PGA460-Q1 Ultrasonic Signal Conditioner EVM With
The PGA460-Q1 EVM evaluation module (EVM) allows users to evaluate the functionality of Texas
Instrument's PGA460-Q1 ultrasonic sensor-signal conditioner IC. The PGA460-Q1 is a fully integrated
system-on-chip, analog front-end (AFE) device for ultrasonic sensing. This user's guide describes both the
hardware platform containing a sample PGA460-Q1 device and the graphical user interface (GUI)
software used to configure the functionality and diagnostics. In addition to evaluating the PGA460-Q1
device, the other objective of this board is to display the ultrasonic echo profile and measurement results
of either a transformer driven closed-top transducer or direct-driven open-top transducer when using the
GUI.
NOTE: Texas Instruments recommends using the PGA460-Q1 EVM user's guide (this document)
after reading and following the steps listed in the PGA460-Q1 EVM Quick Start Guide. To
download this guide, go to the product folder: www.ti.com/product/PGA460-Q1.
...................................................................................................................
1
2
.....................................................................................................................
3
4
5
..................................................................................................................
6
1
2
3
4
5
6
7
8
Tree View Page Listing
9
10
11
12
13
14
15
16
17
18
19
20
Submit Documentation Feedback
........................................................................................................
.........................................................................................
................................................................................
.........................................................................................
.....................................................................................................
..................................................................................................
...................................................................................
....................................................................................................
....................................................................................................
....................................................................................
..............................................................................................................
..................................................................................................
.............................................................................................................
............................................................................................................
..........................................................................................................
.................................................................................
..............................................................................................
........................................................................................
.................................................................................................
................................................................................................
Copyright © 2017-2018, Texas Instruments Incorporated
SLAU659B - February 2017 - Revised March 2018
Transducer User's Guide
Contents
List of Figures
........................................................
......................................................................
User's Guide
................................
Guide
3
4
10
47
51
56
4
5
6
7
10
10
12
13
14
15
17
18
20
22
24
26
27
27
28
28
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Texas Instruments PGA460-Q1
Summary of Contents for Texas Instruments PGA460-Q1
-
Page 1: Table Of Contents
GUI. NOTE: Texas Instruments recommends using the PGA460-Q1 EVM user's guide (this document) after reading and following the steps listed in the PGA460-Q1 EVM Quick Start Guide. To download this guide, go to the product folder: www.ti.com/product/PGA460-Q1. Contents ........................ - Page 2 ......................Bill of Materials Trademarks LaunchPad, BoosterPack, Code Composer Studio, MSP430 are trademarks of Texas Instruments. SIMPLE SWITCHER is a registered trademark of Texas Instruments. All other trademarks are the property of their respective owners. PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's SLAU659B –...
-
Page 3: Introduction
Introduction The PGA460-Q1 EVM is a fully assembled evaluation module (EVM) designed for the combined evaluation of the PGA460-Q1 ultrasonic-sensor signal conditioner IC, an ultrasonic transducer, and center- tap transformer or half-bridge driver. Because of the two driver options, the user can evaluate any two pin, open or closed top ultrasonic transducer in the operating frequency range of 30 to 80 kHz, or 180 to 480 kHz. -
Page 4: Setup And Operation
Setup and Operation www.ti.com Figure 1 shows the PGA460-Q1 EVM architecture, identifying the key components and blocks previously listed. External Integrated USB Power 5 to 7.5 EXT to 5V 3.3V Power Mode Hub and Power Jumper eZ-FET Emulator Boost Buck... -
Page 5: Evm Boards Separated
Installing the Graphical User Interface Software Before the PGA460-Q1 device can be evaluated, the GUI software must be available on a host computer. Run the GUI installer and save the executable (.exe) file in a convenient location (such as the computer Desktop or the C:\Program Files (x86)\Texas Instruments\ folder). -
Page 6: Evm Boards - Assembled
(ESD). Use proper laboratory techniques and equipment to minimize the chance of an ESD or electrical overstress (EOS) event. PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's SLAU659B – February 2017 – Revised March 2018 Guide Submit Documentation Feedback... -
Page 7: Boostxl-Pga460 Functional Blocks
Figure 4 shows the functional blocks of the BOOSTXL-PGA460. Figure 4. BOOSTXL-PGA460 Functional Blocks SLAU659B – February 2017 – Revised March 2018 PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's Guide Submit Documentation Feedback Copyright © 2017–2018, Texas Instruments Incorporated... -
Page 8: Power Mode Jumper Position
Standard PGA460 is powered by an external source at J5 or J6. TI recommends (Default) full evaluation and development of the PGA460-Q1 be performed in the Pin2-4 Short standard power mode for best results. The MSP-EXP430F5529LP and BOOSTXL-PGA460 are powered by USB. - Page 9 GND by default. To use separate transmitter and receiver sense elements, desolder the R36 resistor, which shorts the return path of the transmitting net to the INP path of the PGA460-Q1. Install the receiver sense transducer element to J14.
