e-Lite
DC INVERTER FREE | LV-MO80 > 180
Installation and Operation Manual
LV-MO80-180-IOM- 20.04-E

Advertisement

loading
Need help?

Need help?

Do you have a question about the e-Lite LV-M080 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lennox e-Lite LV-M080 Series

  • Page 1 e-Lite DC INVERTER FREE | LV-MO80 > 180 Installation and Operation Manual LV-MO80-180-IOM- 20.04-E...
  • Page 3: Table Of Contents

    CONTENTS PAGE WARNING PRECAUTIONS................1 If the supply cord is damaged, it must be replaced by the ATTACHED FITTINGS..............2 manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. OUTDOOR UNIT INSTALLATION............3 An all-pole disconnection switch having a contact separation of INSTALL THE CONNECTING PIPE.............4 at least 3mm in all poles should be connected in fixed wiring.
  • Page 4: Attached Fittings

    An insufficient power supply capacity or inappropriate installation 6) Reamer may cause fire. 7) Gas leak detector Use the specified cables for wiring connect the terminals 8) Tape measure securely fix. To prevent external forces applied to the terminals 9) Thermometer from affecting the terminals.
  • Page 5: Outdoor Unit Installation

    Installation in the following places may result in some troubles. Do not install the unit in such places below. A place full of machine oil. A place full of sulphuric gas. A place where high-frequency radio waves are likely to be generated as from audio quipment, welders, and medical equipment.
  • Page 6: Install The Connecting Pipe

    INSTALL THE CONNECTING PIPE 3.3 Moving and installation Since the gravity center of the unit is not at its physical center, Check whether the height drop between the indoor unit and so please be careful when lifting it with a sling. outdoor unit, the length of refrigerant pipe, and the number of the bends meet the following requirements: Never hold the inlet of the outdoor unit to prevent it from...
  • Page 7 The second connect methond Outdoor Unit(Take Model 160 for example) Check point of indoor unit Check point of outdoor unit (28) Intdoor Units (28) Fig. 4-2 (28) The First Line Branch Pipe 4.3 Heat Insulation (28) Do the heat insulation to the pipes of air side and liquid side separately.
  • Page 8 Table 4-8 The straight distance between the contiguous branchpipes is at Capacity of Maximum Sum Capacity least 0.5m; Outdoor Unit Outdoor unit Quantity of of Indoor unit The straight distance which the branch pipes connected to the (kW) (horsepower) Indoor unit (horsepower) indoor unit is at least 0.5m;...
  • Page 9 The indoor unit below to the main pipe L3 are N3~N6, and its to- Indoor unit branch pipe tal capacity is 28×3+22=106, the size of pipe L3 isΦ15.9/Φ9.5, Inner branch pipes are a~f, the size selection please refers to and he branch pipe C should be FQZHN-01D. Table4-6.
  • Page 10 The second cennect methond Outdoor unit Pipe length(From the nearest branch pipe equivalent length Maximum pipe equivalent length (From the first line branch pipe) Maximum pipe equivalent length The First Line Branch Pipe Indoor unit Fig.4-8 4.10 Refrigerant Amount to be Added 4.7 Remove Dirt or Water in the Piping Make sure there is no any dirt or water before connectiong Calculate the added refrigerant according to the diameter and the...
  • Page 11: Electrical Wiring

    ELECTRICAL WIRING Outdoor unit X Y E P Q E Power Supply Signal wire between indoor/outdoor unit Indoor unit Indoor unit Indoor unit Branch Box Branch Box Branch Box Power Supply Signal wire between indoor units Please use 3-core shielded wire, and connect the shielded layer to Grounding Fig.
  • Page 12 Power (380-415V~ 50Hz 3-Phase) Power (220-240V~ 50Hz 1-Phase) (380-415V~ 60Hz 3-Phase) (220-240V~ 60Hz 1-Phase) (208-230V~ 60Hz 3-Phase) (208-230V~ 60Hz 1-Phase) Switch / Circuit breaker Switch / Circuit breaker Power wiring Power wiring wire distribution box (indoor) (outdoor) in broken line table, users can purchase the Central control montior when necessary.please contract with local supplier in details .
  • Page 13 Wrong connection may cause malfunction . NOTE Wiring Connection The wire diameter and continuous length is under the Seal the wiring connection with the insulation material , or the condition that the voltage vibration is within 2%. If the condensing dew will be caused. continuous length is exceed showing value, choose the wire diameter follow relevant regulation.
  • Page 14: Test Running

