- Page 1 USER MANUAL 24513 Maritime Wind Sensor...
-
Page 2: Table Of Contents
LAMBRECHT meteo | u[sonic]WS6 Content Warranty Description General Function Dimensioned drawing Message string WIMWV Setting into operation Unpacking Choice of the installation site Mounting Electrical connection Cable entries Start-up Functional test Service and maintenance Replacement of spare parts Repair procedures... -
Page 3: Warranty
Warranty Please note the loss of warranty and non-liability by unauthorized manipulation of the system. You need a written permission of the LAMBRECHT meteo GmbH for changes of system components. These activities must be operated by a qualified technician. The warranty does not cover: Mechanical damages caused by external impacts (e. -
Page 4: Dimensioned Drawing
LAMBRECHT meteo | u[sonic]WS6 2.3 Dimensioned drawing page – aem.eco... -
Page 5: Message String Wimwv
LAMBRECHT meteo | u[sonic]WS6 2.4 Message string WIMWV WIND DIRECTION AND WIND SPEED Example of data sequence with comma separated fields: $WIMWV,357.0,R,5.2,M,A*CS<CR><LF> field delimiter: , (comma) header: $WIMWV NORMS wind direction: 0.0 to 360.0 Emission R: relative wind direction EN 60945:2002 wind speed: 0.4 to 60.0... -
Page 6: Setting Into Operation
LAMBRECHT meteo | u[sonic]WS6 Setting into operation 3.1 Unpacking When removing the sensor from the original box take care not to damage the cup rotor and the wind vane. The measuring ele ments must not be used as a handle. -
Page 7: Electrical Connection
LAMBRECHT meteo | u[sonic]WS6 3.4 Electrical connection The cable is connected to the sensor by means of a splash-proof plug connection in the shaft of the sensor. Before mounting the sensor on the fitting tube, the cable with the plug connector has to be passed through the tube. The electrical connection of the different models can be found in the wiring diagram. -
Page 8: Cable Entries
LAMBRECHT meteo | u[sonic]WS6 3.5 Cable entries If the sensor is mounted in correct manner and connected with the right cable (accessory), you can attach the wires to power supply and signal outputs to data acquisition equipment (computer). The sensor requires a 12-pole CONINVERS plug connector of the series designation „TC“... -
Page 9: Repair Procedures
LAMBRECHT meteo | u[sonic]WS6 Wind Vane: The wind vane blades can be removed after loosening the three screws of each blade. After mounting of the new parts the wind vane has to be balanced. For this purpose the sensor must be held in a horizontal position (90°... -
Page 10: Disposal
LAMBRECHT meteo | u[sonic]WS6 Disposal LAMBRECHT meteo GmbH is listed and registered at the Stiftung Elektro-Altgeräte Register ear under: WEEE-Reg.-Nr. DE 45445814 In the category of monitoring and control instruments, device type: “Monitoring and control instruments for exclusively commercial use”. -
Page 11: Technical Data
Visualization and evaluation software MeteoWare-CS3 00.95800.010000 Data logger met[LOG] ID 00.14742.301002 Display unit METEO-LCD/NAV Copyright © 2023 LAMBRECHT meteo GmbH. All rights reserved. 24513-NMEA_b-de.indd 21.23 Information in this document subject to change without notice. Photo copyright: © Tamme - Adobe stock...