-
Page 10: Software
GUI will fail to load. Flash Program MSP-EXP430F5529LP If the MSP-EXP430F5529LP has not been flash programmed with the required PGA460-Q1 EVM batch (.bat) firmware, the GUI will automatically prompt the user to do this at start-up, or after the MSP- EXP430F5529LP is plugged-in to the USB port. - Page 11 PGA460-Q1 device features, and modify the register configuration for optimal performance. Figure 7 shows the default starting screen of the PGA460-Q1 GUI. If the EVM is connected properly, the screen should display the following EVM Status indicators in the bottom left corner of the GUI: •...
-
Page 12: Pga460-Q1 Evm Gui Starting Screen With Successful Evm Connection Status
Software www.ti.com Figure 7. PGA460-Q1 EVM GUI Starting Screen With Successful EVM Connection Status The default start-up GUI view is of the block diagram page, which provides a high-level perspective of the internal blocks and configurable features of the device. This perspective is intended to present which user- controlled settings are most important for proper device operation. -
Page 13: Tree View
• Is the Disable PGA460-Q1 EVM Communication state set (Menu Bar → Edit)? This should be enabled to allow the GUI to operate correctly with the EVM. • If the device was powered after the GUI was first initialized, click the Check for PGA460-Q1 to retry the PGA460-Q1 check. -
Page 14: Evm Status - Success
Figure 9. EVM Status – Success In the event that no PGA460-Q1 EVM is connected, but the user is still interested in an example of the GUI configuration for a working device, the Simulation button will populate all controls with default values and allow the user to run the GUI with simulated results. -
Page 15: General Settings Configuration Page
3.5.1.1 General The General page is the most critical page for the initial configuration of the PGA460-Q1 device. The General page must be updated according to the specific driver mode, transducer specifications, and maximum distance to detect (see Figure 10). - Page 16 (30 cm to 7 m). The short range gain applied as soon as the PGA460-Q1 begins recording data, and the long range gain is applied at the time equivalent of the starting threshold point 9-12.
-
Page 17: Block Diagram
3.5.1.2 Block Diagram The block diagram representation of the PGA460-Q1 is a simplified view of the settings on the General page superimposed onto a visual equivalent of each device function. The block diagram perspective offers three control groups as shown in Figure Figure 11. -
Page 18: Time Varying Gain Page
Initial Gain and Gainn — Expressed in an absolute gain value in dB, and are unrelated from each other. The final gain assignment determined by the gain setting 5 will be kept constant until the end of the echo record time. PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's SLAU659B – February 2017 – Revised March 2018 Guide Submit Documentation Feedback Copyright ©... - Page 19 Clear Chart — Erases all data points on the TVG chart. SLAU659B – February 2017 – Revised March 2018 PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's Guide Submit Documentation Feedback Copyright © 2017–2018, Texas Instruments Incorporated...
