Dnake E211 Quick Start Manual

Indoor monitor
Hide thumbs Also See for E211:

Advertisement

Quick Links

Download this manual
E211
QUICK START GUIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the E211 and is the answer not in the manual?

Questions and answers

Related Manuals for Dnake E211

Summary of Contents for Dnake E211

  • Page 1 E211 QUICK START GUIDE...
  • Page 2 REMARK Please follow the user manual for correct installation and testing. If there is any doubt please call our tech-supporting and customer center. Our company applies ourselves to reformation and innovation of our products. No extra notice for any change. The illustration shown here is only for reference.

  • Page 3: Table Of Contents

    CATALOG Pictures ..............1 Package Contents...........2 System Configuration ..........3 System Diagram............4 Installation..............7 Safety Instructions ..........11 For specific operation instructions, please scan the following QR code to obtain the full version of the User Manual.

  • Page 4: Pictures

    Volume decrease Volume increase Calling Master Answer/Hang up Station/SOS/ Relay 3 Unlock Relay 1 Microphone LED indicator light Handset(Optional) MODEL: E211/E211W Speaker Microphone mute DND/Relay 2 Volume decrease Volume increase Calling Master Answer/Hang up Station/SOS/ Relay 3 Unlock Relay 1...

  • Page 5: Package Contents

    PACKAGE CONTENTS MODEL: E211/E211W Indoor Monitor Bracket Screw Diode Wires Quick Start Guide MODEL: E211H/E211A Rear Cover Screw Diode Indoor Monitor Wires Handset Quick Start Guide...

  • Page 6: System Configuration

    SYSTEM CONFIGURATION System Configuration...

  • Page 7: System Diagram

    SYSTEM DIAGRAM Siren/Alarm Network (PoE) Power REC- +12V REC+ MIC- RS485 MIC+ +12V IN-DET 485+ HOOK-DET 485- Indoor Monitor Handset(Optional) 1. Power The power interface of Indoor Monitor connects to 12V DC power. +12V +12V DC 12V Power Interface 2. Network(PoE) Standard RJ45 interface is for the connection with PoE switch or other network switch.
  • Page 8 3. RS485 Interface Enable to connect equipment with RS485 interface. RS485 interface can output 12V/100mA power supply. If RS485 equipment to be connected doesn't require the power supply, there is no need to connect to +12V. +12V +12V RS485 Interface RS485 Equipment 4.
  • Page 9 5. Handset Interface Conector from Handset Handset(Optional) E211 Conector to Monitor REC- REC+ MIC- MIC+ IN-DET HOOK-DET...

  • Page 10: Installation

    INSTALLATION MODEL: E211/W211W(Surface Mounting-86 Mounting Box) Screws 86 Mounting Box Rear Cover Product dimension: 100x184x25mm Surface mounting product dimension: 100x184x28mm Installation Instructions: [Suggestion]: The camera should be 1450〜 1550mm above the ground. The camera at this Wall height can capture human face perfectly.
  • Page 11 MODEL: E211/W211W(Surface Mounting-118 Mounting Box) 118 Mounting Box Screws Rear Cover Product dimension: 100x184x25mm Surface mounting product dimension: 100x184x28mm Installation Instructions: [Suggestion]: The camera should be 1450〜 1550mm above the ground. The camera at this Wall height can capture human face perfectly.
  • Page 12 MODEL: E211H/W211A(Surface Mounting-86 Mounting Box) Screws Screws 86 Mounting Box Rear Cover Product dimension: 100x184x25mm Surface mounting product dimension: 100x184x28mm Installation Instructions: [Suggestion]: The camera should be 1450〜 1550mm above the ground. The camera at this Wall height can capture human face perfectly. 400~500mm...
  • Page 13 MODEL: E211H/W211A(Surface Mounting-118 Mounting Box) Screws 118 Mounting Box Screws Rear Cover Product dimension: 100x184x25mm Surface mounting product dimension: 100x184x28mm Installation Instructions: [Suggestion]: The camera should be 1450〜 1550mm above the ground. The camera at this Wall height can capture human face perfectly. 400~500mm...

  • Page 14: Safety Instructions

    SAFETY INSTRUCTIONS In order to protect you and others from harm or your device from damage, please read the following information before using the device. Do not install the device in the following places: Do not install the device in high-temperature and moist environment or the area close to magnetic field, such as the electric generator, transformer or magnet.
  • Page 15 V1.2 600110154102...
