- Page 1 Operation Manual Network GPIO NCIO-1000...
- Page 2 A personal welcome to you from the management and employees of Inter-M All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
-
Page 3: Table Of Contents
Important Safety Instructions ....................2 Overview ..........................3 Features ..........................3 Contents and Accessories ....................3 Front Panel ........................4 Rear Panel ........................5 Operation .........................9 Applications ........................10 Block Diagram .......................11 Specifications .........................12 Service Procedures ........................15 Schematic........................15 Parts List.........................15 Variations and Options ....................15 Warranty ........................15 NCIO-1000... -
Page 4: Unpacking
NETWORK GPIO Unpacking Unpacking Although your NCIO-1000 is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. As with most electronic devices, we strongly recommend you retain the original packaging. In the un- likely event the product must be returned for servicing, the original packaging (or reasonable equivalent) is required. -
Page 5: Overview
NETWORK GPIO Overview Overview NCIO-1000 provides device control functions through contacts, RS-232C, and RS-422 communication in a network system that provides an integrated transmission solution through an automatic network infrastructure. Multiple devices can be controlled through contact, RS-232C, RS-422 communication by linking complex and extensive systems (PA, SR, AV) with each other. -
Page 6: Front Panel
※ If there is no operation of the display control switch for 30 seconds, OLED turns off and turns on when operated. 3. DISPLAY PANEL CONTROLLING SWITCH By turning the display control switch, the user can check the desired information. 4. POWER LED The green LED lights up when the instrument is powered on. NCIO-1000... -
Page 7: Rear Panel
4. CONTACT INPUT TERMINAL It is the terminal for inputting the contact point. Contact input of up to 16 channels can be received. When each channel becomes short with COM, a contact point is input. NCIO-1000... - Page 8 ※ For detailed wiring, please refer to the contact wiring method. ※ Because there is an error between voltage ranges, please use the recommended voltage. ※ Before connecting the contacts, be sure to check the polarity and be careful not to exceed the maximum of 60V. NCIO-1000...
- Page 9 It terminal is used to connect device to the network. Broadcasting can be controlled through integrated software. ※ For the setting method, refer to the integrated software manual. Please download the manual from the website (www.inter-m.net). <100 Base-T> <1G Base-T>...
- Page 10 NETWORK GPIO 10. RESET SWITCH If the user press the switch for more than 10 seconds, the settings of the device will be reset to factory defaults. NCIO-1000...
-
Page 11: Operation
DNS 8. 8. 8. 8 00:1d:1d:00:00:00 0.00 ① It is the standby screen of the device. The model name (NCIO-1000), software version, and network IP are displayed. ② In the standby screen, if the user turn the control switch on the front panel to the right, network-re- lated details (IP Address, Subnet mask, DNS Server, Mac Address) are displayed. -
Page 12: Applications
NETWORK GPIO Applications Applications NCIO-1000... -
Page 13: Block Diagram
NETWORK GPIO Block Diagram Block Diagram NCIO-1000... -
Page 14: Specifications
NETWORK GPIO Specifications Specifications NCIO-1000 DRY CONTACT INPUT : 1CH~16CH Contact Input/Output DRY CONTACT OUTPUT : 1CH~16CH UGA INPUT : 1CH~4CH Serial communications RS-232C, RS-422(485) Network communications 100/1000 Base-T (RJ-45) Operating Temperature -10℃~40℃ Operating Voltage 120-240V, 50/60Hz, DC 24V, 500mA... - Page 15 NETWORK GPIO ※ DIMENSIONS NCIO-1000...
- Page 16 5. In case of fixing by not using the included screws or screws of the same size, or using insufficient number of screws the manufacturer is not responsible for any safety accidents caused by this. Accessories included for fixing the product - Specification: SCREW M5x0.8P, L=12 - Quantity: 4pcs NCIO-1000...
-
Page 17: Service
To obtain specific warranty information and available service locations contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region. - Page 18 NOTE...
- Page 20 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