-
Page 20: Threshold Page
CRC error that is always flagged high on initialization. The threshold CRC error must be cleared before the PGA460-Q1 is allowed to execute a Burst & Listen or Listen-Only command. - Page 21 1 or 2 threshold mapping will be refreshed. If not checked, the last auto- thresholding algorithm is applied to the last set of echo data dump values. SLAU659B – February 2017 – Revised March 2018 PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's Guide Submit Documentation Feedback...
-
Page 22: Diagnostic Page
The PGA460-Q1 device can implement a low-power mode where the current consumption is reduced to preserve system power. In the event of low-power mode, the threshold is reset upon wake-up, and must be rewritten to clear the threshold CRC error. - Page 23 Noise Only — During noise level measurement, the PGA460-Q1 device executes and returns the result of the Receive Only (Preset 2) command where no burst is performed; only a record interval is started and lasts 8.192 ms.
-
Page 24: Test Modes Page
3.5.1.6 Test Modes The Test Modes page contains the user controls required to both enable and route the PGA460-Q1 internal test modes and signals and to program or reload the EEPROM registers. Figure 15. Test Modes Page The internal signals on the TEST pin can be extracted by selecting a predefined signal through the internal test mux using the TEST_MUX register parameter. - Page 25 The shadow registers are referenced for all operations of the device. At start-up, the PGA460-Q1 device loads the shadow registers with the values stored in the EEPROM. If the PGA460-Q1 device is power cycled, the shadow registers are cleared and the shadow registers are reloaded with the EEPROM-based values.
-
Page 26: Data Monitor Page-Working Example
Time-of-Flight Converter on the Utilities tab to determine what the minimum record time length must be for a target at any given distance. PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's SLAU659B – February 2017 – Revised March 2018 Guide Submit Documentation Feedback Copyright ©... -
Page 27: Data Monitor-Run Options
No. Loops — The number of loops determines how many run commands are automatically issued to the PGA460-Q1 device by the GUI. To run an indefinite number of loops, set the value to 0. # of Objects to Detect — The number of objects to detect is only required for the ultrasonic measurement results feature, and is used to calculate the distance, width, and peak amplitude based on when the threshold is crossed by the echo profile. -
Page 28: Data Monitor-Graph Tab
Export Last Data Dump — Click this button to export the most recent echo data dump plot as a text, CSV , or XML file. PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's SLAU659B – February 2017 – Revised March 2018... -
Page 29: Data Monitor-Legend
EEPROM register and RAM register memory locations on the PGA460-Q1 device. The UART digital communication is a master-slave communication link in which the PGA460-Q1 is a slave device only. The master device controls when data transmission begins and ends. The slave device does not transmit data back to the master until it is commanded to do so by the master. -
Page 30: Interface - Uart Page
Figure 22. Interface - UART Page The UART page contains elements to configure the PGA460-Q1 device address, select the baud rate of the master, and manually send and receive command data. The controls available on the Diagnostic page are as follows: •... - Page 31 Send & Receive Bytes — When this button is clicked, the hex string displayed in the M-to-S Data Bytes (Hex) text box will be transmitted to the PGA460-Q1 device. The 0x55 sync byte is automatically appended to the beginning of the hex string during the transmit routine. After the transmit routine, a read routine is executed to display the data returned by the PGA460-Q1 device.
-
Page 32: Interface - Tci Page
PGA460-Q1 device to re-enable GUI communication. IO Transceiver Enabled — When this box is checked, the IO pin can be used for communication. PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's SLAU659B – February 2017 – Revised March 2018 Guide Submit Documentation Feedback Copyright ©... - Page 33 Command and Cmd Period — These options allow the user to select which TCI command to send from the GUI master to the PGA460-Q1 slave device. Each command toggles the IO pin low for a given time as indicated in the Cmd Period text box in the form of minimum | nominal | maximum microseconds.
