- Page 1 Step By Step Guide Inverter BRC10 Part number: 0478-0724-06 Issue: 06 Read the User Guide Before using this product you must read and understand the safety information within the Inverter BRC10 User Guide...
-
Page 2: Important Safety Information
Introduction This guide provides step-by-step instructions on how to install the drive, wire the drive using appropriate fuses and cables, configure the drive and run the motor. Download the full Inverter BRC10 User Guide at www.bermar.it. Important safety information Hazards This Step by Step Guide applies to Inverter BRC10 drives and supplies safety information that must be observed. -
Page 3: Step 1: Mount The Drive
Diameter 156 mm 68 mm 130 mm 0.7 kg 46 mm 145 mm 45 mm 22.5 mm 4.8 mm BRC1001 6.14 in 2.70 in 5.12 in 1.54 lb 1.81 in 5.71 in 1.77 in 0.89 in 0.19 in 192 mm... -
Page 4: Power Connections
Power connections Connect the supply and motor connections using the cables and fuses or MCB's in Table 1-4. When using a single-phase supply, the supply should be connected to L1 and L2. Figure 1-1 Power terminal connection Table 1-2 Recommended Torque Settings Drive Voltage 100 V 200 V... - Page 5 Supply Cable, Motor Cable and Fuse/MCB Selection Table 1-3 Fuse, MCB and Cable Compliance Standard Fuse Class CC, J or T Compliant with EN IEC 60947-2 are The circuit breaker must be UL listed and suitable for recommended, with > 5 kA short circuit the installation environment, rated 600 Vac with a short breaking capacity.
-
Page 6: Step 3: Run The Motor
STEP 3: Run the motor The keypad can be used to edit drive parameters directly. For a guide to use the drive keypad, refer to Figure 1-3. Configure Action Detail Power Power the drive, ensure the drive is not enabled. (Display shows: inh) Minimum Frequency Limit P0.01 (Hz) Maximum Frequency Limit P0.02 (Hz) Typically, the maximum frequency limit used is the motor rated frequency. - Page 7 Figure 1-3 Using the Keypad Running Enable Required Required Used to navigate through the drive's parameter settings and rotate Settings Key displayed parameters when the drive is running. Used to reset the drive if there is an error and to stop the drive Stop / Reset Key running if enable/run configuration is set appropriately.
- Page 8 Opozorilo Brīdinājums Pred uporabo tega izdelka morate prebrati in Pirms šā produkta lietošanas ir jāizlasa un jāizprot razumeti varnostne informacije v navodilih za informācija par drošību, kas iekļauta lietošanas uporabo na spodnjem spletnem naslovu. pamācībā tālāk norādītajā URL. www.bermar.it...
- Page 9 ħdan il-Gwida och förstå säkerhetsinformationen i għall-Utent fil-URL t’isfel. användarhandboken på nedanstående URL- adress. Ostrzeżenie Przed przystąpieniem do użytkowania produktu należy przeczytać ze zrozumieniem informacje dotyczące bezpieczeństwa przedstawione w Podręczniku użytkownika dostępnym pod następującym adresem. www.bermar.it...
- Page 10 Company information BER-MAR S.R.L. Via C.. Bassi 28/ A, 40015 S.Vincenzo di Galliera (BO) 0478-0724-06...
