- Page 1 High performance HMI-Projector BP 12 Platin Order Code:…………22207...
-
Page 2: Table Of Contents
High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH CONTENTS Version September 2009 Page Dimension Drawing ..............2 1.1) High Performance HMI- Projector BP 12 Platin-II, 1.2) Ballast ................... 2 Position Drawing ................. 3 2.1) HMI- Projector BP 12Platin-II with High Performance Fan and associated legend ............ -
Page 3: Dimension Drawing
High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH 1) Dimension Drawing 1.1) High Performance HMI- Projector BP 12 Platin-II 1.2) Ballast Type BU12K Best. Nr. 19214 Order C o d e Nennspg.: Serien Nr.: Rated volt.: Serial N o . -
Page 4: Position Drawing
High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH 2) Position Drawing 2.1) HMI- Projector BP 12 Platin-II with High Performance Fan LEGEND Support Spindle Horizontal Adjust Height Adjust Locking Screws Housing Cover Lamp Covers Slide Carrier... -
Page 5: Control Panel On The Projector With Associated Legend
High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH 2.2) Control Panel on the Projector LEGEND Source Power Signal Lamp „ON“ – Push-button (green) „OFF“ – Push-button (red) Hour Counter Connector for Control Cable Connector for Main Power... -
Page 6: Ballast
High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH 2.3) Ballast Type BU12K Best. Nr. 19214 Order C o d e Nennspg.: Serien Nr.: Rated volt.: Serial No. € • ‚ ƒ 208/220/240V-50/60Hz Nennl e i s tung Rated cap. -
Page 7: Construction
High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH 3.) Construction 3.1) Mechanical Construction of the Projector The Aluminium housing is mounted in a stable, mobile undercarriage. Once the unit is in place, the front casters may be lifted from the floor with the two support spindles, fixing the unit in position. -
Page 8: Electrical Hook-Up
5) Electrical Hook-Up CIRCUIT DIAGRAM 102- 08- 07 SEE PAGE 8 The HMI- Projector BP 12 Platin operated by hte ballast BU 12 K (Order Code 19214). The lamp current is limited to 84A by a built in inductor. Therefore an electrical modification of the lamp current (dimming) is impossible. -
Page 9: Electrical Schematic
High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH 6) Circuit Diagram Drawing No.: 102-08-04/c... -
Page 10: Objective Lenses
7.1) Front Condenser Lens POSITION DRAWING OF CONDENSER SYSTEM SEE PAGE 11 In the HMI-projector BP 12 Platin 3 different interchangable multicoated front condenser lenses are used depending upon the applied projection ojectives. Order Code: 12410, Ø 320 mm/ f= 400 mm for Objectives f= 11; 13, 5; 18; 22; 27 cm, Order Code: 12411, Ø... -
Page 11: Projection Diagram
High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH METER Bildbreite der Projektion B Z ... ZOOM-Objektiv Endposition 8) Projection diagram for O= 23cm Berechnungsformeln: Legend: focal length of projection lens width of the image projection distance... -
Page 12: Condenser System And Legend
High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH 9) Condenser System Type: Order Code: Cold Light Mirror Ø 155mm 222-03-04 24-0043 HMI- Lamp 12000 W/ GS H 1701 37205 Fresnel Lens Ø 300 mm 85 40 51... -
Page 13: Basic Unit As Delivered
60 cm and vario - objective f= 30-60 cm G 405/ 60 12014 High Performance Slide Cooling Fan for BP 12 Platin-II CMB/2-140/50 432519 Additional fan for all kinds of Gray Scale Shutters G 405 in combination with wide angle objectives 11 -18 cm... -
Page 14: General Technical Data
High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH 12) General Technical Data Projector: Tilt range of the Projektor: 12° up 35° down Protection Class: IP 20 Ambient Operating Temperature: max. 35°C Weight: unpacked packed 124 kg... -
Page 15: Spare Parts
High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH 13) Spare Parts BP 12 Platin-II number Order text Order Code: per unit Housing Heat Dissipation 11-0089 Louvers for 11-0089 11-0095 Pins for Cover 11-0090 Housing Screen (left+right) - Page 16 High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH number Order text Order Code: per unit Optical Material Fresnel Lens (lamp side) „ 300 mm 24-0033 Planconvex Lens (middle lens) „ 320 mm/ f= 677 mm 24-0034 Interchangable Front Condenser Lens f= 11- 27 cm „...
- Page 17 High Performance HMI-Projector BP 12 Platin-II PANI Projection and Lighting Vertriebs GmbH Ballast BU-12K Pos. Order Text Order Code: number per unit Shock Mounts 88941401 Contactor Base 81015418 Contactor 88472241 Timer 88472210 Clamp Sak G28 84610128 Housing 71111025 Resistor 88201475...
