Operator's Manual
BIG FOOT
TREE LADDER
MODEL RE731
Maximum Height
23' to top
Maximum Field Rating
300 lbs
Tree Diameter Range
8" to 20"
Wear Your Harness!
P/N: 33165
© 2020 RETI
C/N: 33164
All Rights Reserved
REV2: 08/25/2020
™
Advertisement
Table of Contents
Related Manuals for TMA Big Foot TREE LADDER RE731
Summary of Contents for TMA Big Foot TREE LADDER RE731
- Page 1 Operator's Manual CLIMBING SYSTEMS BIG FOOT WE ARE HUNTERS TREE LADDER ™ MODEL RE731 Maximum Height 23' to top Maximum Field Rating 300 lbs Tree Diameter Range 8" to 20" Wear Your Harness! PRODUCT MEETS INDUSTRY STANDARDS RECOGNIZED BY P/N: 33165 Get parts online at ©...
-
Page 2: Table Of Contents
Operator's Manual CLIMBING SYSTEMS BIG FOOT TREE LADDER INTRODUCTION Rivers Edge® Treestands are engineered with you the hunter in mind. We appreciate your purchase of one of our world class treestands. Follow these few simple instructions and your stand will provide you many years of trouble-free pleasure. -
Page 3: Warnings
Operator's Manual CLIMBING SYSTEMS BIG FOOT TREE LADDER READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE ASSEMBLY STOP MODEL RE731 WARNING TOTAL WEIGHT LIMIT - 300 LB Pull up a bow, backpack, or firearm or other equipment TREE DIAMETER RANGE - 8" TO 20" only after being secure in the treestand and a firearm must be pulled up with it unloaded, chamber open, and MAXIMUM USE HEIGHT - 23’... -
Page 4: Inspection And Maintenance
Operator's Manual CLIMBING SYSTEMS BIG FOOT TREE LADDER WARNING INSPECTION AND MAINTENANCE Read and perform all inspection and maintenance tasks before each and every use. Replace any questionable BEFORE EACH USE PERFORM THE FOLLOWING: components immediately with RETI original replacement parts. -
Page 5: Assembly Instructions
Operator's Manual CLIMBING SYSTEMS BIG FOOT TREE LADDER ASSEMBLY INSTRUCTIONS SETUP AND USE INSTRUCTIONS No Tools Needed 1. Stand the assembled Big Foot Tree Ladder up against a selected straight tree on dry, level ground. 1. Assembly is done on the ground by inserting the male (crimped) top end of each crimped ladder section (1) into the female end of 2. -
Page 6: Illustrated Parts Breakdown
Operator's Manual CLIMBING SYSTEMS BIG FOOT TREE LADDER ILLUSTRATED PARTS BREAKDOWN PARTS LIST KEY # PART # DESCRIPTION QTY. 25828 CRIMPED LADDER SECTION 25829 TOP LADDER SECTION 19847 LOCKPIN 6MM X 50.8MM MK013- RATCHET STRAP ASSEMBLY WITH 3401 S-HOOK 1 IN X 6 FT 23439 SQUARE END PLUG 22MM NO EXTENSIONS AVAILABLE FOR THIS MODEL. -
Page 7: Notes Page
Operator's Manual CLIMBING SYSTEMS BIG FOOT TREE LADDER NOTES Check for parts online at www.HuntRiversEdge.com or call 800-345-6007 M-F 8-5... - Page 8 CLIMBING SYSTEMS WE ARE HUNTERS Rivers Edge® Treestands, Inc. Phone: 800-345-6007 1160 Eighth Avenue, PO Box 755 Fax: 715-822-2124 Cumberland, WI 54829 Email: info@huntriversedge.com *All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvements, product images may not be exact. Warning labels in some product images may have been removed for photography purposes only.
