Member's Mark GAS9670AS Owner's Manual

6 burner gas grill with sear & side burners
Hide thumbs Also See for GAS9670AS:
Table of Contents

Advertisement

Quick Links

6 Burner Gas Grill with Sear
& Side Burners
OWNER'S MANUAL
ASSEMBLY AND OPERATING IN STRUC TIONS
SAVE THIS MANUAL FOR FUTURE REFERENCE
Model GAS9670AS / GAS9670ASO
WARNING/ADVERTENCIA
NOTICE TO INSTALLER:
LEAVE THESE INSTRUCTIONS
HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS
WITH GRILL OWNER FOR FUTURE
AND INSTRUCTIONS ARE IGNORED. READ AND FOLLOW ALL
WARNINGS AND INSTRUCTIONS IN THIS MANUAL TO AVOID
REFERENCE .
PERSONAL INJURY, INCLUDING DEATH OR PROPERTY DAMAGE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GAS9670AS and is the answer not in the manual?

Questions and answers

Related Manuals for Member's Mark GAS9670AS

Summary of Contents for Member's Mark GAS9670AS

  • Page 1 6 Burner Gas Grill with Sear & Side Burners OWNER’S MANUAL ASSEMBLY AND OPERATING IN STRUC TIONS SAVE THIS MANUAL FOR FUTURE REFERENCE Model GAS9670AS / GAS9670ASO WARNING/ADVERTENCIA NOTICE TO INSTALLER: LEAVE THESE INSTRUCTIONS HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS WITH GRILL OWNER FOR FUTURE AND INSTRUCTIONS ARE IGNORED.
  • Page 2 IMPORTANT SAFETY WARNINGS WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR GRILL.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS: General Warnings ..........3-4 LP Gas Cylinder (Tank) Specifi cations and Installation .

  • Page 4: General Warnings

    GENERAL WARNINGS: WARNING • Leak test all connections before fi rst use, even if grill was purchased fully assembled and after each tank refi ll. Check propane tank rubber seal for damage. • Always check grill and propane tank prior to each use as indicated in “Checking for Leaks” & “Pre- Start Check List”...

  • Page 5: Lp Gas Cylinder (Tank) Specifications And Installation

    • Grill is hot when in use. To avoid burns: • DO NOT attempt to move the grill. • Block wheels so grill does not move. • Wear protective gloves or oven mitts. • DO NOT touch any hot grill surfaces. •...
  • Page 6 LP GAS CYLINDER (TANK) SPECIFICATIONS: LP gas cylinder (not supplied with this grill) The LP (Liquid Propane) gas cylinder specifi cally designed to be used with this grill must be 12” (30.5 cm) diameter x 18” (45.7 cm) tall and have a 20 lb. (9.1 kg) capacity incorporating a Type 1 cylinder valve and an over-fi lling protection device (OPD).

  • Page 7: Hose & Regulator Specifications And Installation

    LP GAS CYLINDER (TANK) RUBBER SEAL INSPECTION: • Inspect propane tank valve rubber seal for cracks, wear or deterioration prior to use. A damaged rubber seal can cause a gas leak, possibly resulting in an explosion, fi re or severe bodily harm. •...

  • Page 8: Leak Testing

    HOSE AND REGULATOR: Your grill is equipped with a Type 1 connection device with the following features: 1. The system will not allow gas fl ow from cylinder until a positive connection to valve has been made. Note: The cylinder valve and all grill burner knobs must be turned OFF before any connection is made or removed.
  • Page 9 DANGER To prevent fi re or explosion hazard: • DO NOT smoke or permit ignition sources in the area while conducting a leak test. • Perform test OUTDOORS in a well ventilated area that is protected from the wind. • Never perform a leak test with a match or open fl ame.

  • Page 10: Pre-Start Check List

    PRE-START CHECK LIST: DANGER Property damage, bodily harm, severe burns, and death could result from failure to follow these safety steps. These steps should be performed after the grill has been assembled and prior to each use. DO NOT operate this grill until you have read and understand ALL of the warnings and instructions in this manual.
  • Page 11 MATCH LIGHTING THE MAIN BURNER: 1. Open lid before lighting burner. MATCHLIGHTER 2. Make sure all control knobs are “OFF” . 3. Place a paper match in the end of the matchlighter. Strike match and place through the cooking grate approximately 1/2” (1 to 2 cm) from the burner to be lit.

  • Page 12: Operating The Grill

    5. If ignition does NOT occur in 5 seconds, turn control knob to “OFF” , wait 5 minutes to allow gas to dissipate and repeat lighting procedure. 6. To turn off, turn control knob clockwise until it locks in the “OFF” position. Note: If burner does not light or fl ame is too low, See “Trouble Shooting”...

  • Page 13: Using Other Features Of The Grill

    • If grease fi re occurs while lid is closed, leave lid closed, as a sudden burst of air may increase fl ames. Turn burner knobs to “OFF” , turn off LP cylinder valve. Allow grease to burn out. • Never pour water on a grease fi re as grease may splatter/spread and could result in bodily injury or property damage.

