GAS9670AS / GAS9670ASO
Natural Gas Conversion Kit Sold Separately
PROFESSIONAL INSTALLATION MANUAL
ASSEMBLY AND OPERATING IN STRUC TIONS
SAVE THIS MANUAL FOR FUTURE REFERENCE
NOTICE TO
PROFESSIONAL INSTALLER:
LEAVE THESE INSTRUCTIONS WITH THE
GRILL OWNER FOR FUTURE REFERENCE .
Natural Gas Conversion
Instructions for Model
WARNING
HAZARDOUS EXPLOSION MAY RESULT IF THESE
WARNINGS AND INSTRUCTIONS ARE IGNORED. READ
AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN
THIS MANUAL TO AVOID PERSONAL INJURY, INCLUDING
DEATH OR PROPERTY DAMAGE.

Advertisement

loading
Need help?

Need help?

Do you have a question about the GAS9670ASO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Member's Mark GAS9670ASO

Summary of Contents for Member's Mark GAS9670ASO

  • Page 1 LEAVE THESE INSTRUCTIONS WITH THE GRILL OWNER FOR FUTURE REFERENCE . Natural Gas Conversion Instructions for Model GAS9670AS / GAS9670ASO Natural Gas Conversion Kit Sold Separately PROFESSIONAL INSTALLATION MANUAL ASSEMBLY AND OPERATING IN STRUC TIONS SAVE THIS MANUAL FOR FUTURE REFERENCE...
  • Page 2 IMPORTANT SAFETY WARNINGS WE WANT YOU TO USE YOUR CONVERSION KIT FOR YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT THE ATTENTION TO POSSIBLE HAZARDS AS THE GRILL IS CONVERTED AND USED AS A NATURAL GAS GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS General Warnings ............3 Assembly Instructions .

  • Page 4: General Warnings

    DANGER Connection should be made by a professional service technician. Supply the technician with a copy of these instructions. Incorrect connection can result in a gas leak with possibility of fi re. GENERAL WARNINGS WARNING • Never use liquid propane gas in a unit designed for natural gas. •...

  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTIONS YOU MUST BE A PROFESSIONAL SERVICE TECHNICIAN TO CONVERT THIS GRILL. READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR OPERATING THE CONVERTED GRILL. The following tools are required to assemble the Conversion Kit: • Phillips and Flathead Screwdrivers •...
  • Page 6 CONVERSION INSTRUCTIONS GAS9670AS/ASO GAS MANIFOLD CAUTION: Some parts may contain sharp edges. Wear protective gloves if necessary. Note: Make sure all control knobs are in the off position, LP tank valve is closed and tank is disconnected from regulator and removed from grill. GAS MANIFOLD Step 1 Using an adjustable wrench to hold...
  • Page 7 Step 3 KNOB Remove two screws from each burner which are located in back of grill. BURNER Remove burners from back of grill. WING NUT VALVE NOZZLE Step 4 Remove wing nut from side burner. Carefully lift side burner up and away from valve nozzle.
  • Page 8 REMOVE SCREWS Step 5 Remove 2 screws from the back of the sear burner. Carefully lift sear burner up and away from the valve nozzle. Remove sear burner and sear burner grease tray. Use gas orifice tool to remove the LP Brass orifi ce from the sear burner valve.
  • Page 9 SIDE VIEW FIREBOX Step 6 FRONT Use the gas orifice tool to remove the PANEL LP brass orifice from each main burner valve, through the hole on the firebox front panel. Note: All orifices of the grill are double orifices (LP gas and natural gas).

  • Page 10: Connecting To Natural Gas Source

    CONNECTING YOUR GRILL TO THE NATURAL GAS SOURCE 1. Coat pipe nipple with gas resistant tefl on tape or pipe dope. Tighten quick-disconnect coupling onto pipe nipple that leads to natural gas supply (Figure A). 2. After grill is completely assembled, make sure natural gas supply valve is “OFF” and then connect natural gas hose to socket.

  • Page 11: Leak Testing

    WARNING • Never use your grill without leak testing all gas connections and hoses. See the section on “Leak Testing” in this manual for proper procedures. • Visually inspect the hose assembly prior to each use for evidence of damage, excess wear or deterioration.
  • Page 12 CHECKING FOR LEAKS: 1. Create a mixture of 50% water and 50% liquid dishwashing soap. Watch For Bub bles 2. Open the lid. 3. Ensure all control knobs are set to the “OFF” position. 4. Ensure gas hose is tightly connected to gas source. 5.

  • Page 13: Pre-Start Check List

    WARNING Property damage, bodily harm, severe burns, and death could result from failure to follow these safety steps. These steps should be performed after the grill has been assembled and prior to each use. DO NOT operate this grill until you have read and understand ALL of the warnings and instructions in this manual.
  • Page 14 FOR REPLACEMENT PARTS PLEASE CONTACT EMBERS GRILLS CUSTOMER SERVICE DEPARTMENT AT 1-855-735-9922 OR EMAIL US AT: help@embersgrills.com. HOURS OF OPERATION ARE 8:00A.M. TO 5:00P.M. MONDAY THROUGH FRIDAY. PARA PIEZAS DE REPUESTO PÓNGASE EN CONTACTO CON EL DEPARTAMENTO DE ATENCIÓN AL CLIENTE DE EMBERS GRILLS AL 1-855-735- 9922 O ENVÍENOS UN CORREO ELECTRÓNICO A: help@embersgrills.com.
