- Page 1 USER MANUAL...
-
Page 2: Table Of Contents
Definitions WARNING: Indicates a potentially hazardous situation, which, if not avoided, may result in minor or moderate injury. CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may result in damage to the device. NOTE: Used to call attention to notable information that should be followed during use. Contents Definitions ............................ -
Page 3: Important Safety Information
Important Safety Information WARNING: Failure to follow these instructions could result in injury, or damage to the CELLER8®, CELLER8® Mat, or other property. Read all the information below before using the CELLER8® or CELLER8® Mat. WARNING: Do not use the CELLER8® products if fitted with a Pacemaker, ICD or any other electrical implants. - Page 4 CAUTION: Never store CELLER8® or CELLER8® Mat in a Vehicle in cold or hot weather. Please refer to the technical specification for storage temperatures and humidity ranges. CAUTION: Never store CELLER8® for prolonged time with the battery charge depleted. NOTE: The CELLER8® products are not medical devices and should not be used as a substitute for professional medical judgment.
-
Page 5: Intended Use
Intended Use The CELLER8® is a non-invasive Pulsed Electromagnetic Field (PEMF) device intended to be used as a localised PEMF application or to power or alongside the CELLER8® Mat for a full body PEMF application. The CELLER8® and CELLER8® Mat deliver magnetic therapy using electromagnetic fields generated by copper coils and is used to improve overall general wellness as part of a healthy lifestyle. -
Page 6: Charging The Celler8
Charging the CELLER8® 1. Charging Port 2. CELLER8® Mat Port To charge the CELLER8®, connect the pre-approved AC Power Adaptor provided to the Charging Port (1) of the CELLER8®. Then connect the Power Adaptor to the Mains. WARNING: Only use the pre-approved AC charging adaptor, supplied with CELLER8®️ products and ensure that it is plugged into a mains location that is safe and easily accessible. -
Page 7: Setting Up The Celler8
CELLER8® Switched Off When the CELLER8® is switched off and plugged into mains power, the CELLER8® will be charging and an animated battery will appear onscreen. CELLER8® Switched On When the CELLER8® is switched on and plugged into mains power, the CELLER8® will be charging and the battery status can be found in the upper, righthand corner. - Page 8 CELLER8® + CELLER8® Mat Layout 1. CELLER8® 2. Strap 3. AC Power Adaptor 4. CELLER8® Mat Cable 5. CELLER8® Mat Switching On/Off the CELLER8® To switch the CELLER8® on, push down the Control Dial for 2 seconds. An animation will appear onscreen, followed by the Menu screen, and Control Dial will illuminate to indicate that the CELLER8®...
- Page 9 Setting up the Strap The CELLER8® comes with a dedicated, elasticated strap, to help keep the CELLER8® in place when being used for localised application. To set-up, slide the Strap through the clip on the back of the CELLER8®. Holding the CELLER8® in place, wrap the elasticated strap around the area of the body. Secure the strap by using the Velcro.
- Page 10 Setting up the CELLER8® Mat The CELLER8® can be used alongside the CELLER8® Mat for full-body PEMF application. The CELLER8® can be used as the controller for the CELLER8® Mat, or it can be used at the same time for both a full-body and localised PEMF application, as shown below. The CELLER8®...
- Page 11 Selecting a CELLER8® Application When the CELLER8® is switched on, the screen will display the Application Menu. There are three application options: CELLER8® (Controller) The CELLER8® application will apply localised PEMF. CELLER8® Mat The CELLER8® Mat application will only use the CELLER8®...
- Page 12 Selecting a CELLER8® Program Once the desired applicator has been selected, the Program Menu will appear. There are 4 pre-set programs to choose from: • Morning • Evening • Meditation • Night Alternatively, you can opt for the Custom program. More information about the programs can be found in the About CELLER8®...
- Page 13 Setting CELLER8® Mat CELLER8® 1 Gauss/ 100 µT 2 Gauss/ 200 µT The localised CELLER8® will reach 2 Gauss/ 200 µT 4 Gauss/ 400 µT intensities up to 100 Gauss 5 Gauss/ 500 µT 10 Gauss/ 1,000 µT (10,000 Microtesla). 10 Gauss/ 1,000 µT 20 Gauss/ 2,000 µT The full body CELLER8®...