    Table 5-3 Outdoor unit SW3(SW-1) Obtain network address automatically Obtain network address manually Indoor unit Revocation indoor unit network address Room full of leak refrigerant (All refrigerant has run up) b. Leak alarm related to mechanical ventilator Indoor unit TEST RUNNING Operate according to "gist for test running"...
  • Page 15 8.1 Information requirements for air-to-air conditioners Cooling mode: Information requirements for air-to-air conditioners Model(s): LV-MO120-I4T Test matching indoor units from 2, non-duct: 2×LV-C4(C)36-2DC + 2×LV-C4(C)22-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Type:compressor driven If applicable:driver of compressor:electric motor Item Symbol...
  • Page 16 Heating mode: Information requirements for air-to-air conditioners Model(s): LV-MO120-I4T Test matching indoor units from 2, non-duct: 2×LV-C4(C)36-2DC + 2×LV-C4(C)22-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Idication if the heater is equipped with a supplementary heater:no If applicable:driver of compressor:electric motor Parameters shall be declared for the anerage heating season,parameters for the warmer and colder heating seasoms are optional Item...
  • Page 17 Cooling mode: Information requirements for air-to-air conditioners Model(s): LV-MO120-I4M Test matching indoor units from 2, non-duct: 2×LV-C4(C)36-2DC + 2×LV-C4(C)22-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Type:compressor driven If applicable:driver of compressor:electric motor Item Symbol Value...
  • Page 18 Heating mode: Information requirements for air-to-air conditioners Model(s): LV-MO120-I4M Test matching indoor units from 2, non-duct: 2×LV-C4(C)36-2DC + 2×LV-C4(C)22-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Idication if the heater is equipped with a supplementary heater:no If applicable:driver of compressor:electric motor Parameters shall be declared for the anerage heating season,parameters for the warmer and colder heating seasoms are optional Item...
  • Page 19 Cooling mode: Information requirements for air-to-air conditioners Model(s): LV-MO140-I4T Test matching indoor units from 2, non-duct: 2×LV-C4(C)36-2DC + 2×LV-C4(C)28-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Type:compressor driven If applicable:driver of compressor:electric motor Item Symbol Value...
  • Page 20 Heating mode: Information requirements for air-to-air conditioners Model(s): LV-MO140-I4T Test matching indoor units from 2, non-duct: 2×LV-C4(C)36-2DC + 2×LV-C4(C)28-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Idication if the heater is equipped with a supplementary heater:no If applicable:driver of compressor:electric motor Parameters shall be declared for the anerage heating season,parameters for the warmer and colder heating seasoms are optional Item...
  • Page 21 Cooling mode: Information requirements for air-to-air conditioners Model(s): LV-MO140-I4M Test matching indoor units from 2, non-duct: 2×LV-C4(C)36-2DC + 2×LV-C4(C)28-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Type:compressor driven If applicable:driver of compressor:electric motor Item Symbol Value...
  • Page 22 Heating mode: Information requirements for air-to-air conditioners Model(s): LV-MO140-I4M Test matching indoor units from 2, non-duct: 2×LV-C4(C)36-2DC + 2×LV-C4(C)28-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Idication if the heater is equipped with a supplementary heater:no If applicable:driver of compressor:electric motor Parameters shall be declared for the anerage heating season,parameters for the warmer and colder heating seasoms are optional Item...
  • Page 23 Cooling mode: Information requirements for air-to-air conditioners Model(s): LV-MO160-I4T Test matching indoor units from 2, non-duct: 2×LV-C4(C)45-2DC + 2×LV-C4(C)36-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Type:compressor driven If applicable:driver of compressor:electric motor Item Symbol Value...