-
Page 34: Memory Map Page
Zero Grid Set all register values to 0. Deselect Grid Remove all selections from the grid. PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's SLAU659B – February 2017 – Revised March 2018 Guide Submit Documentation Feedback Copyright © 2017–2018, Texas Instruments Incorporated... - Page 35 A row on the Memory Map page that is highlighted yellow indicates a queued modification to the grid, but a pending write to the PGA460-Q1 device. If multiple rows indicate queued changes are pending (multiple yellow rows), each row requires an individual Write Single click, or single Write All click.
-
Page 36: Faults And Errors Tab
Figure 25. Faults and Errors Tab PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's SLAU659B – February 2017 – Revised March 2018 Guide Submit Documentation Feedback Copyright ©... -
Page 37: Device Error Status Descriptions
0 = No error 1 = VPWR undervoltage error The PGA460-Q1 device begins the response transmission with a diagnostic data field. This field contains UART communication error bits. If a particular bit is set to 1 then the associated communication error has occurred sometime between the last response operation and the current response operation. -
Page 38: Pga460-Q1 Uart Diagnostic Data Description
After every UART command, the UART diagnostic bits are read. After every BURST and LISTEN command, LISTEN ONLY command, or register read or write, the error status bits of the device are updated. PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's SLAU659B – February 2017 – Revised March 2018 Guide Submit Documentation Feedback Copyright ©... -
Page 39: Utilities Tab
3.6.2.2 Time-of-Flight Converter Because the PGA460-Q1 device is intended for use in time-of-flight calculations, the time-of-flight converter is used to compute a distance or round-trip time equivalent for the user input variable. Speed of sound is assumed to be 343 m/s at room temperature by default. The speed of sound can change across temperature and humidity. - Page 40 The coefficient values of the band-pass filter (BPF) of the digital signal processing block are automatically calculated and updated by the PGA460-Q1 device for the low operating frequency range of 30 to 80 kHz. In the event the high-frequency range of 180 to 480 kHz is required, the PGA460-Q1 coefficient values must be updated manually to match the desired frequency and BPF width.
-
Page 41: Register Tab
27). If the Register tab is selected, the Memory Map page will load into the center panel. Figure 27. Register Tab SLAU659B – February 2017 – Revised March 2018 PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's Guide Submit Documentation Feedback Copyright © 2017–2018, Texas Instruments Incorporated... -
Page 42: Power Budget Calculator For Pga460-Q1
Power Budget Calculator — The user can approximate the average power consumption of the PGA460-Q1 device by specifying the required device parameters, power modes, and command interval length. Figure 28. Power Budget Calculator for PGA460-Q1 PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's SLAU659B –... -
Page 43: Echo Data Dump Plotter For Pga460-Q1
Data Plotter— Echo data dumps exported from the Data Monitor page can be loaded into the Plotter for post-analysis, overlap, comparison, and averaging. Figure 29. Echo Data Dump Plotter for PGA460-Q1 SLAU659B – February 2017 – Revised March 2018 PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's... -
Page 44: Scripting For Pga460-Q1
PGA460-MATCHING daughtercard hardware, which is available as a Design File on the PGA460-Q1 product page. The MATCHING daughtercard uses the LaunchPad's standard I2C port available on LP-BP pins 9 (P4.2) and 10 (P4.1) for SCL and SDA respectively. Connect the I2C port of the MATCHING daughtercard to the I2C pins on the BOOSTXL-PGA460 motherboard. -
Page 45: Matching Daugthercard
GUI Initialization Mode — When the BOOSTXL-PGA460 (Standard) mode is selected, the GUI will initialize with the expectation of communicating to the PGA460-Q1 through UART. When the External IO-Pin Only mode is selected, the GUI will initialize with the expectation that an external module is connected to the BOOSTXL-PGA460 motherboard using IO-TCI and IO- OWU communication only. - Page 46 LED to indicate that the EVM is operating correctly, and that a PGA460-Q1 device is detected. If the virtual LED turns red, either the EVM hardware has disconnected, or a PGA460-Q1 device was not detected.