-
Page 14: Creating A Custom Celler8® Program
To pause the program, press the Control Dial; press once if the screen is active, or twice if the screen has dimmed. A prompt will appear giving the option to Stop or Resume the program. If the program is to be resumed after a break, use the Control Dial to ensure Resume is highlighted and Control Dial to resume the current session. -
Page 15: Settings Menu
Once the parameters for the Custom program have been made and confirmed, a screen will appear showing the new values. NOTE: Any changes to the Custom program will be remembered once the device has been switched off in the memory as the last used Custom program. - Page 16 In the Settings Menu, Sound can be enabled/disabled and the Polarity of the CELLER8® products can be altered. The Settings Menu also displays the current firmware version. Enabling/Disabling Sound Use the Control Dial to highlight Sound. Press the Control Dial to enable/disable sound. When sound is disabled, no sound will play at the end of a PEMF session to signify the user.
- Page 17 If using the CELLER8® Mat, the grey side of the CELLER8® Mat is set to North as standard. To change the Polarity, in the Setting Menu, use the Control Dial to highlight Polarity. Press the Control Dial to change the Polarity. Use the Control Dial to navigate to Confirm and press the Control Dial to save the changes.
-
Page 18: About Celler8® Programs
When the Polarity is switched to South, the grey side of the CELLER8® Mat will be South. About CELLER8® Programs The CELLER8® has 4 pre-set programs to choose from: • Morning • Evening • Meditation • Night Alternatively, you can you opt for the Custom program. Morning Program (12Hz to 30Hz, stepping up every 5 seconds) The Morning Program uses a range of frequencies specifically for application at the earlier part of the day. -
Page 19: Device Care And Maintenance
The Night Program has been designed to be used at bed time. In this mode, it can be used for up to 12 hours, but is set for 2 hours as default. The device lights will dim in this mode and the sound will be disabled, even if the sound is selected enabled on the CELLER8®. - Page 20 Warning Screens Battery Charging When the CELLER8® is switched off and plugged into mains power, an animated battery will display onscreen to signify that the battery is charging. Batter Low The Battery Low screen will show when the device does not have enough battery to operate.
-
Page 21: Celler8® Technical Information
CELLER8® Technical Information CELLER8® and CELLER8® Mat Coil Locations The CELLER8® and CELLER8® Mat consist of copper coils which generate a magnetic field. A frequency generator is used to energize the coil to create a pulsed electromagnetic field. One large copper coil can be found in the CELLER8® and 12 copper coils can be found in the CELLER8®... -
Page 22: Celler8® + Celler8® Mat Technical Specification
CELLER8® + CELLER8® Mat Technical Specification 1G-100G (Gauss) Intensity Range 0.1mT-10mT (Milli-Tesla) 100μT-10,000μT (Micro-Tesla) Frequency Range 1-100Hz Programs 5 (including Custom) Application CELLER8® Mat, CELLER8®, and CELLER8® + CELLER8® Mat CELLER8®: 1 Number of Coils CELLER8® Mat: 12 Polarity North and South (user selectable) Waveform Square Pulsed Warranty... -
Page 23: List Of Celler8® Symbols
CELLER8® Strap Technical Specification Nylon Multi_lament 25% Materials Nylon Mono_lament 50% Elastane 25% Dimensions 100cm x 7.5cm Weight List of CELLER8® Symbols Icon Description Icon Description CELLER8® Back Program Battery Battery Full Battery Empty Battery Empty CELLER8® hexagon Meditation Program Custom Program Morning Program Evening Program... - Page 24 List of Packaging Symbols Symbol Description Manufactured by IPX0 – not protected against IPXO – not protected against water ingress water ingress Direct current CE mark Keep dry Consult instructions before use Serial Number UDI number Dispose of according to WEEE Class III appliance for use with a separate extra-low voltage external power supply Manufacturer logo...
-
Page 25: Warranty And Returns Information
Contact the local distributor for support and repairs for the CELLER8®. Contact Details: Phone: +44 (0) 1622 854864 Email: office@celler8.com Website: www.celler8.com Distributed by: NewMed Ltd Manufactured by Bedfont® Scientific Ltd. Station Yard, Station Road, Station Yard, Station Road, Harrietsham, Harrietsham, Maidstone, Kent, Maidstone, Kent, ME17 1JA... - Page 26 info@newmedltd.co.uk 0044 (0)1622 851122 0808 1689 282...
- Page 27 Disclaimer: The information contained in this manual is for informational and educational purposes only and come from our own experiences. The product does not claim to diagnose, treat, cure or prevent any medical conditions. Always consult your doctor.
- Page 28 Maidstone, Kent, ME17 1JA England ME17 1JA England Tel: +44 (0) 1622 854864. Email: office@celler8.com www.celler8.com © Bedfont Scientific Limited 2023 ® Issue 1 - June 2023, Part No: LAB875 Bedfont Scientific Limited reserves the right to change or update the ®...
