV-6232. B) To save the sound source in PV-6232 - Add 001~099 in front of file name to be used as the sound source in PC to properly archive/indicate each track’s number. ER-6116... - Page 7 B) Connect PV-6232 to PC to create folders as below. Copy the file used as the default emergency sound source to ‘IMSND’ folder; name it ‘EMORG.mp3‘. ※ Caution: if folder structure and file name is different, sound source will not transmit when emergency broadcasting. ER-6116...
-
Page 8: Front Panel
If this button is pushed during an EM scenario caused by a fire contact point input, scenario operation will be stopped and a basic message will be transmitted only to zones where contact point is input. 4. BUZZER OFF BUTTON Buzzer will be generated in case of communication error. It is used to turn off buzzer notifications. ER-6116... -
Page 9: Rear Panel
Refer to Equipment Setting and Checking (page 4) for detailed setting methods. Caution: Communication error may occur if setting is performed incorrectly. 3. RS-232 TERMINAL 1) It can be used when playing the EM scenario message by connecting to PV-6232(VOICE FILE). ER-6116... - Page 10 Statuses of contact point output are as follows. (Opposite operations for each other) RELAY OUTPUT System Mode STANDBY OPEN CLOSE FIRE Contact Point CLOSE OPEN 7. DC INPUT TERMINAL - Power input terminal. Check polarity before connecting DC 24V. - When connecting to PD (Power Distributor), connect to unswitched terminal. ER-6116...
-
Page 11: Applications
9 10 11 12 13 14 15 16 LOAD OPEN SPEAKER OUTPUT INPUT DC 24V ADDRESS 1 2 3 4 5 6 7 8 9 10 ER-6116 LINK FIRE SENSOR 1 2 3 4 5 6 7 8 COM RELAY DC 24V VOICEFILE OUTPUT TERM. -
Page 12: Block Diagram
EMERGENCY ROUTER Block Diagram Block Diagram ER-6116... -
Page 13: Specifications
EMERGENCY ROUTER Specifications Specifications ER-6116 Channel 16CH Communications Protocol LINK IN/OUT RS-485 (Maximum 1km/3,280 feet) VOICE FILE RS-232 (Maximum 12m/40 feet) Fire Sensor Dry Contact Operating Temperature -10°C ~ +40°C / 14°F ~ 104°F Power Source DC 24V, 100mA Weight (Set) 2.8kg/6.2lbs... -
Page 14: Service
To obtain specific warranty information and available service locations contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region. - Page 15 EMERGENCY ROUTER ER-6116...
- Page 16 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