  • Page 24 Heating mode: Information requirements for air-to-air conditioners Model(s): LV-MO160-I4T est matching indoor units from 2, non-duct: 2×LV-C4(C)45-2DC + 2×LV-C4(C)36-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Idication if the heater is equipped with a supplementary heater:no If applicable:driver of compressor:electric motor Parameters shall be declared for the anerage heating season,parameters for the warmer and colder heating seasoms are optional Item...
  • Page 25 Cooling mode: Information requirements for air-to-air conditioners Model(s): LV-MO160-I4M Test matching indoor units from 2, non-duct: 2×LV-C4(C)45-2DC + 2×LV-C4(C)36-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Type:compressor driven If applicable:driver of compressor:electric motor Item Symbol Value...
  • Page 26 Heating mode: Information requirements for air-to-air conditioners Model(s): LV-MO160-I4M Test matching indoor units from 2, non-duct: 2×LV-C4(C)45-2DC + 2×LV-C4(C)36-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Idication if the heater is equipped with a supplementary heater:no If applicable:driver of compressor:electric motor Parameters shall be declared for the anerage heating season,parameters for the warmer and colder heating seasoms are optional Item...
  • Page 27 Cooling mode: Information requirements for air-to-air conditioners Model(s): LV-MO180-I4M Test matching indoor units from 2, non-duct: 4×LV-C4(C)45-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Type:compressor driven If applicable:driver of compressor:electric motor Item Symbol Value Unit Item...
  • Page 28 Heating mode: Information requirements for air-to-air conditioners Model(s): LV-MO180-I4M Test matching indoor units from 2, non-duct: 4×LV-C4(C)45-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Idication if the heater is equipped with a supplementary heater:no If applicable:driver of compressor:electric motor Parameters shall be declared for the anerage heating season,parameters for the warmer and colder heating seasoms are optional Item...
  • Page 29 Cooling mode: Information requirements for air-to-air conditioners Model(s): LV-MO80-I4T Test matching indoor units from 2, non-duct: 2×LV-C4(C)36-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Type:compressor driven If applicable:driver of compressor:electric motor Item Symbol Value Unit Item...
  • Page 30 Heating mode: Information requirements for air-to-air conditioners Model(s): LV-MO80-I4T Test matching indoor units from 2, non-duct: 2×LV-C4(C)36-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Idication if the heater is equipped with a supplementary heater:no If applicable:driver of compressor:electric motor Parameters shall be declared for the anerage heating season,parameters for the warmer and colder heating seasoms are optional Item...
  • Page 31 Cooling mode: Information requirements for air-to-air conditioners Model(s): LV-MO105-I4T Test matching indoor units from 2, non-duct: 2×LV-C4(C)45-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Type:compressor driven If applicable:driver of compressor:electric motor Item Symbol Value Unit Item...
  • Page 32 Heating mode: Information requirements for air-to-air conditioners Model(s): LV-MO105-I4T Test matching indoor units from 2, non-duct: 2×LV-C4(C)52-2DC Outdoor side heat exchanger of air conditioner:air Indoor side heat exchanger of air conditioner:air Idication if the heater is equipped with a supplementary heater:no If applicable:driver of compressor:electric motor Parameters shall be declared for the anerage heating season,parameters for the warmer and colder heating seasoms are optional Item...
  • Page 36 Before using your air conditioner, please read this manual carefully and keep it for future reference. Due to LENNOX EMEA ongoing commitment to quality, the specifications, ratings and dimensions are subject to change without notice and without incurring liability. Improper installation, adjustment, alteration, service or maintenance can cause property damage or personal injury.