-
Page 47: External Pga460-Q1 Evaluation
By detaching the BOOSTXL-PGA460 from the PGA460-Q1 EVM, the MSP-EXP430F5529LP can still be used as the master controller and interface to the PGA460-Q1 GUI through logic level USART. However, if the supply-voltage TCI or OWU interfaces are to be routed to the external PGA460-Q1 module, the BOOSTXL-PGA460 motherboard is required, and additional register modifications must be made to the onboard PGA460-Q1 device. -
Page 48: External Owi Evaluation Setup For Pga460Q1Usff-Xf Module With Software Modification
No. Once all register changes and hardware connections are ready, the GUI will automatically restart or be manually restarted to reveal and initialize to the OWI Evaluation page. PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's SLAU659B – February 2017 – Revised March 2018... -
Page 49: Owi Evaluation
Ensure to restart the GUI after changing the initialization mode. Figure 34. One-Wire Evaluation Page—Working Example SLAU659B – February 2017 – Revised March 2018 PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's Guide Submit Documentation Feedback Copyright © 2017–2018, Texas Instruments Incorporated... - Page 50 OWI Chart. When the Read (R) button is clicked, the Device Settings section is updated with the latest values read from the PGA460-Q1. When the Write (W) button is clicked, only the Device Settings highlighted in yellow will be updated; otherwise, there has been no change to the value since the last read.
-
Page 51: Schematic, Bill Of Materials, And Layout
GPIO ! Copyright © 2017, Texas Instruments Incorporated Figure 35. PGA460-Q1 EVM Schematic – USSC SLAU659B – February 2017 – Revised March 2018 PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's Guide Submit Documentation Feedback Copyright © 2017–2018, Texas Instruments Incorporated... -
Page 52: Pga460-Q1 Evm Schematic - Driver And Transducer
INP_DD DECPL_DD GND_DD Copyright © 2017, Texas Instruments Incorporated Figure 36. PGA460-Q1 EVM Schematic – Driver and Transducer PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's Guide SLAU659B – February 2017 – Revised March 2018 Submit Documentation Feedback Copyright © 2017–2018, Texas Instruments Incorporated... -
Page 53: Pga460-Q1 Evm Schematic - Power
MAIN_LOCAL Copyright © 2017, Texas Instruments Incorporated Figure 37. PGA460-Q1 EVM Schematic - Power SLAU659B – February 2017 – Revised March 2018 PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's Guide Submit Documentation Feedback Copyright © 2017–2018, Texas Instruments Incorporated... -
Page 54: Bill Of Materials
Schematic, Bill of Materials, and Layout www.ti.com Bill of Materials Table 8 lists the bill of materials (BOM) for the PGA460-Q1 EVM. Table 8. Bill of Materials Designator Quantity Value Description Package Part Number Manufacturer 0.47uF CAP, CERM, 0.47 µF, 50 V, +/- 10%,... - Page 55 RES, 1.0 k, 5%, 0.1 W, 0603 0603 CRCW06031K00JNEA Vishay-Dale RES, 0, 5%, 0.25 W, 1206 1206 CRCW12060000Z0EA Vishay-Dale SLAU659B – February 2017 – Revised March 2018 PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's Guide Submit Documentation Feedback Copyright © 2017–2018, Texas Instruments Incorporated...
-
Page 56: References
TS3L501E 8-Channel SPDT/16-Bit to 8-Bit Multiplexer and Demultiplexer Ethernet LAN Switch With Power-Down Mode • PGA460-Q1 Ultrasonic Sensor-Signal Conditioner • SN65HVDA100-Q1 LIN Physical Interface (SLIS128) PGA460-Q1 Ultrasonic Signal Conditioner EVM With Transducer User's SLAU659B – February 2017 – Revised March 2018 Guide Submit Documentation Feedback Copyright © 2017–2018, Texas Instruments Incorporated... - Page 57 Added the Datalog directory path ..................• Added new definitions to the File Menu section ..................• Added External PGA460-Q1 Evaluation section ........• Added SN65HVDA100-Q1 LIN Physical Interface (SLIS128) app note to References Changes from Original (February 2017) to A Revision ....................