  • Page 14: Proper Care And Maintenance

    PROPER CARE & MAINTENANCE: WARNING: If a bristle brush is used to clean any of the cooking surfaces, ensure no loose bristles remain on the cooking surfaces prior to grilling as loose bristles may attach to food. CLEANING INTERIOR OF GRILL: •...
  • Page 15 BURNER ASSEMBLY/MAINTENANCE: • Although your burners are constructed of stainless steel, they may corrode as a result of the extreme heat and acids from cooking foods. Regularly inspect burners for cracks, abnormal holes, and other signs of corrosion damage. If found, replace burner.

  • Page 16: Transporting And Storage

    TRANSPORTING AND STORAGE: WARNING • Never move a grill when hot or in use. • Make sure that cylinder valve is closed and burner knobs are in the off position. • DO NOT store a spare LP gas cylinder (fi lled or empty) under or near the grill. •...

  • Page 17: Trouble Shooting

    TROUBLE SHOOTING: Problem Possible Cause Prevention/Cure Burner will not light LP gas tank valve is closed Make sure regulator is securely attached to the LP gas tank, turn LP gas tank valve to “OPEN” LP gas tank is low or empty Check if LP gas tank is empty.

  • Page 18: Grill Cooking Tips

    Problem Possible Cause Prevention/Cure Flame blows out High or gusting winds Do not use grill in high winds Low on LP gas Replace or refi ll LP gas tank Burner holes may be obstructed Refer to “Burner Assembly/Maintenance” instructions Flow limiting device tripped Refer to “Regulator Resetting Procedure”...

  • Page 19: Assembly Instructions

    READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR OPERATING YOUR GRILL. WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN AS SEM BLING THIS UNIT. The following tool is required to assemble this Member's Mark 6 Burner Gas Grill: • Phillips Screwdriver PARTS LIST:...
  • Page 21 Remove screws Step 1 • Remove 4 screws Remove screws • Loosen 4 screws from right side and 3 screws from left side of the grill body 3-4 turns, do not remove. Loosen screws Step 2 • Remove screw from LEFT SIDE TABLE...
  • Page 22 LEFT SIDE TABLE Step 3 • Install SIDE TABLES RIGHT SIDE using key TABLE holes. • Tighten 4 screws on right side. • Do not tighten screws on LEFT SIDE TABLE. Step 3a LEFT SIDE TABLE • Install 2 screws. DO NOT FULLY TIGHTEN.
  • Page 23 RIGHT SIDE Step 3b TABLE • Install 2 screws and tighten. (removed from step 1) Step 4 • Install screw and tighten. (removed from step 2) • Tighten 3 screws (see step 3) • Tighten 2 screws (see step 3a)
  • Page 24 WING NUT SIDE BURNER Step 4a • Remove WING • Remove SIDE BURNER SIDE BURNER VALVE Step 4b • Install SIDE BURNER VALVE in control panel using key holes and tighten screws. Tighten screws SIDE BURNER VALVE...
  • Page 25 Step 4c BURNER • Install SIDE VENTURI BURNER • Make sure BURNER VENTURI fi ts over VALVE NOZZLE. • Tighten WING NUT and attach IGNITER WIRE to ELECTRODE. VALVE NOZZLE WING NUT ELECTRODE IGNITER WIRE...
  • Page 26 Step 5a • Remove 2 screws from SEAR BURNER • Remove SEAR BURNER Step 5b • Install SEAR BURNER VALVE in control panel using key holes SEAR BURNER VALVE and tighten screws. Tighten screws...
  • Page 27 Step 5c • Install SEAR BURNER and tighten 2 screws Step 5d • Make sure BURNER VENTURI fi ts over VALVE NOZZLE VALVE NOZZLE BURNER VENTURI...
  • Page 28 Step 6a • Attach IGNITER WIRES to IGNITER IGNITER SWITCH SWITCH. IGNITER WIRES Step 6b SEAR BURNER ELECTRODE • Attach SEAR BURNER ELECTRODE WIRE to IGNITER. IGNITOR WIRE...
  • Page 29 WARMING RACK Step 7 COOKING GRATES • Install HEAT TENTS • Install COOKING GRATES HEAT TENTS • Install WARMING SEAR BURNER SIDE BURNER RACK GRATE GRATE • Install SEAR BURNER GRATE and SIDE BURNER GRATE • Install SEAR BURNER KNOB and SIDE BURNER KNOB SEAR BURNER...
  • Page 30 GREASE TRAY HANDLE Step 8 • Install GREASE TRAY HANDLE. Step 9 • Install GREASE CUP and SEAR BURNER GREASE TRAY. SEAR BURNER GREASE TRAY GREASE CUP...
  • Page 31 Step 10 • Install DOOR HANDLES. DOOR DOOR HANDLES HANDLES Step 11 AA BATTERY • Install AA BATTERY for ELECTRONIC IGNITION ELECTRONIC IGNITION...
  • Page 32 Model GAS9670AS Assembled...
  • Page 33 8:00 a.m. A las 5:00 p.m. DE LUNES A VIERNES. FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT: www.embersgrills.com ©2018 The Boltz Group LLC Owner’s Manual for Model Addison, Texas 75001 U.S.A OM9670AS/9670ASO Manual del Propietario para el Modelo www.embersgrills.com GAS9670AS / GAS9670ASO 1018...
